INSTALLATION, TECHNICAL,
MAINTENANCE
Reciprocating Condensing unit
for medium temperature application
DRM Codes
JEHBCU0150M1
JEHBCU0150M3
JEHBCU0225M1
JEHBCU0225M3
JEHBCU0300M1
JEHBCU0300M3
JEHBCU0400M3
JEHBCU0500M3
JEHBCU0600M3
JEHBCU0675M3
JEHBCU0825M3
JEHBCU1000M3
Reciprocating Condensing unit
for low temperature application
DRM Codes
JEHBCU0175L1
JEHBCU0175L3
JEHBCU0225L1
JEHBCU0225L3
JEHBCU0350L3
JEHBCU0400L3
JEHBCU0725L3
Scan below QR code to download latest manual from
Website:
https://drm.daikinmalaysia.com/download/
T-CU01-APR24-7
DMSS Codes
LRMRS0150AXV1
LRMRS0150AXY1
LRMRS0225AXV1
LRMRS0225AXY1
LRMRS0300AXV1
LRMRS0300AXY1
LRMRS0400AXY1
LRMRS0500AXY1
LRMRS0600AXY1
LRMRS0675AXY1
LRMRS0825AXY1
LRMRS1000AXY1
DMSS Codes
LRLRS0175AXV1
LRLRS0175AXY1
LRLRS0225AXV1
LRLRS0225AXY1
LRLRS0350AXY1
LRLRS0400AXY1
LRLRS0725AXY1
V2
AIR COOLED SPLIT
COMMERCIAL CONDENSING
UNIT
IOM NO: T-CU01-APR24-7
Scroll Condensing unit
for medium temperature application
DRM Codes
JEHBSCU0200M1
JEHBSCU0200M3
JEHBSCU0250M1
JEHBSCU0250M3
JEHBSCU0300M1
JEHBSCU0300M3
JEHBSCU0350M1
JEHBSCU0350M3
JEHBSCU0400M1
JEHBSCU0400M3
JEHBSCU0500M3
JEHBSCU0600M3
JEHBSCU0680M3
JEHBSCU0800M3
JEHBSCU1000M3
Scroll Condensing unit
for low temperature application
DRM Codes
JEHBSCU0200L3
JEHBSCU0300L3
JEHBSCU0400L3
JEHBSCU0500L3
JEHBSCU0600L3
JEHSCU0750CL3
JEHSCU0951CL3 EVI
DMSS Codes
LRMSS0200AXV1
LRMSS0200AXY1
LRMSS0250AXV1
LRMSS0250AXY1
LRMSS0300AXV1
LRMSS0300AXY1
LRMSS0350AXV1
LRMSS0350AXY1
LRMSS0400AXV1
LRMSS0400AXY1
LRMSS0500AXY1
LRMSS0600AXY1
LRMSS0680AXY1
LRMSS0800AXY1
LRMSS1000AXY1
DMSS Codes
LRLSS0200AXY1
LRLSS0300AXY1
LRLSS0400AXY1
LRLSS0500AXY1
LRLSS0600AXY1
LRLSFS0750BXY1
LRLVFS0951BXY1
Page I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LRLRS0175AXV1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daikin LRLRS0175AXV1

  • Page 1 JEHBSCU0800M3 LRMSS0800AXY1 JEHBSCU1000M3 LRMSS1000AXY1 Reciprocating Condensing unit Scroll Condensing unit for low temperature application for low temperature application DRM Codes DMSS Codes DRM Codes DMSS Codes JEHBCU0175L1 LRLRS0175AXV1 JEHBSCU0200L3 LRLSS0200AXY1 JEHBCU0175L3 LRLRS0175AXY1 JEHBSCU0300L3 LRLSS0300AXY1 JEHBCU0225L1 LRLRS0225AXV1 JEHBSCU0400L3 LRLSS0400AXY1 JEHBCU0225L3 LRLRS0225AXY1...
  • Page 2 READ BEFORE PROCEEDING! GENERAL SAFETY GUIDELINES This guideline is intended for users to ensure safe installation, operation, and maintenance of DAIKIN condensing units. This guideline is not intended to replace the system expertise available from the system manufacturers. This equipment is a relatively complicated apparatus. During installation, operation, maintenance or service, individuals may be exposed to certain components or conditions including, but not limited to refrigerants, materials under pressure, rotating components, and both high and low voltage.
  • Page 3: Table Of Contents

