- Page 1 Operating Instructions Network Camera Model No. PM-EB2NLFR-W/PM-ED2NLFR-W PM-EB2NLFR-W PM-ED2NLFR-W Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use...
-
Page 2: Safety Instruction
Safety Instruction The following symbols or words may be found in this manual. Symbols/Words Description Indicates a medium or low potential hazardous situation which , ⚠ Warning if not avoided, will or could result in slight or moderate injury Indicates a potential risk which, if not avoided, will or could ⚠... -
Page 3: Operation And Daily Maintenance
Power Source', 'LPS' on unit, output rated minimum POE 48V/ 350mA, no more than 2000m altitude of operation and Tma=60 Deg.C. ◼ As for the modes with PoE function, the function of the ITE being investigated to IEC 60950-1 standard is considered not likely to require connection to an Ethernet network with outside plant routing, including campus environment and the ITE is to be connected only to PoE networks without routing to the outside plant. -
Page 4: Privacy Protection
⚫ DO NOT turn on the white light when you install or maintain the camera. Please wear appropriate eye protection when you want to test the white light. ⚫ DO NOT stare at the operating light source. It will probably be harmful to your eyes. Privacy Protection ⚫... -
Page 5: Regulatory Information
specified IP addresses from accessing the system. ⚫ If you add multiple users, please limit functions of guest accounts. ⚫ If you enable UPnP, it will automatically try to forward ports in your router or modem. It is really very convenient for users, but this will increase the risk of data leakage when the system automatically forwards ports. - Page 6 The products have been designed and manufactured in accordance with Directive EU RoHS Directive 2011/65/EU and its amendment Directive EU 2015/863 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. 2012/19/EU (WEEE directive): The Directive on waste electrical and electronic equipment (WEEE Directive).
-
Page 7: Table Of Contents
Table of Contents Network Connection ...................... 1 LAN ........................1 1.1.1 Access through Panasonic IP Manager Tool ..........1 1.1.2 Directly Access through IE ............... 3 WAN ........................4 Live View ........................8 Network Camera Configuration ................... 9 System Configuration ..................9 3.1.1... - Page 8 3.6.3 Block and Allow Lists ................37 3.6.4 Security Management ................37 Maintenance Configuration................38 3.7.1 Backup and Restore ................38 3.7.2 Reboot ....................39 3.7.3 Upgrade ....................39 3.7.4 Operation Log ..................40 Search ........................... 41 Image Search ....................41 Video Search ....................
-
Page 9: Network Connection
1.1.1 Access through Panasonic IP Manager Tool Network connection: ① Make sure the PC and IP Camera are connected to the LAN and the Panasonic IP Manager Tool is installed in the PC. ② Double click the Panasonic IP Manager Tool icon on the desktop to run this software as... - Page 10 The default IP address of the camera is 192.168.0.10. ③ Double click the IP address and then the system will pop up the IE browser to connect IP CAMERA. After you read the privacy statement, check and click “Already Read”. Then activate the device.
-
Page 11: Directly Access Through Ie
Please enter the user name (admin) and password. The security questions must be set after you click “Login” button. It is very important for you to reset your password. Please remember these answers. 1.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.0.10 Subnet Mask: 255.255.255.0 Gateway: 192.168.0.1... -
Page 12: Wan
① Manually set the IP address of the PC and the network segment should be as the same as the default settings of the IP camera. Open the network and share center. Click “Local Area Connection” to pop up the following window. Select “Properties”... - Page 13 ① Make sure the camera is connected to the local network and then log in the camera via LAN and go to Config→Network→Port menu to set the port number. Port Setup ② Go to Config →Network→TCP/IP menu to modify the IP address. IP Setup ③...
- Page 14 Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (for example, if the http port is changed to 81, please enter “192.198.1.201:81” in the address bar of web browser to access). ➢ Access through PPPoE dial-up Network connection Access the camera through PPPoE auto dial-up.
- Page 15 ➢ Access through static IP Network connection The setup steps are as follow: ① Go to Config→Network→Port menu to set the port number. ② Go to Config →Network→TCP/IP menu to set the IP address. Check “Use the following IP address” and then enter the static IP address and other parameters. ③...
