UNDER MOUNT RANGE HOOD SERIES
OWNER'S MANUAL &
INSTALLATION GUIDE
READ ENTIRE INSTALLATION GUIDE PRIOR TO INSTALLING THE RANGE HOOD
For installation and assembly videos, please visit our website
https://www.youtube.com/channel/UCII7TGMbkwoGSqzo-pGfaJw
The images shown are for illustration purposes only and may not be an exact
streamlinebath.com
www.streamlinebath.com
our YouTube page by searching for
"Streamline Bath"
following the below link to our channel:
representation of the product.
T-1549-SERIES
T-1585-SERIES
CAUTION!
support@streamlinebath.com
OR
OR
TWO PERSON
LIFT REQUIRED
(310) 935-0028

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-1549 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Streamline T-1549 Series

Summary of Contents for Streamline T-1549 Series

  • Page 1 For installation and assembly videos, please visit our website www.streamlinebath.com our YouTube page by searching for "Streamline Bath" following the below link to our channel: https://www.youtube.com/channel/UCII7TGMbkwoGSqzo-pGfaJw The images shown are for illustration purposes only and may not be an exact representation of the product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Disclaimer Electrical Guidelines Warranty Guidelines Tools Required Parts Supplied Installation Dimensions Ventilation Options Installation Instructions Control Panel Operation Product Care & Maintenance LED Light Replacement support@streamlinebath.com (310) 935-0028 streamlinebath.com...

  • Page 3: Safety Disclaimer

    In the event of malfunctions or Use this unit only in the manner if repairs are required to the appliance, intended by Streamline. If you have any do not attempt to solve the problems questions, please contact Streamline. directly.
  • Page 4 The range hood must only be used to Before installing your range hood, it's exhaust cooking fumes in the home. essential to verify the local, city, and The manufacturer disclaims all liability state regulations for the appropriate for any other use of the appliance. The venting method.
  • Page 5 Before drilling any holes, it is crucial to Never leave surface units unattended verify that the space behind the when set to high heat. Boil-over can installation surface is free of any cause smoke and grease to spill over, electrical cables, pipes, or other which may ignite.
  • Page 6 (from boilers, fireplaces, etc.). Make sure questions on repairs and other work the mains voltage corresponds to the on the appliance, please contact values on the rating plate located inside Streamline at 310-935-0028 the range hood. support@streamlinebath.com Old ductwork should be cleaned or replaced before installation to avoid the possibility of a grease fire.

  • Page 7: Electrical Guidelines

    Electrical Guidelines Please ensure to observe all governing codes and ordinances when installing the range hood. Additionally, ensure that the electrical installation is adequate and complies with the latest edition of the National Electrical Code, ANSI/NFPA 70, or CSA Standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No. 0-M91, as well as all local codes and ordinances.

  • Page 8: Warranty Guidelines

    USE THE PRODUCT, OR ANY OTHER ASSOCIATED EQUIPMENT, THE COST OF SUBSTITUTE EQUIPMENT, AND ANY CLAIMS BY THIRD PARTIES RESULTING FROM THE USE OF THIS PRODUCT. UNDER NO CIRCUMSTANCES SHALL STREAMLINE'S LIABILITY EXCEED THE PURCHASE PRICE OF THE UNIT . STREAMLINE® PRODUCTS MUST BE INSTALLED BY A FULLY INSURED, LICENSED, PROFESSIONAL WHO SHALL FOLLOW THE INSTRUCTIONS PROVIDED BY STREAMLINE®.
  • Page 9 • In no event shall Streamline have any liability or the warranty. responsibility whatsoever for damage to surrounding property, including cabinetry, floors, ceilings, and other structures or objects around the product.

  • Page 10: Tools Required

    Tools Required Electric Drill 5/16'' Drill Bit Screwdriver Utility Knife Tape Measure Electrical Aluminum Foil Pliers & Pencil Wiring Tape/Duct Tape ON OFF Jigsaw/Saber Hammer Stud Finder support@streamlinebath.com (310) 935-0028 streamlinebath.com...

  • Page 11: Parts Supplied

    Parts Supplied Name Image ST4x30 Mounting Screws M5x10 Screws Wall Anchors Washer Damper Mounting Bracket 6'' Aluminum Flexible Duct 7.7'' to 6'' Round Duct Reducer support@streamlinebath.com (310) 935-0028 streamlinebath.com...

  • Page 12: Installation Dimensions

    Installation Dimensions Floor To Ceiling Height Floor To Counter Top Height (Standard: 36’’) Height of Counter Top to Range Hood Bottom (Minimum 25.6’’) Kitchen Cabinet Height Range Hood Installation Height [A-D-(B+C)] support@streamlinebath.com (310) 935-0028 streamlinebath.com...

