Avintage AVI97X3ZI/2 Instructions For Use Manual

Triple-compartment service cellar that can be integrated in a column
Hide thumbs

Advertisement

Table of Contents

Triple-compartment service cellar that can be integrated in a column
INSTRUCTION FOR USE – AVI97X3ZI
FR – MANUEL D'UTILISATION
D – GEBRAUCHSANWEISUNG
SP – MANUAL DE UTILIZACION
CZ – NÁVOD K OBSLUZE
p. 2
GB – USE INSTRUCTIONS
p. 49
NL – HANDLEIDING
p. 97
IT – MANUAL
p. 145
SK – NÁVOD NA OBSLUHU
p. 26
p. 73
p. 121
p. 169
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVI97X3ZI/2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avintage AVI97X3ZI/2

Summary of Contents for Avintage AVI97X3ZI/2

  • Page 1 Triple-compartment service cellar that can be integrated in a column INSTRUCTION FOR USE – AVI97X3ZI FR – MANUEL D’UTILISATION p. 2 GB – USE INSTRUCTIONS p. 26 D – GEBRAUCHSANWEISUNG p. 49 NL – HANDLEIDING p. 73 SP – MANUAL DE UTILIZACION p.

  • Page 2: General Safety Instructions

    Before use, please read and follow the safety rules and operating instructions in this manual. Firstly, we would like to thank you for purchasing an AVINTAGE product and hope that this appliance fully lives up to your expectations. This appliance enables you to bring your bottles at room temperature or bring them to service temperature (depending on the bottles) thanks to its wide adjustment range.
  • Page 3 products. Under no circumstances is it intended to keep food products fresh. Make sure that your electrical installation’s voltage corresponds to that on the appliance’s nameplate; the appliance must be connected to an approved, earthed system. Incorrect repairs or connections can cause safety hazards. Have your electrical installation checked by a professional, if you are in any doubt.
  • Page 4 mains plug immediately. To prevent any risk of fire, electrocution or injury, do not immerse the mains cable, plug or the appliance itself in water or any other liquid. Do not handle the appliance with wet hands. Keep the appliance away from any source of heat and out of direct sunlight.
  • Page 5 supervised. Keep all packaging away from children as there is risk of suffocation. • Risk of child entrapment. Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still dangerous, even if they will “just sit in the garage a few days”.
  • Page 6 WARNING — To avoid a hazard due to instability of the appliance, it must be fixed in accordance with the instructions. WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance, as they could leak or release fluids.
  • Page 7 Refrigerating fluid The refrigerating circuit in the appliance uses refrigerating isobutene (R600a), which is a highly inflammable natural gas and is therefore dangerous for the environment. When transporting or installing the appliance, ensure that no element of the refrigerating circuit is damaged. The refrigerating fluid (R600a) is inflammable. Caution: risk of fire If the refrigerant circuit should be damaged: ...
  • Page 8 You must not operate the appliance without the interior lighting lamp cover. Disconnect the appliance before replacing the lighting bulb. The cellar is only applied with power supply of single phase alternating current of 220~240V/50Hz. Do not attempt to replace a damaged power cable, contact your after-sales service.
  • Page 9 are only designed to facilitate minor movements. Do not move the appliance over long distances. Never use the base, drawers, doors etc. to stand on or as supports. To avoid items falling and causing injury or damage to the appliance, do not overload the door racks or put food in the crisper drawers.
  • Page 10 service center. ensure proper electrical connection, follow recommendations given in the present manual. Unpack the appliance and visually check that it is not damaged. Do not connect a damaged appliance. Inform your retailer or point of sale of any damage. In such a case, keep the packaging.
  • Page 11 still closing properly. If this is not the case, contact your after- sales service. Trouble shooting Any electrical work should be carried out by a qualified and skilled technician. • The appliance should be repaired by an accredited repair centre, using only manufacturer’s original spare parts. The appliance is designed for home use only.

