  • Page 1 EN User Manual | Washer Dryer EW7W368SI...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. TECHNICAL DATA..................8 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Do not change the specification of this appliance. • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.

  • Page 5: Safety Instructions

    • Items that have been soiled with substances such as vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer. •...

  • Page 6: Electrical Connection

    • Do not install or use the appliance where has been carried out or new devices fitted the temperature can be less than 0°C or (water meters, etc.), let the water flow until where it is exposed to the weather. it is clean and clear.

  • Page 7: Product Description

    • Do not use a detergent ball if setting a • Please note that some of these spare non-stop programme. parts are only available to professional repairers, and that not all spare parts are 2.5 Service relevant for all models. •...

  • Page 8: Technical Data

    Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at electro‐...

  • Page 9: Installation

    5. INSTALLATION 5.2 The appliance is equipped WARNING! with ... Refer to Safety chapters. 5.1 Be prepared for installation It is recommended that installation is carried out by two persons. 5.3 Unpacking WARNING! Use the gloves. WARNING! Remove all the packaging and the transit bolts before installing the appliance. 1.
  • Page 10 3. Remove the protection from the bottom. 4. Return the appliance in vertical position and remove the socket protection. 5. Remove the power supply cable and the drain hose from the hose holders. It is possible to see water flowing from the drain hose.

  • Page 11: Positioning And Levelling

    7. Close the holes with the plastic caps you find in the user manual bag. Put the smallest cap F in upper hole and the two bigger caps G in lower holes. We recommend that you keep the packaging and the transit bolts for any movement of the appliance.
  • Page 12 5.5 Hose and cable connection 1100 mm 1450 mm 1210 mm 940 mm 1360 mm 900 mm The inlet hose 1. Remove the inlet hose from inside the drum. 2. To connect the water inlet hose towards the proper direction and with the proper inclination, check the position of the water tap before connecting it to the back of the appliance.

  • Page 13: Water Drainage

    5. Connect the water inlet hose to the cold water tap with 3/4 thread. WARNING! The inlet water shall not exceed 25 °C. WARNING! Make sure that there are no leaks from the couplings. Use the hose supplied with appliance. Do not use an extension hose if the inlet hose is too short.
  • Page 14 To a wall-pipe Directly to a built-in drain pipe in the room wall and tighten it with the supplied cable tie L. You can extend the drain hose to maximum 400 cm. Contact the service centre for the other drain hose and the extension. 5.6 Building in This appliance has been designed to be built into the kitchen furniture.
  • Page 15 The appliance is also equipped with an adhesive sponge pad H that you can find inside the drum. Attach it on the top of the appliance where indicated in the drawing. When levelling the appliance under the furniture, DO NOT squeeze the sponge pad. Before proceeding with appliance building in, bring it near the recess and preposition the inlet hose, the drain hose and the mains cable.
  • Page 16 Reversibility of the cupboard door Carry out the cupboard door reversibility before the appliance is built in completely. If the cupboard door has to be opened from left to right, invert the position of the hinge supports M with the magnetic plate N and lower plate O. Make sure that the plate with magnet is on the upper position.
  • Page 17 Set the position of the lower hole respecting dimensions and distances shown in the drawing 16-22 mm (449 mm). Countersink the holes. Ø 35 mm 12,5 - 14 mm 22±1,5 mm 595-598 mm Hinges To mount the hinges it is necessary to drill two holes (dia.
  • Page 18 Counter-magnet The appliance is pre set for a magnetic closure. For a correct closure: 1. Position the screw C and the counter-magnet D on the magnetic plate N. Lean the cupboard door against the screw until it leaves a mark. 2.

  • Page 19: Control Panel

    6. CONTROL PANEL 6.1 Control panel description Dry Mode touch button permanent Anti-crease option The permanent options are set by holding pressed the relative button for at Time Manager touch button least 3 seconds. permanent Child Lock option Programme dial Stains touch button and permanent Spin touch button...
  • Page 20 6.2 Display The Temperature area: Temperature indicator . Cold water indicator. Door locked indicator. Child safety lock indicator. The digital indicator can show: • Programme duration (e. g. , washing and/or drying phase). • Delay time (e. g. • Cycle end ( •...

  • Page 21: Dial And Buttons

    Drum clean indicator. This is a recommendation to perform the drum cleaning. Re‐ fer to paragraph "Cleaning the drum" in "Care and cleaning" chapter. Anti-crease phase indicator. Read the 'Permanent Anti-crease' paragraph for more details. Drying phase indicator. The spin area: Spin speed indicator No Spin indicator.