  • Page 13: Ventilation Options

    Ventilation Options There are three different options available for venting the range hood. It is recommended to seek guidance from a professional installer to choose the best installation method for your specific requirements. Wall Venting Roof Venting support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com...
  • Page 14 We recommend installing the vent inspect each joint. Use certified system before installing the range hood. aluminum or foil tape to seal and tape all joints securely. Clamps may also be A damper is required in the venting used. system. If the wall or roof cap already has a damper, do not use the damper To minimize the backward flow of that comes with the range hood.

  • Page 15: Installation Instructions

    Installation Instructions 1. The range hood should be carefully removed from its packaging. RANGE HOOD 2. Remove the protective blue/white film from the range hood. 3. Ensure that there are no components or packaging materials that may have become trapped or left inside the range hood and remove any, if necessary. support@streamlinebath.com (310) 935-0028 streamlinebath.com...
  • Page 16 4. Test to ensure that the range hood works by plugging it into an electrical outlet. 5. Check that all features are properly functioning and that the LED lights work. 6. Unplug the range hood. support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 (310) 935-0028 (310) 935-0028...
  • Page 17 7. Remove the mesh or baffle filters, depending on the range hood that was purchased. Recessed Installation 8. If you plan to use the provided template, affix the template with tape to the bottom of the cabinet. Use a pencil to trace and mark the spots on the bottom of the cabinet where drilling will occur for the mounting holes as well as for the duct.
  • Page 18 10. Insert the plastic wall anchors firmly into the four drilled holes. 11. Insert the ST4*30 screws into the plastic wall anchors, leaving about 1/4 of an inch of the screw protruding from the cabinet. It will be tightened after the range hood is hung in the final step.
  • Page 19 12. Optional Reinforcement: For added support, optional mounting brackets are provided to secure the range hood to the wall. Consult your installer to decide if this step is necessary, depending on the weight of the hood and the wall structure. This is especially recommended for heavier range hoods that may require extra reinforcement.
  • Page 20 14. Check for stability by mounting the range hood onto the screws and ensuring it fits tightly and securely. 15. Remove the range hood from the mounting screws. 16. An optional 7.7” to 6” round adapter is included. If you choose to vent with a 6”...
  • Page 21 17. There are multiple ventilation choices available for the range hood: Ductless Ventilation: Venting through the roof: Venting through the wall: If you choose to vent When venting through the No additional ductwork is wall, an extra cutout of 6.25'' through the roof, you will required for a ductless (159mm) will need to be made...
  • Page 22 18. Two holes need to be cut in the cabinet: one for the duct and another for the power cord. a. Use a saw or drill to create a circular hole in the bottom of the cabinet. b. Drill a 1-1/2 inch hole into the bottom of the cabinet next to the vent hole to create an access hole for the power cord.
  • Page 23 20. Attach the vent flaps on the reducer. Ensure that the flaps can open smoothly without any obstructions. Ensure that the bumps on the flap face upwards and outwards Flaps 21. Connect the round aluminum duct exhaust hose to the round vent air flap by placing one end of the hose over the flap and securing it with two small screws.
  • Page 24 22. Pull the ductwork and electrical cord through the cabinet hole. 23. Lift and hang the range hood on the screws previously drilled. support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com...
  • Page 25 24. At the back of the range hood, right below the mounting holes, there will be 2 visible holes (1 on each side). These are additional safety holes to help secure the range hood in position. a. Use a 5/16'' [8mm] drill bit to make pilot holes in the cabinet at the marked locations.
  • Page 26 26. Plug in the range hood to the electrical outlet. Make sure that all operations are functioning properly. Wall Mount Installation 1. Find the optimal height for mounting the range hood. For the best results, it is recommended to place it between 25.6 to 30 inches above the range. a.
  • Page 27 2. If you plan to use the provided template, affix the template with tape to the wall, making sure that it aligns with the two previously drawn lines. Alternatively, you may also position the range hood along the vertical and horizontal lines and mark the location of the mounting holes on the wall.
  • Page 28 5. Insert (2) ST4*30 screws into the plastic wall anchors, leaving about 1/4 inch of the screw protruding from the cabinet. It will be tightened after the range hood is hung. Screws 6. Check for stability by mounting the range hood onto the screws and ensuring it fits tightly and securely.
  • Page 29 8. Optional Reinforcement: For added support, optional mounting brackets are provided to secure the range hood to the wall. Consult your installer to decide if this step is necessary, depending on the weight of the hood and the wall structure. This is especially recommended for heavier range hoods that may require extra reinforcement.
  • Page 30 10. Take the provided reducer and insert it into the top of the range hood duct. 11. Attach the vent flaps on the provided reducer on the top of the range hood. Ensure that the flaps can open smoothly without any obstructions. Ensure that the bumps on the flap face upwards and outwards.
  • Page 31 12. Connect the round aluminum duct exhaust hose to the round vent air flap by placing one end of the hose over the flap and securing it with two small screws. Then, wrap the connection with tape or use a hose clamp and wrap it with tape to ensure a tight seal.
  • Page 32 14. At the back of the range hood, right below the mounting holes, there will be 2 visible holes (1 on each side). These are additional safety holes to help secure the range hood in position. a. Use a 5/16'' [8mm] drill bit to make pilot holes in the cabinet at the marked locations.
  • Page 33 16. Plug in the range hood to the electrical outlet. Make sure that all operations are functioning properly. support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com...