-
Page 16: Live View
2 Live View After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size Zoom out Fit correct scale Rule information display Auto (fill the window) Motion alarm indicator Full screen... -
Page 17: Network Camera Configuration
3 Network Camera Configuration In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 3.1 System Configuration 3.1.1 Basic Information In the “Basic Information” interface, the system information of the device is listed. 3.1.2 Date and Time Go to Config→System→Date and Time. -
Page 18: Local Config
modify the time zone of the camera according to the time zone of the computer. If the time zone of the computer is modified, the current web client needs to be closed. Then re-open it and log in again. Click the “Date and Time” tab to set the time mode and time format. 3.1.3 Local Config Go to Config→System→Local Config to set up the storage path of captured pictures and recorded videos on the local PC. - Page 19 pictures and descriptions are for reference only. The real camera interface shall prevail. Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity.
- Page 20 Antiflicker: ⚫ Off: disables the anti-flicker function. This is used mostly in outdoor installations. ⚫ 50Hz: reduces flicker in 50Hz lighting conditions. ⚫ 60Hz: reduces flicker in 60Hz lighting conditions. White Balance: Adjust the color temperature according to the environment automatically. Exposure Mode: Choose “Auto”...
-
Page 21: Video / Audio Configuration
Set full time schedule for common, auto mode and specified time schedule for day and night. Choose “Timing” in the drop-down box of schedule as shown below. Drag “ ” icons to set the time of day and night. Blue means day time and blank means night time. -
Page 22: Osd Configuration
usage. However, if the value is set too high, and there is a high frequency of movement in the video, there is a risk of frame skipping. Video Compression: H264+, H264, H265 or H265+ can be optional. If H.265/H.265+ is chosen, make sure the client system is able to decode H.265/H.265+. -
Page 23: Video Mask
Set time stamp, device name and OSD content here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. 3.2.4 Video Mask Go to Image→Video Mask interface as shown below. A maximum of 4 zones can be set up. To set up video mask: 1. -
Page 24: Roi Configuration
3.2.5 ROI Configuration Go to Image→ROI Config interface as shown below. An area in the image can be set as a region of interest. This area will have a higher bitrate than the rest of the image, resulting in better image quality for the identified area. 1. - Page 25 1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Holding Time: it refers to the interval time between the adjacent motion detections. For instance, if the alarm holding time is set to 20 seconds, once the camera detects a motion, it will go to alarm and would not detect any other motion in 20 seconds.
-
Page 26: Alarm Server
3. Set the schedule for motion detection. Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule. -
Page 27: Event Configuration
3.4 Event Configuration For more accuracy, here are some recommendations for installation. ⚫ Cameras should be installed on stable surfaces, as vibrations can affect the accuracy of detection. ⚫ Avoid pointing the camera at the reflective surfaces (like shiny floors, mirrors, glass, lake surfaces and so on). -
Page 28: Line Crossing
color deviation. 2. Set the alarm holding time and alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection section for details. 3. Click “Save” button to save the settings. 4. Set the sensitivity of the exception detection. Click “Sensitivity” tab to go to the interface as shown below. - Page 29 1. Enable line crossing alarm and set the alarm holding time. 2. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to Motion Detection section for details. 3. Click “Save” button to save the settings. 4.
-
Page 30: Region Intrusion
3.4.3 Region Intrusion Region Intrusion: Alarms will be triggered if someone or something intrudes into the pre-defined areas. This function can be applicable to important supervision places, danger areas and prohibited areas, like military administrative zones, house breaking, scenic high danger areas, no man’s areas, etc. -
Page 31: Network Configuration
※ Configuration requirements of camera and surrounding area 1. Avoid the scenes with many trees or the scenes with various light changes (like many flashing headlights). The ambient brightness of the scenes shouldn’t be too low. 2. Cameras should be mounted at a height of 2.8 meters or above. 3. -
Page 32: Port
Either method of network connection can be used. If PPPoE is used to connect internet, the camera will get a dynamic WAN IP address. This IP address will change frequently. To be notified, the IP change notification function can be used. Click “IP Change Notification Config”... -
Page 33: Onvif
1. Check “Enable”. 2. Check the IP address and port of the transfer media server in the CMS/NVMS. Then enable the auto report in the CMS/NVMS when adding a new device. Next, enter the remaining information of the device in the CMS/NVMS. After that, the system will automatically allot a device ID. -
Page 34: Ddns
use the onvif user in the above interface. 3.5.5 DDNS If the camera is set up with a DHCP connection, DDNS should be set for the internet. 1. Go to Config→Network→ DDNS. 2. Apply for a domain name. Take www.dvrdyndns.com for example. Enter www.dvrdydns.com in the IE address bar to visit its website. -
Page 35: Snmp
After the domain name is successfully applied for, the domain name will be listed as below. 3. Enter the username, password, domain you apply for in the DDNS configuration interface. 4. Click the “Save” button to save the settings. 3.5.6 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. - Page 36 2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2, Enable SNMPv3) according to the version of the SNMP software that will be used. 3. Set the values for “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port” and so on. Please make sure the settings are the same as that of the SNMP software.
