IMPORTANT—PLEASE READ All products shown are prototype. Actual product delivered may vary. Product specifi cations, features, and software are subject to change without notice. For the most up-to-date version of this manual, please see our website: https://truefi tness.com/services-support/user- manuals/ CONTACTING OUR SUPPORT TEAM To contact TRUE for any of your pre or post installation questions, please call our toll-free numbers Monday - Friday 8:30am - 5:00pm (CST): •...
REPORTING FREIGHT CLAIMS OR PARTS DAMAGE Unfortunately, sometimes materials can be damaged during shipment. If materials are damaged during shipment, please follow the guidelines below to determine the appropriate process for you to follow. Severe Damage—Obvious damage to external packaging and internal product. Please refuse the shipment and it will be returned to TRUE by the carrier.
TABLE OF CONTENTS SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS..................5 GENERAL CARE AND MAINTENANCE............................7 COMMERCIAL MAINTENANCE SCHEDULE..........................8 COMPLIANCES..................................8 DIMENSIONS AND WEIGHTS..............................9 LABEL LOCATIONS.................................10 WARNING AND INTENDED USE LABELS..........................10 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST..............................12 ASSEMBLY STEPS..................................15 PREVENTATIVE MAINTENANCE DAILY INSPECTION AND MAINTENANCE..........................23 WEEKLY INSPECTION AND MAINTENANCE..........................23 OTHER SCHEDULED PREVENTATIVE MAINTENANCE......................23 CLEANING THE EQUIPMENT..............................24...
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS FACILITY AND USER SAFETY PRECAUTIONS • Review and understand all of the warning labels affi xed to this machine and on the facility safety sign. • Be certain that the machine operation is understood before it is used. Refer to the instructional procedure label affi xed to the machine.
INSTALLATION SAFETY PRECAUTIONS • Read this installation manual entirely before assembling this equipment. • Verify that there is adequate space surrounding this piece of equipment for safe access and operation. Installation must meet ADA requirements for accessibility. • Install this piece of equipment on a solid level surface that does not deviate more than 1/8” over a 10’ distance (or as defi...
GENERAL CARE AND MAINTENANCE IMPORTANT Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these products. As a minimum, the items presented in the SAFETY section of this document and the items that follow here, should be included in your maintenance program.
COMMERCIAL MAINTENANCE SCHEDULE Commercial Maintenance Schedule Daily Weekly Monthly 6 Months Annually Inspect all nuts and bolts and tighten if needed. Inspect safety catches, stop rods, and their fasteners. Replace at the fi rst sign of wear. Inspect all anti-slip surfaces and replace as needed. Inspect all accessory bars and handles.
DIMENSIONS AND WEIGHTS • ASSEMBLED DIMENSIONS (W X L X H) 66" x 67” x 92” / 167 cm x 170 cm x 233 cm HEIGHT 92” 233 cm WIDTH LENGTH 66” 67” 167 cm 170 cm ∙ PRODUCT WEIGHT 345 lbs / 157 kg ∙...
LBL-WRN-0014A LABEL, SQUAT LONG BAR STOP HEIGHT LBL-WRN-0021 LABEL, WARNING USE SPOTTER & STOP CATCHES SL-XFW8110-35 LABEL, SERIAL NUMBER WARNING AND INTENDED USE LABELS WARNING: Replace all labels that may be worn, damaged, or missing. To replace any worn or missing decals contact TRUE product support (service@truefi tness.com | 800.883.8783).
Page 11
Part# and Description Image LBL-WRN-0010 (General Warning) SL-XFW8110-35 (Serial Number) TRUE FITNESS TECHNOLOGY, INC 865 HOFF RD, ST LOUIS MISSOURI 63366 USA MODEL NO: XFW8110-35 SERIAL NO: 25-XFW811000A LBL-WRN-0014A (Long Bar Stop Height) TO REDUCE THE RISK OF SERIOUS SPINAL INJURY, DO NOT PLACE LONG BAR STOPS BELOW THIS LEVEL WHEN DOING SQUAT EXERCISES.
ASSEMBLY INSTRUCTIONS NOTE: Supplemental video available on YouTube: https://www.youtube.com/@TRUEFitnessservicevids PREASSEMBLY CHECKLIST CAUTION: Use caution when assembling this product. Unpacking and assembling this product requires two or more people. Use caution when unpacking this product. Avoid damage to the product. DO NOT use a box cutter. DO NOT slice into the packaging. VERIFY BOX CONTENTS IMPORTANT! Please verify all box contents.
BOX CONTENTS BOX CONTENTS Item Image Item Image Left Front Frame Chin Up Bar Right Front Frame Cross Brace Double Oval Foot Cross Brace with Label Left Stop Bar Left Rear Frame Right Stop Bar Right Rear Frame Left Bar Catch Right Bar Catch Olympic Bar Holder Adjustment Column...
