- Page 1 CODE 3.017182 TELEPHONE Instructions and recommendations CONTROL...
- Page 2 Congratulations for having chosen a top-quality Immergas product, able to assure well-being and safety for a long period of time. As an Immergas Customer, you can also count on a qualified After-sales service, prepared and updated to guarantee constant efficiency of your “GSM telephone control”.
- Page 3 INDEX General warnings..................................4 Cleaning the case..................................4 Warning....................................4 Package contents..................................5 Installation..............................6 Installation operations............................... 6 General description............................ 8 Inserting the SIM CARD ............................9 Signal strength................................10 Electrical connections - Power supply........................10 Connection with CAR .
- Page 4 To clean the “GSM telephone control” cover, use a dry cloth. Never use abrasive or powder detergents. WARNING. Immergas reserves the right to make improvements and changes to details and accessories, excepting the essential features of the model described and illustrated herein.
- Page 5 PACKAGE CONTENTS. Key: 1 - Power supply 5 - Fixing screws on recessed box 2 - GSM telephone control 6 - “GSM telephone control” cover fixing screw 7 - Instruction booklet 3 - Antenna 4 - Expansion anchors...
- Page 6 INSTALLATION. 1.1 Installation operations. 1) Separate the fixing template (Fig. 2 ref. 1) from the front body of the “GSM telephone control” (Fig. 2 ref. 2) by first rotating the upper part of the front body (Fig. 2 ref. a) and then pulling it out slightly towards the bottom (Fig.
- Page 8 GENERAL DESCRIPTION. The “GSM telephone control” is equipped with two Relays which can be controlled by means of SMS texts or phone RINGS (Relay 1). The Relays can be enabled, disabled, or enabled only for set period of time (Pulse function). The “GSM telephone control”...
- Page 9 2.1 Inserting the SIM CARD Warning: when using old SIM CARDS of mobile phone service provider "3", the “GSM telephone control” may not work correctly. Before inserting the SIM CARD in the left side of the “GSM telephone control”: - check your balance on your SIM CARD - make sure that your PIN and any answering service are disabled;...
- Page 10 2.2 Signal strength. This function can be useful to find the correct position of the “GSM telephone control”. The GSM signal strength can be viewed by simultaneously pressing the two buttons CH1 and CH2. In this case, the three LEDs display the GSM signal strength. GREEN LED RED LED CH 2 RED LED CH 1...
- Page 11 - Insert the power supply jack into the jack plug (Fig. 7 ref. 6) located on the side of the “GSM telephone control”. - Insert the power supply socket into the mains plug (100÷240 Vac). The “GSM telephone control” has two relays (Relay 1 (Fig. 7 ref. 7) and Relay 2 (Fig. 7 ref. 5) with voltage-free con- tacts: contact capacity 8 A - 250 Vac/30 Vdc (Fig.
- Page 12 Connection with CAR GSM telephone control Generator...
- Page 13 Connection with CRONO 7. GSM telephone control CRONO 7 Generator Connection to generator. Connect the “C” and “NA” terminals of the “GSM telephone control” to the “TA” connection terminals on the generator (see generator wiring diagram).
- Page 14 CONTROL MANAGEMENT THROUGH SMS. To be read by the “GSM telephone control”, all SMS commands must be preceded by the symbol “:”. SMS messages not preceded by the symbol “:” are disregarded and are deleted from the “GSM telephone control” without sending any reply to the sender number.
- Page 15 3.3 Entering MASTER numbers. MASTER numbers can be entered by anyone who knows the password. 1 to 3 MASTER numbers can be entered. The command to enter them is shown below: :master#0000=+3912345678,+3987654321,+391324846 Where “0000” represents the “GSM telephone control” password, whilst the numbers to the right of the “=” are the MASTER numbers to be saved.
- Page 16 3.5 Deleting USERS. USERS can be deleted only by MASTER numbers. The command used to delete users is : delete=+3912345678,+3987654321,...,+391324846. The numbers to the right of “=” are the USER numbers to be deleted. If the command is accepted, the “GSM telephone control” will return the string user/s deleted. PAY ATTENTION to the following indications: - USER numbers must be entered without spaces and must include the international prefix, where the access code must be entered as “+”...
- Page 17 3.7 Enabling/disabling a load. ENABLING A LOAD The command can be sent by a registered MASTER number or a USER number, and is used to enable one of the 2 relays. To enable Load 1, send the command: :on1 to enable Load 2 send the command: :on2 If the command is accepted and the SMS command notifications have been activated, the “GSM telephone control”...
- Page 18 3.10 Ring function. Relay 1 can also be enabled/disabled by means of a phone RING. By calling the “GSM telephone control” number, Relay 1 will be switched (if it is set to “OFF”, it will be switched to “ON” and vice versa). The “GSM telephone control”...
- Page 19 3.13 Controlling the “GSM telephone control” through a status string. It is possible to control the “GSM telephone control” by modifying the STATUS string (modify Loads status “LOAD 1, LOAD 2” and thermostat temperature “TEMPERATURE ON”). To this avail, the STATUS string received from the "GSM telephone control” must be copied and the Loads parameters and the thermostat temperature must be changed.
- Page 20 3.15 No mains voltage. The “GSM telephone control” can send a SMS message notification to the MASTER numbers if the 12V power supply goes down or is restored. The function can be enabled or disabled. To enable the function, the following command must be sent from a MASTER number: :rete=on The “GSM telephone control”...
- Page 21 GSM COMMANDS SUMMARY. COMMAND EXPLANATION :on1 Load 1 is enabled :on2 Load 2 is enabled :off1 Load 1 is disabled :off2 Load 2 is disabled :im p1= n Load 1 will be enabled for n seconds :im p2= n Load 2 will be enabled for n seconds “GSM telephone control”...
- Page 22 PROBLEMS/SOLUTIONS PROBLEMS SOLUTIONS GREEN LED flashing every 3 seconds - SIM card with PIN to be removed. - SIM card incorrectly inserted. - Make sure that the SIM card has not been disabled from the phone company. - Communication error with GSM module. GREEN LED flashing every 0.5 seconds - The GREEN LED flashing for more than one minute indicates that there is no GSM network in that position.
- Page 24 This instruction booklet is made of ecological paper immergas.com Professionals in the sector can also use the e-mail address to request further specific details: consulenza@immergas.com Immergas S.p.A. 42041 Brescello (RE) - Italy Tel. 0522.689011 Fax 0522.680617...