    LRLRS0725~ LRLRS0825 ..........6 WIRING DIAGRAM ..........23 LRLSFS0750 ..............6 LRLRS0225AXV1, LRMRS0225AXV1, LRMRS0300AXV1 23 LRLVFS0951 ..............7 LRLRS0175AXV1, LRMRS0150AXV1 ......23 OUTLINE DRAWINGS ..........7 LRMSS0200AXV1, LRMSS0250AXV1, LRMSS0300AXV1 LRMRS0150~ LRMRS0300; LRLRS0175~ LRLRS0225; ..................24 LRMSS0200~ LRMSS0300; LRLSS0200 & LRLSS0300 ..7 LRMSS0350AXV1, LRMSS0400AXV1 ......
  • Page 4 ) ......32 ELECTION UNIT ) ......32 NSULATION ELECTION UNIT ) ....32 XPANSION ALVE ELECTION UNIT ............33 RESSURE ESTING .............. 33 ETECTION & C ..........33 VACUATION HARGING ..............33 LECTRICAL ............34 TART HECKS ............34 UNNING ............
  • Page 5: Nomenclature

    Nomenclature Digit Description L – Daikin low temperature air conditioner R – Outdoor Unit 3 & 4 LR – Low Temp. Reciprocating; MR – Medium Temp. Reciprocating LS – Low Temp. Scroll MS – Medium Temp. Scroll LSF – Low Temp. Scroll with Fan Speed Controller LVF –...
  • Page 6: Specifications

    Specifications General Medium Temperature Application Compressor Fan Motors Electrical Data MODEL Swept Operating MCC** Power Input Type Oil type LRC (A) FLC (A) volume Charge Current DRM Codes DMSS Codes (m³/h) (cm³) (A)* JEHBCU-0150-M-1 LRMRS0150AXV1 230V/1~/50Hz MTZ18-5VM 5.26 JEHBCU-0150-M-3 LRMRS0150AXY1 400V/3~/50Hz MTZ18-4VM 5.26...
  • Page 7: General Low Temperature Application

    MODEL Swept Operating MCC** Power Input Type Oil type volume Charge Current DRM Codes DMSS Codes (m³/h) (cm³) (A)* LRLRS0175AXV1 230V/1~/50Hz NTZ48-5VM JEHBCU-0175-L-1 LRLRS0175AXY1 400V/3~/50Hz NTZ48-4VM Polyester oil JEHBCU-0175-L-3 (175Z) LRLRS0225AXV1 230V/1~/50Hz NTZ68-5VM 11.8 10.8 JEHBCU-0225-L-1 LRLRS0225AXY1 400V/3~/50Hz NTZ68-4VM 11.8...
  • Page 8: Product System Cycle

    Product System Cycle LRMRS0150~ LRMRS0675; LRMSS0200~ LRMSS0680 LRLRS0175~ LRLRS0225; LRLSS0200 & LRLSS0300 T-CU01-APR24-7 Page 4...
  • Page 9: Lrlrs0350~ Lrlrs0400; Lrmss0350~ Lrmss0680

    LRLRS0350~ LRLRS0400; LRMSS0350~ LRMSS0680; LRLSS0400~LRLSS0600 LRMRS0825~ LRMRS1000; LRMSS0800~LRMSS1000 T-CU01-APR24-7 Page 5...
  • Page 10: Lrlrs0725~ Lrlrs0825

    LRLRS0725~ LRLRS0825 LRLSFS0750 T-CU01-APR24-7 Page 6...
  • Page 11: Lrlvfs0951

    LRLVFS0951 Outline Drawings LRMRS0150~ LRMRS0300; LRLRS0175~ LRLRS0225; LRMSS0200~ LRMSS0300; LRLSS0200 & LRLSS0300 T-CU01-APR24-7 Page 7...
  • Page 12: Lrmrs0400~ Lrmrs0675; Lrlrs0350~ Lrlrs0400

    LRMRS0400~ LRMRS0675; LRLRS0350~ LRLRS0400; LRMSS0350~ LRMSS0680; LRLSS0400~ LRLSS0600 LRMRS0825~ LRMRS1000; LRLRS0725~ LRLRS0825 T-CU01-APR24-7 Page 8...
  • Page 13: Lrmss0800~ Lrmss1000

