BLACKBERRY RADAR H2M IS
ITH100 – 1
April 2024
Chassis
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RADAR H2M IS ITH100-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blackberry RADAR H2M IS ITH100-1

Summary of Contents for Blackberry RADAR H2M IS ITH100-1

  • Page 1 BLACKBERRY RADAR H2M IS ITH100 – 1 April 2024 Chassis Installation Guide...

  • Page 2: Table Of Contents

    1 Overview ......................3 2 Safety and Product Information ............... 4 3 Get ready for installation ................11 4 Installing BlackBerry Radar H2M IS modules ..........12 Prepare to install ....................12 Installation tools ....................15 Matching a module identifier to an asset identifier ..........16 Module installation ....................

  • Page 3: Overview

    Prepare the device for shipping. • Device removal. Complete BlackBerry Radar documentation is available online when you log in to BlackBerry Radar Dashboard. For instructions on how to configure the BlackBerry Radar Dashboard or how to activate newly installed devices, see the online documentation.

  • Page 4: Safety And Product Information

    CHASSIS 2 Safety and Product Information Before you start using the BlackBerry Radar H2M IS™ device (herein after referred to as device), review the safety and regulatory information provided in this document. Keep this document in a safe place so that you can refer to it whenever you need it.
  • Page 5 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS Product information: BlackBerry Radar H2M IS ITH100-1 Intrinsic safety warnings Warning markings WARNING—DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT WARNING—POTENTIAL ELECTROSTATIC CHARGING HAZARD—SEE INSTRUCTIONS WARNING – DO NOT REMOVE OR REPLACE WHILE CIRCUIT IS LIVE UNLESS THE AREA...
  • Page 6 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS Relevant standards Standards IECEx Subject IEC 60079-0:2017 Ed. 7 Part 0: Equipment – General requirements IEC 60079-11:2011 Ed. 6 Part 11: Equipment protection by intrinsic safety ''i'' ATEX EN IEC 60079-0:2018 Part 0: Equipment – General requirements...
  • Page 7 869.85 MHz will be used for CE frequency band and 915 MHz will be used for FCC and ISED frequency band. Operating temperature and humidity The BlackBerry Radar H2M IS device is designed for the following temperature and humidity ranges: Operation: Storage: Temperature: (-40 to 85°C) -40 to 185°F...
  • Page 8 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS recycling channels. Ensure you dispose of your BlackBerry Radar device and its battery in accordance with the laws and regulations in your area. If you have an existing waste management partner, please consult with them regarding disposal, or visit BlackBerry.com/RadarSupport...
  • Page 9 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna.
  • Page 10 (ITE)--Limits and methods of measurement,” ICES-003 of Innovation, Science and Economic Development Canada. EU + UKCA regulatory conformance Hereby, BlackBerry declares that the radio equipment, BlackBerry Radar H2M IS ITH100-1 is in compliance with: Directive 2014/53/EU and UK Radio Equipment Regulations 2017 SI 2017/1206.

  • Page 11: Get Ready For Installation

    BlackBerry Radar Installation App. This app will allow you to record the pairing of each BlackBerry Radar H2M IS module to its asset (that is, the chassis that the device will be installed on) and its associated BlackBerry Radar accessories.

  • Page 12: Installing Blackberry Radar H2M Is Modules

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 4 Installing BlackBerry Radar H2M IS modules You may have a large number of BlackBerry Radar H2M IS modules to install. Follow the instructions in this section to: Match each module identifier to its asset identifier •...
  • Page 13 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS To attach the module to the asset you wish to track, you must supply your own fasteners. Depending on the construction of your mounting location, you may wish to use the following types of fasteners.
  • Page 14 CHASSIS Fastener selection considerations—Thread rolling screws You may also wish to install your BlackBerry Radar H2M IS on your chassis where you may not have simultaneous access to both sides of your device to securely install the fastener without a partner. To support one-person installation, in this scenario, we recommend using thread rolling screws.

  • Page 15: Installation Tools

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 4.2 Installation tools Required tools to complete the installation: Smartphone with BlackBerry Drill and Drill Bits Tape Radar Installation App Pencil or Non-Permanent Marker Nut Driver or Safety Glasses Tape Measure Socket Wrench with Socket* Wrench *Nut Driver + Drill offers fastest installation.

  • Page 16: Matching A Module Identifier To An Asset Identifier

    In order to track an asset, the Radar H2M IS module that is installed on the asset must be associated with the asset in the BlackBerry Radar Dashboard. It is, therefore, very important to keep a clear record of which Radar H2M IS module is installed on which asset.
  • Page 17 BlackBerry Radar H2M IS device and associated accessories. 3. If you are unable to use the BlackBerry Radar Installation App during your installation, you need to obtain a worksheet where you can record the pairing of each BlackBerry Radar H2M IS module to its asset and associated BlackBerry Radar accessories.
  • Page 18 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS Tip: For modules that have previously been transferred to new assets, the temporary S/N label may no longer be in place. If this is the case, you will need to write the module identifier (S/N) for each module on the installation worksheet.

  • Page 19: Module Installation

    NOTE: Installation on the front surface of a trailer or container is not recommended. Vibration from the tractor’s engine or trailer mounted refrigeration, heating and generator units may result in false motion alerts. This diagram illustrates the supported installation orientations for the BlackBerry Radar H2M IS module.

