Summary of Contents for Cybernet CyberMed XB22
-
Page 2: Fcc-B Radio Frequency Interference Statement
CyberMed / iOne XB22 / XB24 / XB24K User Manual FCC-B Radio Frequency Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 3 Safety Instructions Always read the safety instructions carefully. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protect the equipment from overheating. DO NOT COVER THE OPENINGS. Confirm the voltage of the power source and adjust accordingly to 110/220V before connecting the equipment to the power inlet.
-
Page 4: Weee Statement
WEEE Statement (Waste Electrical and Electronic Equipment) The WEEE directive places an obligation on EU-based manufacturers, distributors, retailers and importers to take-back electronics products at the end of their useful life. A sister Directive, ROHS (Restriction of Hazardous Substances) compliments the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. -
Page 5: Table Of Contents
A - Battery behavior of the CyberMed / iOne XB series ..........28 B - Battery Storage and Maintenance ................ 29 C - Cybernet Limited Warranty ................... 30 D - Cybernet’s Recycling Program ................31 E - Getting Help ......................31... -
Page 6: Getting To Know Your Monitor
Ready to use Alternating current Getting to Know Your Monitor This manual refers to both the Medical CyberMed XB22 / XB24 / XB24K models and the Enterprise iOne XB22 / XB24 / XB24K models. Model difference: 1) CyberMed units: Features a white colored unit for medical markets with Antimicrobial and Medical grade certifications. -
Page 7: Cybermed / Ione Xb22 / Xb24 / Xb24K Specifications
CyberMed / iOne XB22 / XB24 / XB24K Specifications XB22: LCD panel 21.5” 1920 x 1080 250nits XB24: LCD panel 23.6” 1920 x 1080 250nits Display XB24K: LCD panel 23.6” 3840 x 2160 300 nits IP65 front panel Durability IPX1 back cover Validated by 3 party lab and is not part of cUL verification Audio... -
Page 8: Power Information
iOne has a black housing XB22: 21.75” x 14.50” x 1.92” (L,W,D) Dimensions XB24/XB24K: 23.50” x 14.80” x 2.10” (L,W,D) XB22 with three batteries: 18.35 lbs XB22 without batteries: 15.35 lbs Weight XB24/XB24K with three batteries: 20.65 lbs XB24/XB24K without batteries: 17.75 lbs FCC Class B / CE EN55032 / EN55024 / EN60601-1 / EN60601-1-2 / EN3014 89 ANSI/AAMI ES60601-1 (2005) + AMD1 (2012) and CAN/CSA-... - Page 9 earth (ground), earth (ground), Class II equipment, caution, operating instructions, "ON' (power) and "OFF" (power) Language Skills: languages as specified in the marketing plan for LCD PC Experience: other: no special experience needed Permissible Impairments: – mild reading vision impairment or vision corrected to log MAR 0.2 (6/10 or 20/32) –...
-
Page 10: Read The Manual
Unpacking After opening the carton, please check carefully to see if there are any damages or missing parts. Read the Manual Please read the important tips and safety notices in the manual before using your monitor. Be sure to keep this manual for future reference. Safety Instructions This product has undergone various tests in order to comply with safety standards. -
Page 11: Electrical And Power Source Related
3. Having two or more people transporting and/or installing the system is recommended. 4. Before suspending the unit, make sure the material used for suspension is sturdy and stable. If not properly suspended, the system may fall and cause serious injury to people standing nearby as well as to the unit itself. -
Page 12: Environmental Factors
Environmental Factors ▪ Operating Temperature: 0°C to 35°C; Non-operating temperature: -20°C to 60°C. ▪ Operating Humidity (Non-Condensing): 10% to 90%. Non-operating Humidity (Non-condensing): 10% to 90%. ▪ Pressure: 700 to 1060hPa (0-3000m) ▪ Do not insert objects into the openings. ▪... - Page 13 2. Do not attempt to repair the monitor on your own. Disassembling the cover exposes users to high voltages and other dangerous conditions. Notify and request a qualified service technician for servicing the unit. 3. To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth.
- Page 14 ISO 7000-0434: Caution, consult ACCOMPANYING DOCUMENTS. ISO 7000-1641: Follow operating instructions or consult instructions for use. IEC 60417 -5009: ready to use. IEC 60417-5031: Direct current. EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal house hold waste and follow the “national”...
-
Page 15: Cybermed & Ione Xb Series Overview
CyberMed & iOne XB series Overview CyberMed & iOne XB22 DOC ID: 16000901 Page | 14... - Page 16 CyberMed & iOne XB24 / XB24K DOC ID: 16000901 Page | 15...