  • Page 12: Technical Data

    manufacturer. This appliance meets the requirements of all applicable European directives and their amendments, and notably complies with the following standards: 2011/65/EU (ROHS) 2014/35/EU on electrical safety 2014/30/EU on electromagnetic compatibility 643/2009/CE relating to energy labels 2. TECHNICAL DATA Below is an example of the nameplate: The nameplate attached to the inside or rear of the appliance (depending on the model) includes the entire information specific to your appliance.
  • Page 13 This will reduce the possibility of a malfunction in the cooling system from handling during transportation. Clean the interior surface with lukewarm water using a soft cloth. When disposing your appliance, please choose an authorized disposal site. Place your wine cooler on a floor that is strong enough to support it when it is fully loaded. To level your Wine cooler, adjust the front leveling leg at the bottom of the wine cooler.
  • Page 14 Warning: to ensure proper operation, the ventilation grilles must never be obstructed or covered. 1. After installed wine cellar into cooler, please adjust limited block (a) close to the kitchen cabinet (b). 2. Please fix the 3 pcs screws through the limited block (a) screw hold into the kitchen cabinet (b), please find below picture for reference.
  • Page 15 Reversing the door The door can be changed from left and right side. No special requirement, all the door is opened from left side. If require to open from right side please refer to the following direction: 1. Incline the wine cooler with 45 degrees, take out right lower hinge’s screws with screwdriver (Fig.1). 2.
  • Page 16 4. OPERATING INSTRUCTIONS It is recommended that you installed your appliance in a place where the ambient temperature is between 16-32°C (N class marked on the rating plate). If the ambient temperature is above or below recommended temperatures, the performance of the unit may be affected and it may not be possible to obtain temperature between 5-20°C/5-10°C/10-20°C.
  • Page 17 value that can be established, it will jump to the highest adjustable temperature value automatically. After stopping pressing the button for 5 seconds, LED figure will stop flash, then exit setting model. Upper compartment: the temperature setting can be adjusted from 5°C to 20°C. Middle compartment: the temperature setting can be adjusted from 5°C to 10°C.
  • Page 18 Ensure that the tray always contains water. Designed by specialists for oenophiles, Avintage brand has taken into account the sensitivity of corks to too low a level of ambient humidity. This is why the tray should be placed on the shelf below the fan situated in the bottom, to provide minimum humidity.
  • Page 19 The winter system The winter kit is a frost protection system which enables the cellar to operate in an environment where the temperature is between 0 and 32°C. A sensor located inside the appliance triggers a low power electrical element when the inner temperature of the wine cellar becomes inferior by 3°C than the set temperature. This is a low power element to avoid sudden rises in the temperature of the wine and so avoid thermal shocks that are damaging to the preservation of the wine.

  • Page 20: Care And Maintenance

    Examples of serving temperatures Opinions vary, and the ambient temperature too, but many people agree on the following: Prestigious Bordeaux wines – Reds 16 – 17°C Prestigious Burgundy wines – Reds 15 – 16°C Prestigious dry white vintages 14 – 16°C Light, young, fruity reds 11 –...

  • Page 21: In The Event Of A Breakdown

    Energy saving tips • The wine cooler should be located in the coolest area of the room (but at least at 16°C), away from heat producing appliances, and out of the direct sunlight. Ensure that the unit is adequately ventilated. Never cover air vents. Only open the door for as long as necessary.

  • Page 22: Troubleshooting

    9. TROUBLE SHOOTING You can solve many common Wine cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE •...
  • Page 23 As we continuously improve our products for the benefit of our customers, we reserve the right to modify technical characteristics without notice. Warranties for AVINTAGE brand products are offered exclusively by selected retailers. No part of these instructions may be considered as a supplementary guarantee.
  • Page 24 EUROPEAN DATA SHEET according to the regulations (UE) N°1060/2010 SERVICE WINE CABINET BRAND AVINTAGE COMMERCIAL REFERENCE AVI97X3ZI POWER SUPPLY 220-240 V / 50 Hz PRODUCT DIMENSIONS (W x D x H) 595 x 540 x 1788 mm NET WEIGHT 106 kg...