-
Page 37: 802.1X
3.5.7 802.1x If it is enabled, the camera’s data can be protected. When the camera is connected to the network protected by the IEE802.1x, user authentication is needed. To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. -
Page 38: Upnp
Multicast Address Main stream: The address format is “rtsp://IP address: rtsp port/profile1?transportmode=mcast”. Sub stream: The address format is “rtsp://IP address: rtsp port/profile2?transportmode=mcast”. Audio: Having entered the main/sub stream in a VLC player, the video and audio will play automatically. (Only the model with the built-in MIC supports this function) If “Allow anonymous login…”... -
Page 39: Ftp
Sender Address: sender’s e-mail address. User name and password: sender’s user name and password (you don’t have to enter the username and password if “Anonymous Login” is enabled). Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection” pull-down list according to what’s required. - Page 40 2. Click “Add” to add the information of the FTP. After that, click “Save” to save the settings. Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server.
-
Page 41: Https
File Name Event Type IP address change MOTION Motion detection Video exception TRIPWIRE Line crossing detection PERIMETER Region intrusion detection TXT file content: device name: xxx mac: device MAC address Event Type time: For example: device name: IPC mac: 00-18-ae-a8-da-2a MOTION time: 2021-03-16 12:20:07 3.5.12 HTTPS HTTPs provides authentication of the web site and protects user privacy. -
Page 42: Qos
Click the “Create” button to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on. Then click “OK” to save the settings. * Click “Create a certificate request” to enter the following interface. Click “Create”... -
Page 43: Security Configuration
3.6 Security Configuration 3.6.1 User Configuration Go to Config→Security→User interface as shown below. Add user: 1. Click the “Add” button to pop up the following textbox. 2. Enter user name in the “User Name” textbox. 3. Enter the password in the “Password” and “Confirm Password” textbox. Please set the password according to the requirement of the password security level (Go to Config→Security→Security Management→Password Security interface to set the security level). -
Page 44: Online User
1. Select a user to modify password if necessary in the user configuration list box. 2. The “Edit user” dialog box pops up by clicking the “Modify” button. 3. Enter the old password of the user in the “Old Password” text box. 4. -
Page 45: Block And Allow Lists
An administrator user can kick out all the other users (including other administrators). 3.6.3 Block and Allow Lists Go to Config→Security→Block and Allow Lists as shown below. The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6 and then enter IP address in the address box and click the “Add”... -
Page 46: Maintenance Configuration
Please set the password level and expiration time as needed. Password Level: Weak, Medium or Strong. Weak level: Numbers, special characters, upper or lower case letters can be used. You can choose one of them or any combination of them when setting the password. Medium Level: 8~16 characters, including at least two of the following categories: numbers, special characters, upper case letters and lower case letters. -
Page 47: Reboot
⚫ Import & Export Settings Configuration settings of the camera can be exported form a camera into another camera. 1. Click “Browse” to select the save path for import or export information on the PC. 2. Click the “Import Setting” or “Export Setting” button. Note: The login password needs to be entered after clicking the “Import Setting”... -
Page 48: Operation Log
1. Click the “Browse” button to select the save path of the upgrade file 2. Click the “Upgrade” button to start upgrading the firmware. 3. Enter the correct password and then the device will restart automatically Caution! Do not close the browser or disconnect the camera from the network during the upgrade. -
Page 49: Search
4 Search 4.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the local PC card can be found here. Note: When using the plug-in free browser, the local images cannot be searched. ⚫... -
Page 50: Video Search
The descriptions of the buttons are shown as follows. Icon Description Icon Description Close: Select an image and click Close all: Click this button to this button to close the image. close all images. Actual size: Click this button to Fit size: Click to fit the image on display the actual size of the the screen. - Page 51 Icon Description Icon Description Play button. After pausing the video, click this button Pause button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio.
-
Page 52: Appendix
B: IP address is not available. Reset the IP address. C: Web port number has been changed: contact administrator to get the correct port number. D: Exclude the above reasons. Restore to default setting by Panasonic IP Manager Tool. Panasonic IP Manager Tool cannot search devices. - Page 53 No sound can be heard. A：Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function.
