- Page 1 Machine Translated by Google User Manual X58 DELUXE SZ HUANAN SANXIAN TECHNOLOGY CO.,LTD. WWW.HUANANZHI.COM...
-
Page 2: Table Of Contents
Machine Translated by Google Safety Information Table of contents The components contained in this package are susceptible to damage by electrostatic discharge (ESD). Please observe the following precautions to ensure successful computer assembly. Safety Information ..............Make sure all components are securely connected. Loose connections may cause the computer to not recognize the components or not turn on. -
Page 3: Packaging
Machine Translated by Google Before connecting the power supply to an electrical outlet, make sure that your outlet Introduction provides the same voltage as indicated on the power supply. Features Place the power cord where it will not be stepped on by others and do not place anything on top of it. -
Page 4: Motherboard Diagram
Machine Translated by Google Motherboard Diagram Rear I/O Panel USB 2.0 Audio Ports 8P CPU power supply interface 4-pin fan connector PS/2 3-pin fan connector DDR3*3 slots USB 2.0 USB 2.0 USB 3.0 PS/2 Mouse USB3.0 USB2.0 Figure 1-2 Overall rear I/O panel display Gigabit LAN 24P motherboard power supply interface Speed light... -
Page 5: Installation And Setup
Machine Translated by Google Installation and Setup Notice PCIEx16 Please check the motherboard carefully. All pins marked with "1" or thick white lines are pin 1. PCIEx1 PCIEx16 Figure 2-4 PCI expansion slot Figure 2-1 Clear CMOS jumper Hard disk indicator light - positive power Power indicator light - positive pole of power supply pole Hard disk indicator light - negative Power indicator light - negative pole of power supply... - Page 6 Machine Translated by Google 1. Use a screwdriver to remove the baffle and screws on the main chassis 2. When installing the graphics card, you need to bend the card slot In order to correctly place the CPU in the motherboard, there are head.
-
Page 7: Driver Installation
Machine Translated by Google 3.1 Install the sound card driver (HD Audio series installation as the first step) Driver Installation Run "Driver": /X58 SUOND CARD DRIVER/VISTA-WIN7- 1. Driver Catalog List: R267,XP Select WDW-267 Driver Catalog Driver Description Applicable operating system Select "Next"... - Page 8 Machine Translated by Google Main 5. Installation of network card driver System Overview (System Information) Run "Driver": X58 LAN DRIVER /WIN7 XP Set the current time, hard disk specifications and display type Click "Next" to continue Advanced Advanced Settings (Advanced BIOS function settings) Select "Install"...
-
Page 9: Safety Precautions
Drivers installation ........... user. If you need any assistance in the process of installationÿplease contact our after-sales customer service or reach us on HUANANZHI official E- BIOS Settings ..............mail:bussiness@huananzhi.com for professional technical support. Prior to installation or disassembly, please switch off the power and pull the power cable from the socket. -
Page 10: Packing
If there is any damage to 1 x PCIe x1 packaging or lack of accessories, contact us as soon as possible. 1 x PCIe 1.1*HUANANZHI X58 DELUXE motherboard 2.1*SATA data cable 3.1*I/O shield back plat 4.1*user manual 5.1* warranty card... -
Page 11: Motherboard Diagram
PCI Interface Audio Input 3Pin Fan Interface JAUDI Audio output/ JUSB2.0 RESET SW HDD LED Front speaker output JUSB3.0 Microphone input POWER SW POWER LED 1-1 X58 DELUXE motherboard illustration 1-4 Audio Port Configuration 05 Motherboard Diagram Rear I/O Panel 06... -
Page 12: Installation And Settings
Machine Translated by Google Installation And Settings ÿ NOTICE PCIEx16 please check the motherboard where all pins marked with number “1” or white bold line are position “1”. PCIEx1 PCIEx16 2-4 PCI Expansion Slot 2-1 Clear CMOS Jumper CLR-CMOS HDD_LED+ PWR_LED+ HDD_LED- PWR_LED-... - Page 13 Machine Translated by Google 1.Use a screwdriver to remove the bezel and screws on the main unit 2.Need to pick up the card slot of the card slot when installing the graphics card In order to properly place the CPU in the motherboard, the surface of 3.Insert the graphics card into the card the LGA1366 CPU has two pairs...
-
Page 14: Drivers Installation
Machine Translated by Google Drivers installation 3.1Audio driver installation (take HD Audio series for example) Run "driver installer": / X58 SOUND CARD DRIVER/VISTA-WIN7-R267, 1.Drivers listing: take WDW-267 if OS is XP Driver Directory Driver Description Operating System Click on "next"to continue,and then"finished" Intel chip win7/win10 X58 Chipset Driver... -
Page 15: Bios Settings
Machine Translated by Google 5.Driver installation of network 1.Main Menu Function Run "driver installer"": X58 LAN DRIVER/WIN7 XP Main Advanced Boot Save Exit Chipset Security click on "next"- Main "installation"- "finished"and restart the computerÿ and restart the computerÿThe system will automatically System Overview Date/Time settings, HDD specs/Monitor type settings.