  • Page 22: Permanent Extra Rinse

    The final spin is not performed. The water When it is activated, the appliance will default of the last rinse is not drained out to to this option after you switch it off or change/ prevent the fabrics from creasing. The reset the programme.

  • Page 23: Child Lock

    When you set a washing programme, the 7.10 Child Lock display shows the default duration and With this option you can prevent children from dashes. playing with the control panel. Touch Time Manager button to reduce the To activate/deactivate this option, hold the programme duration according to your needs.

  • Page 24: Delay Start

    • Press the On/Off button for a few seconds you have to dry (refer to "Timed drying" to activate or the deactivate the appliance. table). The display shows the set value. • Turning the programme dial in another Each time you touch this button the time position.

  • Page 25: Programmes

    8. PROGRAMMES 8.1 Programme Chart Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1600 rpm 8.0 kg 1600 rpm - Eco 40-60 (Wash 400 rpm only mode) 40 °C White cotton and fast-coloured cotton.
  • Page 26 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Steam programme Steam programme can be used for reducing wrinkles and odours of garments that just need to be refreshed, avoiding washing.
  • Page 27 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1600 rpm 5.0 kg Programme to treat mixed fabrics (cotton and synthetic (1600 - 400 items) up to 5 kg. Complete washing programme that washes MixLoad 69min rpm) the daily soiled laundry efficiently at 30 °C and ensures a...
  • Page 28 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Reset position. The display shows dashes only. According to Commission Regulation EU 2019/2023. This programme at default temperature and spin speed, in washing only mode, with rated capacity 8.0 kg is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 29 Programme ■ ■ ■ ■ ■ ■ ■ ■ ■ Hygiene ■ ■ Steam ■ ■ ■ Spin/Drain ■ ■ ■ ■ ■ ■ Rinse ■ ■ ■ Machine Clean ■ ■ ■ ■ ■ ■ ■ MixLoad ■ ■ ■...
  • Page 30 ▲ ▲ ▲ Synthetics ▲ ▲ Delicates ▲ ▲ ▲ Hygiene ▲ ▲ MixLoad ▲ ▲ ▲ Sportswear ▲ ▲ Outdoor ▲ ▲ Wool ▲ ▲ Quick 20’ Wash&Dry 60’ At temperature higher than 60 °C the use of powder detergent is recommended. ▲...

  • Page 31: Automatic Drying

    8.3 Automatic drying Initial cycle times for programmes with Auto Dry option are only estimates, the actual drying time may slightly differ from the time displayed. Dryness Level Type of fabric Load Cottons and Linen up to 4.0 kg (bathrobes, bath towels, etc) Extra Dry For towelling materials Denim garments...

  • Page 32: Settings

    Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) Denim garments 1200 165 - 175 1200 75 - 85 Cupboard Dry Cottons and Linen 1600 160 - 180 For items to be stor‐ (bathrobes, bath towels, etc) 1600 100 - 110 1600...

  • Page 33: Before First Use

    and the buttons simultaneously for about 2 seconds. The display shows On or If you deactivate the acoustic signals, Off. they continue to operate when the appliance has a malfunction. 10. BEFORE FIRST USE 1. Make sure that the electrical power is 4.

  • Page 34: Filling The Detergent And Additives

    11.3 Filling the detergent and additives 2. Press the lever down to remove the dispenser. 3. To use powder detergent, turn the flap - Compartment for prewash phase, soak pro‐ 4. To use liquid detergent, turn the flap gramme or stain remover. down.

  • Page 35: Setting A Programme

    Make sure that the flap does not cause a 2. Touch the Start / Pause button. The blockage when you close the drawer. appliance door locks and starts the countdown of the delay start. The display 11.5 Setting a programme shows the indicator 1.

  • Page 36: Cancelling A Running Programme

    placed below the time digits play a simple 2. Change the options. The given animation. The drum rotates shortly. information in the display changes 2. The programme duration could be accordingly. adjusted accordingly and could increase 3. Touch the Start / Pause button again.

  • Page 37: End Of The Programme

    2. Open the appliance door. If necessary, • You must drain the water to open the add or remove the items. Close the door door: and touch the Start / Pause button. 1. If necessary, touch the Spin button to The programme or the delay start continues.

  • Page 38: Daily Use - Washing & Drying

    12. DAILY USE - WASHING & DRYING dryness level. The indicators in the WARNING! display illuminate accordingly: Refer to Safety chapters. Iron dry: for cotton items; Cupboard dry: for cotton and synthetic items; This appliance is an automatic washer Extra dry: for cotton items. dryer.

