IMPORTANT—PLEASE READ All products shown are prototype. Actual product delivered may vary. Product specifi cations, features, and software are subject to change without notice. For the most up-to-date version of this manual, please see our website: https://truefi tness.com/services-support/user- manuals/ CONTACTING OUR SUPPORT TEAM To contact TRUE for any of your pre or post installation questions, please call our toll-free numbers Monday - Friday 8:30am - 5:00pm (CST): •...
REPORTING FREIGHT CLAIMS OR PARTS DAMAGE Unfortunately, sometimes materials can be damaged during shipment. If materials are damaged during shipment, please follow the guidelines below to determine the appropriate process for you to follow. Severe Damage—Obvious damage to external packaging and internal product. Please refuse the shipment and it will be returned to TRUE by the carrier.
TABLE OF CONTENTS SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS..................6 GENERAL CARE AND MAINTENANCE............................8 COMMERCIAL MAINTENANCE SCHEDULE..........................9 COMPLIANCES..................................9 DIMENSIONS AND WEIGHTS..............................10 LABEL LOCATIONS.................................11 WARNING AND INTENDED USE LABELS..........................11 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST..............................13 ASSEMBLY STEPS..................................16 PREVENTATIVE MAINTENANCE DAILY INSPECTION AND MAINTENANCE..........................22 WEEKLY INSPECTION AND MAINTENANCE..........................22 OTHER SCHEDULED PREVENTATIVE MAINTENANCE......................22 CLEANING THE EQUIPMENT..............................23...
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS FACILITY AND USER SAFETY PRECAUTIONS • Review and understand all of the warning labels affi xed to this machine and on the facility safety sign. • Be certain that the machine operation is understood before it is used. Refer to the instructional procedure label affi xed to the machine.
INSTALLATION SAFETY PRECAUTIONS • Read this installation manual entirely before assembling this equipment. • Verify that there is adequate space surrounding this piece of equipment for safe access and operation. Installation must meet ADA requirements for accessibility. • Install this piece of equipment on a solid level surface that does not deviate more than 1/8” over a 10’ distance (or as defi...
GENERAL CARE AND MAINTENANCE IMPORTANT Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these products. As a minimum, the items presented in the SAFETY section of this document and the items that follow here, should be included in your maintenance program.
COMMERCIAL MAINTENANCE SCHEDULE Commercial Maintenance Schedule Daily Weekly Monthly 6 Months Annually Inspect all nuts and bolts and tighten if needed. Inspect safety catches, stop rods, and their fasteners. Replace at the fi rst sign of wear. Inspect all anti-slip surfaces and replace as needed. Inspect all accessory bars and handles.
DIMENSIONS AND WEIGHTS • ASSEMBLED DIMENSIONS (W X L X H) 66" x 73” x 92” / 167 cm x 185 cm x 233 cm HEIGHT 92” 233 cm WIDTH LENGTH 66” 73” 167 cm 185 cm ∙ PRODUCT WEIGHT 363 lbs / 165 kg ∙...
LABEL, WARNING, COMPLETELY INSERT PIN LBL-WRN-0011 LABEL, DO NOT ATTACH STRAPS LBL-WRN-0014 LABEL, SQUAT BAR CATCH HEIGHT SL-XFW7910-35 LABEL, SERIAL NUMBER WARNING AND INTENDED USE LABELS WARNING: Replace all labels that may be worn, damaged, or missing. To replace any worn or missing decals contact TRUE product support (service@truefi tness.com | 800.883.8783).
Page 12
Part# and Description Image SL-XFW7910-35 (Serial Number) TRUE FITNESS TECHNOLOGY, INC 865 HOFF RD, ST LOUIS MISSOURI 63366 USA MODEL NO: XFW7910-35 SERIAL NO: 25-XFW791000A LBL-WRN-0014 (Squat Bar Catch Height) B2065 (Completely Insert Pin) SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT IF THE PIN IS NOT COMPLETELY INSERTED BEFORE USE.
ASSEMBLY INSTRUCTIONS NOTE: Supplemental video available on YouTube: https://www.youtube.com/@TRUEFitnessservicevids PREASSEMBLY CHECKLIST CAUTION: Use caution when assembling this product. Unpacking and assembling this product requires two or more people. Use caution when unpacking this product. Avoid damage to the product. DO NOT use a box cutter. DO NOT slice into the packaging. VERIFY BOX CONTENTS IMPORTANT! Please verify all box contents.
BOX CONTENTS BOX CONTENTS Item Image Item Image Weight Horn Base Frame Round Bumper Upper Left Frame Frame Header Upper Right Frame Rear Brace Left Rear Frame Rear Brace with Label Right Safety Catch Right Rear Frame Left Safety Catch Right Catch Hook Front Column Left Catch Hook...