    LRMSS0800~ LRMSS1000 LRLSFS0750~ LRLVFS0951 T-CU01-APR24-7 Page 9...
  • Page 14: Performance Data

    Performance Data R404A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 1033 1438 1914 2459 3073 3758 4513 1040 1137 1237 1339 1444 1550 JEHBCU0150M1 LRMRS0150AXV1 1269 1708 2217 2796 3444 4163 JEHBCU0150M3 LRMRS0150AXY1 1063...
  • Page 15 R404A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 2688 3279 3924 4676 5536 6470 1460 1510 1560 1600 1630 1655 2489 3032 3655 4354 5160 6038 JEHBSCU0200M1 LRMSS0200AXV1 1590 1630 1680 1720 1760...
  • Page 16 R404A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 7149 8708 10535 12578 14835 17339 4560 4660 4770 4890 5030 5177 6611 8116 9836 11718 13921 16286 4940 5050 5150 5300 5400 5534 JEHBSCU0600M3...
  • Page 17 R404A Low Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (w) DRM Codes DMSS Codes 1130 1499 1900 2333 1164 1401 1648 JEHBCU0175L1 LRLRS0175AXV1 1018 1373 1753 2162 1.75 JEHBCU0175L3 LRLRS0175AXY1 1196 1431 1676 1217 1602 2012...
  • Page 18 R404A Low Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (w) DRM code DMSS code 1156 1451 1790 2182 2634 1390 1480 1580 1690 1800 1075 1355 1677 2053 2483 1480 1570 1670 1770 1890 JEHBSCU0200L3 LRLSS0200AXY1 1247 1553 1914...
  • Page 19 R404A Low Temperature (Rating Condition: Superheat 10K, Sub cooling refer table “Amount of Sub-cooling (K)”) MODEL SERIES WATTS (w) DRM code DMSS code 4965 5995 7196 8600 10241 3963 4156 4339 4515 4683 4951 5921 7054 8381 9937 4244 4491 4731 4965 5192...
  • Page 20 R448A/R449A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) -25 DRM Codes DMSS Codes 1369 1843 2378 2974 3634 4357 1052 1157 1263 1363 1455 JEHBCU0150M1 LRMRS0150AXV1 1204 1659 2179 2764 3415 4136 JEHBCU0150M3 LRMRS0150AXY1 1071 1188 1303...
  • Page 21 R448A/R449A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 2294 2882 3641 4271 5131 6068 1549 1579 1570 1679 1739 1794 JEHBSCU0200M1 LRMSS0200AXV1 2105 2657 3345 4008 4815 5715 JEHBSCU0200M3 LRMSS0200AXY1 1738 1748 1757...
  • Page 22 R448A/R449A Low Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 1133 1418 1757 2150 2602 1353 1423 1501 1599 1696 1052 1355 1677 2064 2505 JEHBSCU0200L3 LRLSS0200AXY1 1516 1570 1632 1711 1819 1020 1318 1659...
  • Page 23: Cooling (K)")

    R448A/R449A Low Temperature (Rating Condition: Superheat 10K, Sub cooling refer table “Amount of Sub-cooling (K)”) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 3939 4934 6091 7426 8956 3240 3428 3637 3857 4079 4846 5947 7217 8670 JEHSCU0951CL3 EVI LRLVFS0951BXY1 3736 4005 4286...
  • Page 24: Sub Cooling 0K)

    R134a Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM Codes DMSS Codes 1347 1826 2355 2934 3563 4242 1013 JEHBCU0150M1 LRMRS0150AXV1 1229 1671 2168 2720 3327 3989 JEHBCU0150M3 LRMRS0150AXY1 1011 1075 1091 1481 1931 2441 3011 3641...
  • Page 25: R134 A Medium Temperature (Rating 10K, Sub Cooling 0K)

    R134a Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM codes DMSS codes 1840 2305 2830 3450 4150 4950 5850 1027 1066 1109 1150 1735 2175 2680 3250 3950 4700 5550 LRMSS0200AXV1 1016 1045 1086 1124 1160 1210...
  • Page 26: R134 A Medium Temperature (Rating 10K, Sub Cooling 0K)

