Summary of Contents for Cardinal CKART260e
- Page 1 CKART260e Operation Manual UTILITY CART...
-
Page 2: Table Of Contents
3. EQUIPMENT ASSEMBLY 3.1 Warnings 3.2 Assembly Guide 3.3 Cable Assembly Steps 3.4 Loading on the slope 4. OPERATIONS 4.1 Operations 4.2 Charging the Battery 5. MAINTENANCE 5.1 Cleaning 5.2 Storage 5.3 Disposal 6. TROUBLESHOOTING 8. PARTS MANUAL 9. CKART260e EXPLOSION DIAGRAM... - Page 3 CARDINAL Customer Service doesn’t stop at checkout. We understand to keep a job-site running smoothly - the proper equipment, spare parts, instruction manuals, and more are needed at the drop of a hat. Visit www.cardinal-sprayers.com to gain access to the incredible resources below.
-
Page 4: Safety Information
Tomahawk Power. The information contained in this manual is based on equipment’s production at the time of publication. Cardinal® reserves the right to change any portion of this information without notice. No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission from Cardinal. -
Page 5: Operating Safety
1.1.10 DO NOT remove the battery while the machine is running In case of longer standstill, press the shut-down button. 1.1.11 NEVER use accessories or attachments that are not recommended by Cardinal. Damage to equipment and injury to the user may result. -
Page 6: Service Safety
1.2.2 ALWAYS replace worn or damaged components with spare parts designed and recommended by Cardinal. 1.2.3 ALWAYS keep machine clean and labels legible. Replace all missing and hard-to-read labels. Labels provide important operating instructions and warn of dangers and hazards. -
Page 7: Battery
3. Efficient Battery: The wheelbarrow operates on a 40V DC battery with a capacity of 6 Ah, allowing for a maximum work time of 3.2 hours. 4. Speed Control: The CKART260e can achieve a maximum forward speed of 6 km/h and a reverse speed of 2 km/h, enabling efficient maneuverability. -
Page 8: Specifications
5. User-Friendly Operation: The wheelbarrow has a user-friendly design with a speed control lever and intuitive buttons for controlling direction and speed, including forward, reverse, and Eco modes. 2.2 Specifications CKART260e SPECIFICATIONS Rated Voltage 40V DC 6 Ah Battery Capacity Max Battery Work time 3.2 h... -
Page 9: Utility Cart Parts
2.3 Utility Cart Parts 4.Right Rim + Tire 1. Tray 5. Speed Control Lever 2. Battery Box 6. Left Rim + Tire 3. Tube Clamps... -
Page 10: Equipment Assembly
3. EQUIPMENT ASSEMBLY 3.1 Warnings WARNING If any parts are missing or damaged, do not operate this utility cart. Failure to do so may result in personal injury or damage to this machine. WARNING WARNING Never make modifications or fabricate accessories to be used with this machine. - Page 11 FIGURE 4 FIGURE 4. 3.2.5 Insert left and right handles into main frame. Fasten in place using a phillips head screwed driver and the hose clamp. FIGURE 5. 3.2.6 The Cardinal Utility Cart FIGURE 5 assembly is complete.
-
Page 12: Cable Assembly Steps
3.3 Cable Assembly Steps 3.3.1 Connect the plug from the motor control lever to the 10-pole socket on the battery box using the motor cable. FIGURE 6. 3.3.2 Connect the plug from the motor to the 3 and 5 -pole socket on the battery box. FIGURE 7. -
Page 13: Operations
4. OPERATION 4.1.1 To turn on machine press the red power switch to the “|” position. FIGURE 9. 4.1.2 To turn off the machine press the red power switch to “O” position. 4.1.3 Pressing the throttle lever will propel the wagon forward. NOTE: Once the wagon is on, make sure these lights are ON: #L4(green), #L3(green), #L1(green). -
Page 14: Maintenance
5. MAINTENANCE Routine checks of your utility wagon will ensure trouble-free operation. Inspect and/or service your utility cart at the intervals shown below. A daily check takes only minutes, but could save you hours of time and money. Good usage habits and maintenance will extend the life of the machine! DAILY WEEKLY... -
Page 15: Storage
5.2 Storage 5.2.1 Clean the wagon thoroughly before storage. 5.2.2 Store all components separately in a dry area at not less than -10 ° C. Charge the battery fully before storing. Disconnect from the charger. NOTE: When not using the wagon for long periods, ensure to charge the battery after a month of no use. -
Page 17: Parts Manual
CKART260e UTILITY CART... -
Page 18: Ckart260E Explosion Diagram
CKART260e EXPLOSION DIAGRAM... - Page 19 Item Quality Description Tray Front Base Frame Right Rim+Tire Left Rim+Tire Drive Motor Assembly Left Support Feet Battery Box (With Motor Controller) Left Handle Handle Cap Speed Control Lever Right Handle Tube Clamps Right Support Feet Main Frame...
- Page 20 With same day shipping and faster delivery times, count on Cardinal to keep you powered throughout the day! With long lasting parts and engines, Cardinal equipment will be the star of your fleet for years to come. Visit www.cardinal-sprayers.com to get started today!