Page 15
HARDWARE PACK CONTENTS XFW7910 HARDWARE PACK ITEM DESCRIPTION HHS, 3/8"-16, 1-1/4", LOCKING PATCH C 446LP LOCK WASHER, 3/8", ZP C 749 WASHER, FLAT, 3/8" USS C 754C HHS, 3/8"-16 X 3" C 452 LOCK NUT, 3/8"-16 X 17/64", NYL C 766A BASE WASHER, PLASTIC CAP, 3/8"...
ASSEMBLY STEPS STEP 1—ATTACH THE FRONT AND MIDDLE COLUMNS TO THE BASE FRAME ASSEMBLIES Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench XFW79-BF000X-35 SUBASSEMBLY, BASE FRAME, XFW7900 XFW79-SF120X-35 SUBASSEMBLY, FRONT COLUMN, XFW7901 XFW79-SF125X-35 SUBASSEMBLY, MIDDLE COLUMN, XFW7901 C 446LP...
Page 17
STEP 2—ATTACH THE UPPER AND REAR FRAME ASSEMBLIES TO THE FRONT AND MIDDLE COLUMNS Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench XFW79- SUBASSEMBLY, UPPER LEFT FRAME, XFW7900 CBR020X-35 XFW79-CBR010X-35 SUBASSEMBLY, UPPER RIGHT FRAME, XFW7900 XFW79-RF025-35 WELDMENT, LEFT REAR FRAME, XFW7900...
Page 18
STEP 3—ATTACH WEIGHT HORNS TO THE REAR FRAME ASSEMBLIES Parts Used in this Step ITEM PART# DESCRIPTION XFW79-WH010X SUBASSEMBLY, WEIGHT HORN XFT-HRK-RRNG BUMPER, ROUND, 1-1/2" ID X 3" OD X 1" D-871A PIN, 3/8" X 1-3/4" ROLL PIN, SLOTTED Attach 4 weight horns to the left and right rear frame assemblies using 4 round bumpers and 4 slotted roll pins on each side. NOTE: For examples purposes, the left rear frame assembly is shown below.
Page 19
STEP 4—ATTACH REAR BRACES AND FRAME HEADER Parts Used in this Step Tools Used in this Step ITEM PART# DESCRIPTION 9/16" Socket Wrench XFW79-CBR030-35 WELDMENT, REAR BRACE, XFW7900 XFW79- SUBASSEMBLY, REAR BRACE, XFW7900 CBR030X-35 XFW79-CBR015X-35 SUBASSEMBLY, FRAME HEADER, XFW7900 C 446LP HHS, 3/8"-16, 1-1/4", LOCKING PATCH C 749 LOCK WASHER, 3/8", ZP...
Page 20
STEP 5—ATTACH SAFETY CATCHES AND CATCH HOOKS Parts Used in this Step ITEM PART# DESCRIPTION XFW79-CT100X-35 SUBASSEMBLY, LEFT SAFETY CATCH, XFW7901 XFW79-CT110X-35 SUBASSEMBLY, RIGHT SAFETY CATCH, XFW7901 XFW79-HK200X-35 SUBASSEMBLY, LEFT CATCH HOOK, XFW7901 XFW79-HK210X-35 SUBASSEMBLY, RIGHT CATCH HOOK, XFW7901 A. Attach the left and right safety catches to the front and middle columns. B.
Page 21
STEP 6—VERIFY ALL ADJUSTMENTS FUNCTION AS INTENDED Pull the safety catches and catch hooks out of the front and middle columns using the pop pins and place them into each of the adjustment holes for the front and middle columns. NOTE: The front and middle columns have twenty-three adjustment holes.
PREVENTATIVE MAINTENANCE Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these products. As a minimum, the items presented in the Safety Instructions section of this document and the items that follow here, should be included in your maintenance program.
CLEANING THE EQUIPMENT Daily Cleaning Wipe all machines with a water dampened cloth and dry completely. This includes painted parts, chrome plated parts, and plastic parts. It is important not to leave parts damp. This will increase the potential for corrosion to occur. CAUTION: Certain anti-bacterial cleaners and other harsh cleaning agents can induce corrosion on the machine components.
fi lled in, signed by the original purchaser, and mailed to TRUE. **Labor warranty is available for equipment located within United States. TRUE Fitness equipment is automatically covered under a 6-month Limited Labor Warranty. This 6-month Limited Labor Warranty begins from the date of purchase shown by a valid receipt.
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original product purchaser and the parts of the TRUE product (the “Product”) listed below. During the applicable Warranty Period, the Product, under normal use and service, shall be free of manufacturing defects in workmanship and materials.
QR Code: Scan the QR code below with your smartphone to be base serial taken directly to the registration page. number location TRUE FITNESS TECHNOLOGY, INC 865 HOFF RD, ST LOUIS MISSOURI 63366 USA OURI 63366 OURI 63366 • By Mail:...