-
Page 17: On Screen Display Buttons
On Screen Display Buttons There are four buttons on the lower bezel as shown above. From right to left: OSD Key Response Time Function LED Behavior Power button used to turn ON and OFF the display. Please Immediately note, the monitor will only turn ON once a video input is The power LED indicates detected. -
Page 18: Side I/O View
Side I/O View Item Description Complies with ISO7816 –1,2,3 T=1 and T=0 protocol. Smart Card Reader Complies with FIPS 140-2. (Optional) Memory card: Synchronous 2-line,3-line and I2C Interface, EMV L1 (Version 2000) DOC ID: 16000901 Page | 17... -
Page 19: On Screen Battery Status Led Icons (Xb Series)
On Screen Battery Status LED Icons (XB Series) There are three battery LED icons on the top bezel to designate the left, middle, and right batteries statuses. Icon Battery Location LED Color Right Battery 1 Green: Battery capacity ≥ 15% Middle Battery 2 Orange: Battery capacity <... -
Page 20: Back View
Back view Item Description Battery Door Battery access door to add/remove batteries. (XB Model) Bracket Hole Reserved for optional external modules: Finger Print module / MSR / NFC VESA mount hole Supports 75 x 75 and 100 x 100 VESA mount using M4 screws*4 (4.0mm x 12.0mm). -
Page 21: Bottom View
19V input with 120/150Watt adapter. WiFi AUX RP SMA WiFi Antenna Extensions. Service For Cybernet use only. 2 x DC Outputs, Supports 5V / 9V / 12V / 15V / 20V / 24V / 48V DC-Out Power devices through the monitor. -
Page 22: Dc Out
There are two DC outputs to allow users to power up devices such as thin clients, scanners, and label printers. The output voltages will be set at Cybernet, based on requirements discussed with your Cybernet representative. Please be careful and follow the labels when plugging in devices to the DC out ports. -
Page 23: Battery Information
Battery Information Each Battery provides a multi-level blue LED indicator, allowing the user to press the LED button for real-time battery capacity levels. LED indicator guide: 1x LED ON – 1~20% charge remaining 2x LED ON – 21~40% charge remaining 3x LED ON –... -
Page 24: Cleaning The Surface Of The Monitor
Below are the approved disinfectants for your monitor. The disinfectants have been validated on both housing and the touch glass. To prevent potential damage to the monitor, please use the disinfectants listed below. Should you have any questions, please contact Cybernet. Cleaner Brand Viraguard®... -
Page 25: Servicing The Batteries
Servicing the Batteries • To install the batteries, first, open the battery door. Then slide the battery into the battery slot with the label facing towards the front. Next, close the battery door. • To remove the batteries, open the battery door. Then grab the battery’s Pull- Mylar to pull the battery out. -
Page 26: Troubleshooting
Troubleshooting Display problems: If the screen is blank, make sure that: When I turn on the - The AC adapter is connected to the monitor and the monitor, nothing appears power cord is plugged into a working electrical outlet. on the screen. - HDMI is plugged in. - Page 27 facing towards the front of the unit. If the battery is still not detected, try charging the battery with the battery charging station. Otherwise, have the battery serviced. DOC ID: 16000901 Page | 26...
-
Page 28: Appendices
Appendices DOC ID: 16000901 Page | 27... -
Page 29: A - Battery Behavior Of The Cybermed / Ione Xb Series
If all doors are open during battery operation, the monitor will shutdown after 60 seconds and power to DC outputs will be terminated. Therefore, Cybernet recommends users to open one battery door at a time during hot swap battery replacement. Please avoid opening all of the battery doors during battery operation. -
Page 30: B - Battery Storage And Maintenance
• The battery typically has a lifespan of 300 cycles under normal usage and operating conditions. After 300 cycles, the battery capacity may lower to 80% of its original capacity. Therefore, Cybernet recommends to replace these batteries for new batteries for a better run time experience. Using the monitor in a higher or lower ambient temperature affects the total number of cycles in the battery's service life. -
Page 31: C - Cybernet Limited Warranty
C - Cybernet Limited Warranty What the warranty covers Cybernet warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, Cybernet will, at its sole option, repair or replace the product with a similar product. -
Page 32: D - Cybernet's Recycling Program
D - Cybernet’s Recycling Program E - Getting Help Corporate Headquarters UK & European Inquiries Cybernet Manufacturing Cybernet Europe 5 Holland #6, Groveland Business Centre Irvine, California 92618 Boundary Way Free: (888) 834-4577 Hemel Hempstead, HP2 7TE Phone: (949) 600-8000...
