- Page 1 CHZ 3002M USER MANUAL...
-
Page 2: Welcome To Eg Automotive
Welcome to EG Automotive, EG Otomotiv San. Trade Ltd. Şti., was established in 1988 to produce and provide service for HVAC systems and air conditioning service equipment. Since its establishment, it has been a solution partner to many customers at home and abroad with its domestic design and production solutions. -
Page 3: Table Of Contents
CHZ 3002 USER MANUAL ................................0 Welcome to EG Automotive, ............................... 1 CHZ 3002M Instructions for Use ..............................3 Figure 1.1 ..................................3 Figure 1.2 ..................................4 a) Use of 3002M Device................................5 a.1) Electrical Connection of Device 3002M ........................5 Figure 1.3 .................................. -
Page 4: Chz 3002M Instructions For Use
CHZ 3002M Instructions for Use Figure 1.1 a. High Pressure Manometer b. Missing Water Warning Light c. Directional Button d. Heater Warning Light e. Emergency Stop Time Counter g. Digital Temperature Regulation Display... - Page 5 Figure 1.2 h. Connection Cable (220V) I. Connection Hoses J. Pressure Reducing Valve k. Flow Direction Control Lever...
-
Page 6: A) Use Of 3002M Device
a) Use of 3002M Device a.1) Electrical Connection of Device 3002M Make sure that the electrical source to which the device will be connected provides the appropriate and sufficient electrical level: 220-240 VAC, 50/60 Hz. If the device is used with an extension cable, the portable extension cable must be a maximum length of 10 meters and of standard 3x2.5 mm². -
Page 7: A.3) Addition Of Chemicals
Addition of Chemicals The "Radiator Cleaning Chemical" supplied and recommended by EG Automotive should be dissolved in 1 liter of warm water in a separate container and added to the water from the filter part where you fill the water. -
Page 8: A.4) Vehicle Connection
a.4) Vehicle Connection Connect the appliance to the vehicle and make sure that the hoses do not leak water from the vehicle connection points. Figure 1.7 Figure 1.8... -
Page 9: A.5) Operating The Device
a.5) Operating the Device After the water has reached a sufficient level and the red lamp has gone out, turn on the switch of the appliance and turn on the electricity. Start the process by setting the clock on the device, which determines the working time, to the time you deem appropriate. -
Page 10: A.7) Changing The Water Flow Direction
a.7) Changing the Water Flow Direction The 3002m model automatically changes the direction of water flow every 5 minutes without any intervention. If the user wishes, he can change the direction of the flow of water by pressing the "Motor" button on the machine to act on the side with more blockages and determine it himself. -
Page 11: A.9) Use Of The Filter Chamber
Figure 2.1 a.9) Use of the Filter Chamber In order to clean the filter chamber located next to the heater cleaning device, you must first turn off the emergency stop switch on the screen of the device. After cleaning the filter chamber, it is important to put it back in place with the appliance turned off. -
Page 12: Chz 3002M Use And Warranty
Our devices are covered by a 2-year warranty. During this period, it is strongly recommended to use the "Radiator Cleaning Chemical" offered to users by EG Automotive. The chemical in question is organic-based and will not harm both the parts of the device and the parts of the vehicle being cleaned. -
Page 13: Warranty Card
WARRANTY CARD Manufacturer's: Vendor's: Title: Address: EG Otomotiv San Tic. Ltd. Şti Phone: Kyrenia District Irmaklar Sok. Küçükyalı Business Fax: Center Email: B Blok No 10 Maltepe Istanbul TURKEY Invoice Date and Number: +90 216 473 90 56 Delivery Date and Place: info@egmakina.com...