  • Page 39: Daily Use - Drying Only

    • The acoustic signals operate (if they are • Press the On/Off button for some seconds active). to deactivate the appliance. • In the display comes on. • The indicator of the Start / Pause button After some minutes from the end of goes off.

  • Page 40: Fluff In The Fabrics

    13.3 Timed Drying The appliance continues to operate with the anti-crease phase for approximately 1. Tap on the Time Dry button 30 minutes or more if Anti-crease option repeatedly to set the desired time value was set. (see the "Timed drying" table in the The anti-crease phase reduces creasing.

  • Page 41: Hints And Tips

    15. HINTS AND TIPS WARNING! Refer to Safety chapters. 15.1 The laundry load • Divide the laundry into: white, coloured, synthetics, delicates and wool. • Follow the washing instructions on the laundry care labels. • Empty pockets and unfold the items. •...

  • Page 42: Ecological Hints

    • Use only detergents and other treatments • Loading the appliance to the maximum specially made for washing machines. capacity indicated for each First, follow these generic rules: programmes helps to reduce energy – powder detergents (also tablets and and water consumption. single-dose detergents) for all types of •...

  • Page 43: Drying Cycle Duration

    • Fabrics with residue of hair sprays, nail WARNING! solvents or similar. • Garments with foam-rubber or materials To avoid creasing and shrinkage do similar to foam-rubber. not overdry the laundry. 15.8 Garment labels 15.11 General Tips When you dry the laundry, obey the Refer to the «Drying programmes»...

  • Page 44: Removing Foreign Objects

    16.2 Removing foreign objects 16.5 Maintenance wash The repeated and prolonged use of low temperature programmes can cause detergent deposits, fluff residues, bacterial Make sure that pockets are empty and all growth inside the drum and the tub. This loose elements are tied up before could generate bad odours and mildew.

  • Page 45: Cleaning The Drum

    16.7 Cleaning the drum Regularly examine the drum to prevent unwanted deposits. Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron Clean the drum with special products for stainless steel. Always follow the instructions that you 2.

  • Page 46: Cleaning The Drain Pump Filter

    Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: • The appliance does not drain the water. • The drum does not turn. • The appliance makes an unusual noise because of the blockage of the drain pump.
  • Page 47 180˚ 3. Turn the filter 180 degrees in anti-clockwise direction to open it, without removing. Let the water flow out. 4. When the bowl is full of water, turn the filter back and empty the container. 5. Repeat the steps 3 and 4 until the water stops to flow out.

  • Page 48: Cleaning The Inlet Hose And The Valve Filter

    8. Clean the filter under the water tap. 9. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages. 10. Close the pump cover. When you drain the water with the emergency drain procedure, you must activate the drain system again: 1.

  • Page 49: Emergency Drain

    45° 20° 16.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, carry 2. Close the water tap. out the same procedure, described in 3. Put the two ends of the inlet hose in a 'Cleaning the drain pump' paragraph.
  • Page 50 17.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Start / Pause button may flash continuously: If the appliance is overloaded, remove some items from the drum...
  • Page 51 • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. Internal fail. No communica‐ • If the alarm code appears again, contact the Authorised Service Centre. tion between electronic ele‐ ments of the appliance.

  • Page 52: Emergency Door Opening

    Problem Possible solution • Make sure the levelling of the appliance is correct. Refer to "Installation in‐ struction". The appliance makes an un‐ • Make sure that the packaging and/or the transit bolts are removed. Refer to usual noise and vibrates. "Installation instruction".

  • Page 53: Consumption Values

    it tensed and, in the meanwhile, open the CAUTION! appliance door. The emergency unlock trigger is located where indicated by the Risk of injury! Make sure that the following picture. drum is not rotating. If necessary, wait until the drum stops rotating. Make sure that the water level inside the drum is not too high.

  • Page 54: Washing Only

    Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of the cycle. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture at the end of washing cycle. Values and programme duration may differ depending on different conditions (e.g.

  • Page 55: Environmental Concerns

    Programme rpm 1) Litres hh:mm °C Cottons 2.250 85.0 04:00 44.00 85.0 1600 90°C Cottons 1.350 80.0 03:25 44.00 55.0 1600 60°C Cottons 0.250 80.0 02:50 44.00 20.0 1600 20°C Synthetics 0.650 75.0 02:25 35.00 40.0 1200 40°C Delicates 0.360 50.0 01:10 35.00...
  • Page 56 157074210-B-412024...
