- Page 1 CHZ 3002 USER MANUAL...
- Page 2 Welcome Founded in 1988, EG Otomotiv San Tic Ltd Sti. was established to manufacture and provide services for HVAC systems and air conditioning service equipment. Since its founded, EG Automotive has become a trusted partner to both domestic and international customers by providing locally designed and manufactured solutions.
- Page 3 Changing Water Flow Direction ..........................8 a.8) Using the Pressure Relief Valve ..........................9 Figure 2.0 ..................................9 a.9) Filter Housing Use ..............................9 CHZ 3002 Usage and Warranty ............................... 10 CHZ 3002 Maintenance Instructions ............................10 Troubleshooting ..................................10...
- Page 4 CHZ 3002 User Manual Figure 1.1 a. High Pressure Manometer b. Low Water Warning Light c. Direction Button d. Heater Warning Light e. Emergency Stop f. Timer g. Digital Temparature Display...
- Page 5 Figure 1.2 h. Power Socket (220VAC) I. Connection Hoses...
- Page 6 7 liters of water is filled, indicating sufficient water. Important: Use only water provided by EG Automotive’s “Heater Core Cleaning Chemical.” Dissolve it in a separate container with 1 liter of warm water and add it through the filter section where water was filled.
- Page 7 Chemical Addition The “Heater Radiator Cleaning Chemical,” supplied and recommended by EG OTOMOTİV, should be dissolved in 1 liter of warm water in a separate container. Once fully dissolved, add it to the water through the filter section where water was previously filled.
- Page 8 a.4) Vehicle Connection Ensure proper hose connections to the vehicle, verifying there are no water leaks from the vehicle’s connection points. Figure 1.7 Figure 1.8...
- Page 9 a.5) Operation After ensuring the water level is sufficient and the red light has gone out, turn on the device by switching on its power. Set the timer to the desired duration and begin the operation. Note: A minimum of 7 liters of water is required in the device. The device is preset to 85˚C, but the temperature can be adjusted on the digital display panel.
- Page 10 a.8) Using the Pressure Relief Valve To prevent potential damage to old radiator cores due to high pressure, utilize the pressure relief valve on the machine. Figure 2.0 a.9) Filter Housing Use To clean the filter housing, first engage the emergency stop switch on the device’s screen. After cleaning, place the filter housing while the device is off.
-
Page 11: Troubleshooting
The device will not operate if the water level is insufficient, protecting itself from potential damage due to dry operation. Our devices are covered by a 2-year warranty. During this time, we strongly recommend using EG Automotive’s heater core cleaning chemical, as it is organic-based and safe for both the device and the vehicle’s components. Damage caused by using different acid-based chemicals may void the warranty.