    R134a Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL SERIES WATTS (W) DRM codes DMSS codes 5250 6550 8050 9800 11700 13850 16100 2390 2490 2620 2750 2890 3040 3210 4950 6150 7600 9250 11100 13150 15300 2630 2760 2890 3030...
  • Page 27: Wiring Diagram

    Wiring Diagram Important Note: All wiring and connections to the condensing unit must be made in accordance to the local codes. LRLRS0225AXV1, LRMRS0225AXV1, LRMRS0300AXV1 LRLRS0175AXV1, LRMRS0150AXV1 T-CU01-APR24-7 Page 23...
  • Page 28: Lrmss0200Axv1, Lrmss0250Axv1, Lrmss0300Axv1

    LRMSS0200AXV1, LRMSS0250AXV1, LRMSS0300AXV1 LRMSS0350AXV1, LRMSS0400AXV1 T-CU01-APR24-7 Page 24...
  • Page 29: Lrlss0200Axy1, Lrlss0300Axy1, Lrmss0200Axy1

    LRLSS0200AXY1, LRLSS0300AXY1, LRMSS0200AXY1, LRMSS0250AXY1, LRMSS0300AXY1, LRLRS0175AXY1, LRLRS0225AXY1, LRMRS0150AXY1, LRMRS0225AXY1, LRMRS0300AXY1 LRLSS0400AXY1, LRLSS0500AXY1, LRLSS0600AXY1, LRMSS0350AXY1, LRMSS0400AXY1, LRMSS0500AXY1, LRMSS0600AXY1, LRMSS0680AXY1, LRLRS0350AXY1, LRLRS0400AXY1, LRMRS0400AXY1, LRMRS0500AXY1, LRMRS0600AXY1, LRMRS0675AXY1 T-CU01-APR24-7 Page 25...
  • Page 30: Lrmss0800Axy1, Lrmss1000Axy1, Lrlrs0725Axy1

    LRMSS0800AXY1, LRMSS1000AXY1, LRLRS0725AXY1, LRLRS0825AXY1, LRMRS0825AXY1, LRMRS1000AXY1 LRLSFS0750BXY1 3.15A S1PL P< S1PH P> GRN/YLW GRN/YLW NOTE 1 I > I > I > GRN/YLW GRN/YLW E1HC (TOP) GRN/YLW GRN/YLW 380-415V 3N~ 50Hz (BOTTOM) NOTE 1:ONLY FOR NON PUMP DOWN SYSTEM, REMOVE LINK WIRE FROM TERMINALS 5 & 6 TO CONNECT EXTERNAL THERMOSTAT FOR CONTROLLING THE COMPRESSOR ACTIVATION.
  • Page 31: Lrlvfs0951Bxy1

    LRLVFS0951BXY1 3.15A +t° +t° 1 2 3 4 5 6 7 8 9 240Vac 24Vac S1PL P< S1PH P> GRN/YLW I > I > I > GRN/YLW E1HC S1NC GRN/YLW (BOTTOM) (TOP) 380-415V 3N~ 50Hz MODEL B1 SETTING,(A) JEHS/SCU-0951-B4-L-3 EVI 12.0 T-CU01-APR24-7 Page 27...
  • Page 32: Safety And Health

    Safety and Health Important Note Only qualified specialists could carry out the installation, maintenance and commissioning of the system. To avoid potential injury, use care when working around coil surfaces or sharp edges of metal cabinets. All piping and electrical wiring should be installed in accordance with all applicable codes, ordinances and local by-laws.
  • Page 33: Installation & Commissioning

    Installation & Commissioning Unit Site Location • In order to achieve maximum cooling capacity, the installation location for the condensing unit should be carefully selected. • Install the condensing unit in such a way so that hot air ejected by the condensing unit cannot be drawn in again (short circuit of hot discharge air).
  • Page 34: Compressor Handling

    Compressor Handling To ensure compressor reliability, the condensing unit together with the compressor must not tilt greater than an angle of 45°. Otherwise, the internal part of the compressor can offset from the housing springs and produce abnormal sound and vibration. Field Piping Important Note: Pipe sizing should only be determined by qualified personnel.
  • Page 35: Indoor Unit