Page 14
HARDWARE PACK CONTENTS XFW8110 HARDWARE PACK XFW8110 HARDWARE PACK ITEM DESCRIPTION ITEM DESCRIPTION HHS, 3/8"-16, 1-1/4", LOCKING HH SCREW, 1/2"-13, 4" PATCH C 446LP C 476 LOCK WASHER, 3/8", ZP HH SCREW, 1/2"-13, 4-1/2", GR8 C 749 C 480A WASHER, FLAT, 3/8" USS C 754C HH SCREW, 3/8"-16, 2-3/4"...
ASSEMBLY STEPS STEP 1—ASSEMBLE THE LEFT AND RIGHT FRAMES Tools Used in this Step Parts Used in this Step 9/16" and 3/4" ITEM PART# DESCRIPTION Socket Wrench XFW81-LFF00-35 WELDMENT, LEFT FRONT FRAME, MATTE BLACK XFW81-RFF00-35 RIGHT FRONT FRAME WELDMENT, MATTE BLACK XFW81-LRF00X-35 ASSEMBLY, LEFT REAR FRAME, MATTE BLACK...
Page 16
STEP 1—ASSEMBLE THE LEFT AND RIGHT FRAMES CONTINUED B. Using a 3/4" socket wrench and open end wrench, attach the left and right front frame and rear frame assemblies to the bottom of the adjustment columns using 3 hex head screws, 1 lock washer, 5 fl at washers, and 2 lock nuts on each side. C.
Page 17
STEP 2—ATTACH CROSS BRACES AND CHIN UP BAR TO THE REAR FRAME ASSEMBLIES Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench XFW81-CBR000-35 WELDMENT, CROSS BRACE FRAME, MATTE BLACK XFW81-CBR000X-35 ASSEMBLY, CROSS BRACE FRAME, MATTE BLACK XFW81-CBR100 WELDMENT, CHIN UP BAR...
Page 18
STEP 3—ATTACH BAND PEG KIT (OPTIONAL) AND WEIGHT HORNS Parts Used in this Step Tools Used in this Step ITEM PART# DESCRIPTION 9/16" Socket Wrench XFW79-WH010X SUBASSEMBLY, WEIGHT HORN XFT-HRK-RRNG BUMPER, ROUND, 1-1/2" ID X 3" OD X 1" XFW81-BP100-35 WELDMENT, BAND STORAGE POST, MATTE BLACK XFW81-BP000X-35...
Page 19
STEP 3—ATTACH BAND PEG KIT (OPTIONAL) AND WEIGHT HORNS CONTINUED B. Slide 2 weight horns and 2 round bumpers into the left and right rear frame assemblies and slide the 2 band storage posts into the weight horns. C. Attach the 2 band storage posts to the weight horns using 2 slotted roll pins. D.
Page 20
STEP 4—ATTACH OLYMPIC BAR HOLDER Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench XFW81- ASSEMBLY, OLYMPIC BAR HOLDER, MATTE OBH000X-35 BLACK C 451 HH SCREW, 3/8"-16, 2-3/4" C 749 LOCK WASHER, 3/8", ZP C 754C WASHER, FLAT, 3/8"...
Page 21
STEP 5—ATTACH LONG STOP BAR ASSEMBLIES AND BAR CATCH ASSEMBLES Parts Used in this Step ITEM PART# DESCRIPTION XFW81-HK100LX-35 ASSEMBLY, LEFT LONG STOP BAR XFW81-HK100RX-35 ASSEMBLY, RIGHT LONG BAR STOP XFW81-HK150LX-35 ASSEMBLY, LEFT BAR CATCH XFW81-HK150RX-35 ASSEMBLY, RIGHT BAR CATCH LBL-WRN-0014A LABEL, SQUAT LONG BAR STOP HEIGHT A.
Page 22
OPTIONAL STEP 6—ANCHOR THE MACHINE TO THE FLOOR IMPORTANT! TRUE strongly recommends that all equipment be anchored to the fl oor to prevent movement and increase stability. IMPORTANT! Due to the wide variation of fl ooring on which the unit can be installed, contact a qualifi ed contractor to determine an appropriate fastening system for your fl...
PREVENTATIVE MAINTENANCE Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these products. As a minimum, the items presented in the Safety Instructions section of this document and the items that follow here, should be included in your maintenance program.
CLEANING THE EQUIPMENT Daily Cleaning Wipe all machines with a water dampened cloth and dry completely. This includes painted parts, chrome plated parts, and plastic parts. It is important not to leave parts damp. This will increase the potential for corrosion to occur. CAUTION: Certain anti-bacterial cleaners and other harsh cleaning agents can induce corrosion on the machine components.
fi lled in, signed by the original purchaser, and mailed to TRUE. **Labor warranty is available for equipment located within United States. TRUE Fitness equipment is automatically covered under a 6-month Limited Labor Warranty. This 6-month Limited Labor Warranty begins from the date of purchase shown by a valid receipt.
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original product purchaser and the parts of the TRUE product (the “Product”) listed below. During the applicable Warranty Period, the Product, under normal use and service, shall be free of manufacturing defects in workmanship and materials.
QR Code: Scan the QR code below with your smartphone to be taken directly to the registration page. base serial number location TRUE FITNESS TECHNOLOGY, INC • By Mail: 865 HOFF RD, ST LOUIS MISSOURI 63366 USA OURI 63366 OURI 63366...