  • Page 34: Control Panel Operation

    Control Panel Operation Push Button Low Speed Medium Speed Button Button Button Starts the fan at low Starts the fan at Turns off the fan. speed. medium speed. High Speed Light Button Button Starts the fan at high Used for turning the speed.
  • Page 35 Electronic Push Button Light High Speed Medium Speed Button Button Button Used for turning the Starts the fan at high Starts the fan at light on or off. speed. medium speed. Low Speed Button Button Starts the fan at low Turns off the fan.
  • Page 36 Electronic Touch Panel 88:88 Light Button Timer Used for turning the light on or off. Allows for a delayed shutdown of the range hood. Speed Button ON/OFF Button Changes the speed of the motor from Turns the fan on or off. high, medium, and low levels.
  • Page 37 Electronic Touch Panel • To turn the range hood on, press the ON/OFF button. • To turn the range hood off, push the ON/OFF button. • Pressing the OFF button once delays the turn-off time by 1 minute. • Pressing the OFF button again will turn the range hood off immediately.
  • Page 38 Touch Switch V1 ON/OFF Button • To turn the range hood on, press the ON/OFF button. The range hood will enter standby mode. If after 1 minute an operation is not selected, the range hood will automatically turn off. • • To turn the range hood off, press the ON/OFF button.
  • Page 39 • After 10 seconds, the clock will blink, and the countdown will begin automatically. Once the countdown is complete, the range hood will automatically turn off. • Please note that the previously set delay time will reset after shutdown to the standard 5 minutes.
  • Page 40 Touch Switch V2 ON/OFF Button • To turn the range hood on, press the ON/OFF button. The range hood will enter standby mode. If after 1 minute an operation is not selected, the range hood will automatically turn off. • To turn the range hood off, press the ON/OFF button.
  • Page 41 • Once done, press the TIMER button to complete the changes. If after 10 seconds there is no button selected, the settings will save automatically. • Please note that the time setting only displays in a 12-hour format. It cannot display in a 24-hour format.

  • Page 42: Product Care & Maintenance

    Product Care & Maintenance support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com streamlinebath.com streamlinebath.com...
  • Page 43 support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com streamlinebath.com streamlinebath.com...
  • Page 44 support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com streamlinebath.com streamlinebath.com...
  • Page 45 support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com streamlinebath.com streamlinebath.com...

  • Page 46: Led Light Replacement

    LED Light Replacement LED LIGHT REPLACEMENT Before proceeding, ensure that the range hood is turned off and disconnected from any electrical supply. Remove the mesh or baffle filters, depending on the range hood that was purchased. The electrical wire for the LED lights can be found behind the light fixtures.
  • Page 47 The wires for the LED lights are connected using a snap-down connector. To disconnect the LED lights, press down on the connector and gently pull the opposing electrical wire away from the connector. Take out the LED light by pressing the long silver bar that covers the LED.
  • Page 48 Insert the new LED lights into the opening inwards and upwards and apply gentle pressure until you hear a click and feel the light sitting securely in place. Reconnect the electrical wiring in the range hood with the LED snap connector.
  • Page 49 Place the filters back into their original position. 10. Turn the range hood back on. support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028 (310) 935-0028 (310) 935-0028 streamlinebath.com streamlinebath.com streamlinebath.com streamlinebath.com...
  • Page 50 Streamline. All product names, logos, and brands are the property of their respective owners. Streamline retains all rights to its trademarks, trade names, and copyrighted materials associated with this product. Unauthorized use of these materials is strictly prohibited and may result in legal action.

This manual is also suitable for:

T-1585 series

Table of Contents