    • Liquid lines should be sized to ensure a full supply of liquid refrigerant to the expansion device. Careful attention should be paid to sizing of liquid lines on large risers (above 6m). • Piping length less than 25m is highly recommended. An additional oil might be required if piping length exceeds 20m or with many oil traps.
  • Page 36: Pipe Size Selection (For Evi Unit Only )

    Pipe Size Selection (For EVI unit Only) Sizing of liquid and suction lines for EVI model will be different from standard scroll models. Piping sizes of this model need to follow the recommended correction coefficient of cooling capacity. This is vital as if the pipework selected is oversized, especially for the suction pipe, the gas velocity will be decreased at low mass flow rate / low evaporating temperature, causing oil return problems.
  • Page 37: Pressure Testing

    The mains electrical supply to the condensing unit must be via a suitable motor rated circuit breaker or fuse. Daikin condensing units require either a 230 volt / 1 phase / 50Hz supply or a 400 volt / 3 phase / 50Hz supply, both of which must include a Neutral and an Earth.
  • Page 38: Pre Start-Up Checks

    Mains cable type and sizing must be selected for the particular application and the electrical installation should confirm to the current local standards. • Cables to the condensing unit should wherever possible be routed through the cable glands supplied on the rear of the units.
  • Page 39: Dual Pressure Switch

    Vacuum operation: Do not operate scroll compressors in a vacuum condition, as this will cause the scrolls to overheat very quickly causing premature failure. System charge: Ensure an adequate liquid charge has been introduced to the high side of the system before starting to ensure a minimum operating pressure on the suction side of 0.5 bar is maintained, otherwise overheating of the scrolls and subsequent damage may occur.
  • Page 40: Low Pressure Safety (Auto Reset)

    Low pressure safety (Auto reset) The low pressure safety switch protects the compressor against deep vacuum operation, a potential cause of failure due to internal arcing and also operation outside the compressor limits. The low pressure safety cut out should never be set below the settings as shown in the following table. For systems without pump-down the LP switch signal contact shall be used to energize a low pressure safety alarm.
  • Page 41: For Evi Unit Only

    For EVI unit only Controller EXD-HP1 The controller EXD-HP1 used in the Series 4 EVI unit operates as an economizer control. The setting of controller is preset by the factory and is password protected. Users are not allowed to change any settings in the controller. Safety Instructions: 1.
  • Page 42: Wiring

    Digital input Di1/Di2 • The digital input Di1 is the interface between controller EXD-HP1 and system controller if Modbus communication has not been used. • The digital status is dependent to operation of system’s compressor or demand. Operating Condition Digital input status Compressor starts Closed (Start) Compressor stops...
  • Page 43: 10. Checklist

    10. Checklist • Check all electrical termination and circuits. • Check the service valves are fully open. • Check compressor oil level. • Check the pressure switch for right settings. • Ensure fan motor and fan blades are installed properly. •...
  • Page 44: 12. Trouble Shooting

    5. Power Supply – Inspect at regular intervals. • Check the running current and voltage for the condensing unit. • Check the electrical wiring and tighten the wires onto the terminal blocks if necessary 6. Refrigerant Charge • Check the refrigerant charge by ensuring that the system is operating correctly, the pressures are as expected and that the liquid line sight glass shows a full bore of liquid refrigerant.
  • Page 45: 13. Exploded View

    13. Exploded View Series 2 – Reciprocating T-CU01-APR24-7 Page 41...
  • Page 46: Series 2 - Scroll

    Series 2 – Scroll T-CU01-APR24-7 Page 42...
  • Page 47: Series 3 - Reciprocating

    Series 3 – Reciprocating T-CU01-APR24-7 Page 43...
  • Page 48: Series 3 - Scroll

    Series 3 – Scroll T-CU01-APR24-7 Page 44...
  • Page 49: Series 4 - Reciprocating

    Series 4 – Reciprocating T-CU01-APR24-7 Page 45...
  • Page 50: Series 4 Mt - Scroll

    Series 4 MT – Scroll T-CU01-APR24-7 Page 46...
  • Page 51: Series 4 Lt - Scroll

    Series 4 LT - Scroll T-CU01-APR24-7 Page 47...
  • Page 52: Series 4 Lt - Evi

    Series 4 LT - EVI T-CU01-APR24-7 Page 48...