  • Page 20: Chassis Installation Procedure

    CHASSIS 4.4.1 Chassis installation procedure If you are using BlackBerry Radar H2M IS to track a chassis trailer, you may mount the module on any flat, vertical surface that offers enough mounting area for the module. When selecting a mounting location, carefully consider how the asset will be used in its normal, day-to-day operation.
  • Page 21 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS SPECIAL NOTE: To preserve the Intrinsic Safety of the BlackBerry Radar H2M IS module, if the module is dropped at any point during the handling or installation process, please replace with a different module that has not been dropped.
  • Page 22 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS IMPORTANT: When mounting under a vehicle, or a piece of equipment, you must exercise a high degree of caution to avoid serious damage to yourself, the module, or your equipment: Use caution when installing near pneumatic, hydraulic, and electrical •...
  • Page 23 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 4. Remove the template. If there are any burrs around the holes, remove them. Also, remove any dust or debris left over from the drilling or de-burring operations. 5. Place the module on the chassis, aligning the holes on the module with the holes you drilled into the chassis.
  • Page 24 7. Once you have installed the module on the asset, create a record of the module-to- asset-to-accessory pairing within the BlackBerry Radar Installation App by recording the asset identifier and scanning the module identifier for the BlackBerry Radar H2M device and associated accessories with the smartphone.
  • Page 25 If you are unable to use the BlackBerry Radar Installation App during your installation, you need to obtain a worksheet where you can record the pairing of each BlackBerry Radar H2M IS module to its asset and associated BlackBerry Radar accessories.
  • Page 26 Radar H2M modules between locations. For a full explanation of the module reset procedure, please refer to Section 4.4.2: Power Cycling your BlackBerry Radar H2M IS modules. For a full explanation of the module Shipping Procedure, please refer to Section 6.4: Preparing your BlackBerry Radar H2M IS modules for Shipping.

  • Page 27: Resetting Blackberry Radar H2M Is Modules

    CHASSIS 4.4.2 Power Cycling BlackBerry Radar H2M IS modules Use this procedure if you need to “power-cycle” your BlackBerry Radar H2M IS module. IMPORTANT: This procedure only works on modules where the Magnet Power Control feature has been disabled in the Blackberry Radar Dashboard.

  • Page 28: Cleaning Blackberry Radar H2M Is Modules

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 5 Cleaning BlackBerry Radar H2M IS modules WARNING: Exposure to some solvents may degrade the sealing properties of materials used in the device. Avoid exposing your device to these solvents. 1. For best performance, regularly clean the housing on every service interval of your asset.

  • Page 29: Removing Blackberry Radar H2M Is Modules

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 6 Removing BlackBerry Radar H2M IS modules Use this procedure if you need to remove your BlackBerry Radar H2M IS module from your asset. For more information on obtaining service for your devices, or recycling and safe disposal...

  • Page 30: Module Removal

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 6.2 Module removal 1. Remove the module from the asset by removing the two fasteners from the ends of the module and remove the module.

  • Page 31: Battery Removal And Replacement

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 6.3 Battery removal and replacement WARNING: Do not open the device when an explosive atmosphere is present. Do not attempt to replace the battery when an explosive atmosphere is present. Work environment 1.
  • Page 32 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 2. To separate the battery door from the outer housing—begin by inserting a flat screwdriver (3-7mm width) into the far-left or far-right slot, marked with the arrows, and pry upwards. Complete the battery door removal by working your way around the door-- inserting the screwdriver into the other slots and prying upwards, until the door is free.
  • Page 33 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS Battery replacement WARNING: Use only replaceable battery packs Blackberry BAT-63705-003 or BAT-63705-004. 1. Insert the replacement battery into the battery compartment. 2. Connect the battery cable to the battery connector. The LED will blink to indicate the module is active.
  • Page 34 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS IMPORTANT: Ensure the battery door is fully seated onto the housing by firmly pressing the door at the door’s corners and at each arrow embossed into the door. 4. Using a Torx T6 screwdriver, install the screws to secure the battery door.

  • Page 35: Shipment Prep

    CHASSIS 6.4 Shipment prep If you ever need to ship your BlackBerry Radar H2M IS module, there are different procedures to use. Which procedure to use, varies, based on whether you are shipping with a battery installed in the module, or not. The following is a summary of the scenarios we will cover in this Installation Guide.
  • Page 36 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 2. Apply a piece of strong tape to keep the magnet in place during transit. If you plan to do any shipping of your device, you may request a sheet of Magnet Tape from your BlackBerry representative.
  • Page 37 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS Scenario 2: Shipping BlackBerry Radar H2M IS, with the battery installed and disconnected. If you don’t have a power on/off magnet, but need to send the module, along with the battery, follow this procedure.
  • Page 38 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 3. Disconnect the battery cable from the battery connector. 4. Store the battery cable by placing the battery cable under the battery connector retainer. NOTE: Battery cable must be stowed for transit to prevent unintended contact with the battery terminals.
  • Page 39 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS Scenario 3: Shipping BlackBerry Radar H2M IS, without the battery. If you only need to send the device and do not need to send the battery, follow this procedure. IMPORTANT: To transport, or ship your module without the battery, the module must be powered off.
  • Page 40 BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 3. Disconnect the battery cable from the battery connector. 4. Remove the battery from the battery compartment by grasping the pull tab and lifting the battery out of the compartment. 5. Place the battery cover onto the module. Place the screws in the circular recess on the battery door and cover with tape.

  • Page 41: Support

    BLACKBERRY RADAR H2M IS ITH100-1 INSTALLATION GUIDE CHASSIS 7 Support If you run into any problem during the installation process, contact the BlackBerry Radar support team at 1-844-RADAR-BB.

  • Page 42: Legal Notice

    The terms of use of this documentation and any BlackBerry product or service are set out in a separate license or other agreement with BlackBerry applicable thereto. Certain features...
