Table of Contents

UNDER CABINET
Installation Instructions,
Maintenance, Use, and Warranty
S-220-USMF-30
S-221-USMF-36
CM
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
C
FOR RESIDENTIAL USE ONLY.
US
T
Intertek
Disclaimer: Item purchased may be slightly different from the manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-220-USMF-30 and is the answer not in the manual?

Questions and answers

Related Manuals for Streamline S-220-USMF-30

Summary of Contents for Streamline S-220-USMF-30

  • Page 1 UNDER CABINET Installation Instructions, Maintenance, Use, and Warranty S-220-USMF-30 S-221-USMF-36 IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. FOR RESIDENTIAL USE ONLY. Intertek Disclaimer: Item purchased may be slightly different from the manual.
  • Page 2 Streamline®. Please notify Streamline® of refusal so we can anticipate the return and contact Streamline & provide a description of the issue as well as photos & proof of purchase. If a send out a new item.
  • Page 3 Step 3 Prior to installing the appliance, plug the power cord into a working electrical outlet and test the various functions of the unit. Ensure that the fan is functional on all speeds and that the lights For ducted installation only. For ductless installation, skip this step. operate normally before proceeding with installation.
  • Page 4 Step 5 Step 7 Cut an electrical access hole in the cabinet(Figure E). If venting the unit through the horizontal knockout Ducted installation only. If installing ductless, skip this step. plate or installing ductless, DO NOT cut a vertical duct access hole. Connect the ductwork to the hood, and secure the seam so that the unit is air tight.

  • Page 5: Operation

    OPERATION MAINTENANCE AND CLEANING FIVE FINGER TOUCH BUTTON CONTROL PANEL Constant maintenance ensures the correct operation and efficiency of the appliance over time. Special attention should be paid to the grease-trapping filters and the charcoal filters. Frequent cleaning of the filters will ensure that fats and grease do not accumulate on the cooker hood, with the consequent LIGHT BUTTON risk of fire.

  • Page 6: Safety Disclaimer

    • Ensure that there is adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other flues. • The exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances S-220-USMF-30 S-221-USMF-36 burning gas or other fuels.
