Avintage AVI24PREMIUM Instructions For Use Manual

Integrated service cellar in column
Hide thumbs Also See for AVI24PREMIUM:

Advertisement

Quick Links

Download this manual
Integrated service cellar in column
Instruction for Use – AVI24PREMIUM
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVI24PREMIUM and is the answer not in the manual?

Questions and answers

Related Manuals for Avintage AVI24PREMIUM

Summary of Contents for Avintage AVI24PREMIUM

  • Page 1 Integrated service cellar in column Instruction for Use – AVI24PREMIUM...
  • Page 2 Before use, please read and follow the safety rules and operating instructions in this manual. Firstly, we would like to thank you for purchasing an AVINTAGE product and hope that this appliance fully lives up to your expectations. This appliance enables you to bring your bottles at room temperature or bring them to service temperature (depending on the bottles) thanks to its wide adjustment range.
  • Page 3 temperature higher than that of a storage compartment for fresh products. Under no circumstances is it intended to keep food products fresh. Make sure that your electrical installation's voltage corresponds to that on the appliance’s nameplate; the appliance must be connected to an approved, earthed system.
  • Page 4 etc.) on electrical components (motor, etc.), disconnect the mains plug immediately. To prevent any risk of fire, electrocution or injury, do not immerse the mains cable, plug or the appliance itself in water or any other liquid. Do not handle the appliance with wet hands. Keep the appliance away from any source of heat and out of direct sunlight.
  • Page 5 out by children, unless they are more than 8 years old and are supervised. Keep all packaging away from children as there is risk of suffocation. • Risk of child entrapment. Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still dangerous, even if they will “just sit in the garage a few days”.
  • Page 6  Bed and breakfast type environments,  Catering and similar non-retail applications. WARNING — To avoid a hazard due to instability of the appliance, it must be fixed in accordance with the instructions. WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance, as they could leak or release fluids.
  • Page 7 flammable and explosive articles should not be put in or near the cabinet, to avoid the fire or explode caused. Refrigerating fluid The refrigerating circuit in the appliance uses refrigerating isobutene (R600a), which is a highly inflammable natural gas and is therefore dangerous for the environment. When transporting or installing the appliance, ensure that no element of the refrigerating circuit is damaged.
  • Page 8 Ensure that the appliance is always electrically earthed. If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire. You must not operate the appliance without the interior lighting lamp cover. Disconnect the appliance before replacing the lighting bulb.
  • Page 9 appliance on fire. The appliance is intended for keeping beverages in normal household as explained in this instruction booklet. The appliance is heavy. Care should be taken when moving it. If your appliance is equipped with castors, remember that these are only designed to facilitate minor movements. Do not move the appliance over long distances.
  • Page 10 Plug the wine cooler into an exclusive, properly installed- grounded wall outlet. Do not under any circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized products service center.
  • Page 11  Leave the doors open as little time as possible.  To ensure that the appliance operates properly, clean the condenser regularly (see “Maintenance”).  Regularly inspect the door seals and ensure that they are still closing properly. If this is not the case, contact your after- sales service.
  • Page 12 be closed by the refrigerating fluid in the event of a leak). The refrigerating fluid type is specified on the power cabinet identification plate. Caution — Do not use electrical equipment in the compartments of the appliance, unless they are of the type recommended by the manufacturer.
  • Page 13 8) Door supporter 9) Feet 3. TECHNICAL DATA Below is an example of the nameplate: The nameplate attached to the inside or rear of the appliance (depending on the model) includes the entire information specific to your appliance. We recommend that you make a note of its serial number in this booklet prior to installation, so that you can refer to it later (technical work, request for assistance, etc.).
  • Page 14 Adequate ventilation is required, do not block the front air outlet. Not designed for placement in adage or basement. The appliance is for indoor use only. This device is designed to be incorporated into fitted kitchen units. Connect the cellar to a single socket and be careful to support it, so that your wine cellar is perfectly level (use of a spirit level is recommended).
  • Page 15 Built-in installation drawing The wine cooler door seals the installed unit almost completely. CAUTION: for all of these models, please take into consideration the clearances required for air intake and exhaust. Hot air must be driven by the ventilation to the rear wall of the cellar and then expelled upwards. The ventilation channels shall be at least 200 square centimeters in cross-section.
  • Page 16 Installation of your wine cellar  Step A  Step B  Step C 1) Kitchen cabinet 2) Door part 3) Body part 4) Upper part of the wine cellar 5) Bottom part of the wine cellar...
  • Page 17 A. Install your wine cellar into the kitchen cabinet, having first checked that the dimensions correspond exactly to those indicated on the installation drawing. B. Once your wine cellar properly positioned into the kitchen cabinet, please adjust it as close as possible to the edges of the kitchen cabinet.
  • Page 19 Door replacement 1) Remove the three screws marked No.1 2) Remove the screw cover No.2 and the screw No.3 3) Remove screw No. 4 4) Remove the door and carefully place it away from the cellar 5) Carefully install door positioning it in the appropriate place 6) Re-install the screw No.3 and the cover 7) Re-install the screw No.4...
  • Page 20 5. OPERATING INSTRUCTIONS It is recommended that you installed your appliance in a place where the ambient temperature is between 10-32°C. If the ambient temperature is above or below recommended temperatures, the performance of the unit may be affected and it may not be possible to obtain temperature between 5- 18°C.
  • Page 21 The anti-vibration system The refrigeration compressor is equipped with special dampers (silent-blocks) and the inner space is insulated from the body by a thick layer of polyurethane foam. These characteristics prevent the transmission of vibration to your wines. The anti-UV system Light accelerates the ageing of wine.
  • Page 22 In reality and in extreme cases, you could store more bottles by stacking the same type of bottle without using shelves, but a varied cellar comprises a wide variety of bottles and the practical aspect of everyday cellar management limits its capacity. You will therefore probably load the appliance a little less than the recommended maximum.
  • Page 23 8. CARE AND MAINTENANCE Before cleaning your appliance (something that should be done regularly), disconnect it by removing the plug or by pulling the fuse on the circuit. Before using your appliance for the first time and regularly after that, we recommend that you clean the inside and outside (front, side and top) with warm mixed with a gentle cleaning product.
  • Page 24 9. IN THE EVENT OF A BREAKDOWN Despite the care we take during production, a breakdown can never be totally ruled out. Before contacting your retailer’s after-sales department, please check that: The appliance is properly plugged in There is not a power cut in progress The breakdown is not one of those described in the table at the end of this manual IMPORTANT: if the power cable supplied is damaged, it must be replaced by the manufacturer, a service centre approved by the brand or the retailer.
  • Page 25 10. TROUBLE SHOOTING You can solve many common Wine cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE •...
  • Page 26 As we continuously improve our products for the benefit of our customers, we reserve the right to modify technical characteristics without notice. Warranties for AVINTAGE brand products are offered exclusively by selected retailers. No part of these instructions may be considered as a supplementary guarantee.
  • Page 27 EUROPEAN DATA SHEET according to the regulations (UE) N°1060/2010 SERVICE WINE CABINET BRAND AVINTAGE COMMERCIAL REFERENCE AVI24PREMIUM POWER SUPPLY 220-240 V / 50 Hz PRODUCT DIMENSIONS (W x D x H) 592 x 551 x 459 mm NET WEIGHT 28 kg...
