Teltonika RUT240 and UWP 3.0
Quick installation guideline
1. Introduction
This guideline describes how to configure the Teltonika RUT240:
1. in Client mode (wireless station mode), which allows you to connect the Teltonika RUT240 to a Wi-Fi
network.
Note: all the devices connected to its LAN ports can be connected to the same network and also to
the Internet.
2. in 4G Mobile mode, which allows to connect the Teltonika RUT240 to a 4G network.
Note: all the devices connected to its LAN ports can be also connected to the Internet.
3. for connecting to a UWP3.0 controller.
2. Web Server access - How to connect
The Teltonika RUT240 has a static network setting coming from factory, that is:
IP address: 192.168.1.1
•
Username: admin
•
• Password: admin01
There two ways to access the web server:
1. Connect a point-to-point Ethernet cable between the computer and the device, using the LAN Ethernet
port, and set the PC network adapter to DHCP.
2. Connect to the wireless network that the router provides as default
Note: the Wi-Fi SSID and password are on the bottom side of the router.
After that, open a browser and type the address 192.168.1.1 to connect to the device web interface.
Note: the system forces the default password change after the first login.
3. How to enable the Client mode
For this setting, you have to be point-to-point connected on the LAN port.
How to define the operation mode
1. From the main bar, select the Network > WAN to open the relevant configuration area.
From the Main WAN column, select
2.
Click Save.
3.
Note: after the change, if you are connected through the Wi-Fi, you could be asked to reconnect.
How to enable the wireless station mode
1. From the main bar, select the Network > Wireless to open the relevant configuration area.
2. Click Add.
3. From the list of all the available Wi-Fi networks, select the one to which the RUT240 must connect
4. Set the proper connection parameters.
Once saved, the router will connect to the network and will get an IP address.
Note: If you go to Status > Overview, you can check the status of the connection from the WAN tile.
Teltonika RUT240 and UWP 3.0 | Quick installation guide | v. 1.0 Jul-22 | Eng | © CARLO GAVAZZI Controls SpA
(Wi-Fi) as interface.

