MATKI ONE
MOWW - T-BAR WALK-IN
INSTALLATION
PARTS LIST
TWO PEOPLE
RECOMMENDED
Please pass the
Guarantee Card
to the customer.
13
Matki PLC, Churchward Road, Yate,
MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL
Bristol BS37 5PL
EN 14428:2008+A1
®
TELEPHONE:01454 322888 (CUSTOMER SERVICES) EMAIL: techsupport@matki.co.uk
8918AF 05/19
Advertisement
Related Manuals for Matki ONE MOWW - T-BAR WALK-IN
Summary of Contents for Matki ONE MOWW - T-BAR WALK-IN
- Page 1 INSTALLATION PARTS LIST TWO PEOPLE RECOMMENDED Please pass the Guarantee Card to the customer. Matki PLC, Churchward Road, Yate, MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL Bristol BS37 5PL TELEPHONE:01454 322888 (CUSTOMER SERVICES) EMAIL: techsupport@matki.co.uk EN 14428:2008+A1 8918AF 05/19...
- Page 2 MOWW LH MOWW RH...
- Page 3 CAUTION: TEMPERED GLASS CANNOT BE CUT, POLISHED METAL AND CHROME CAN BE SCRATCHED. AREFULLY REMOVE ASSEMBLY FROM CARTON, DO NOT PLACE GLASS ON HARD FLOOR OR EXPOSE EDGES TO IMPACT. DO NOT CUT TOP TRACK IN ANY CIRCUMSTANCES. DIMENSIONS MATKI ONE: WETROOM PANEL: WALL BRACE BAR MODEL ‘A’ ‘B’ ‘C’...
- Page 4 MATKI ONE MOWP - WETROOM PANEL & BRACE BAR MOWV - WETROOM PANEL & CEILING BAR FOLLOW STEPS 1 - 5 TO FIT INLINE PANEL MAX. 1000mm FROM WALL POSITION DISTANCE EQUIVALENT TO SIDE PANEL WIDTH (755 - 770mm or...
- Page 5 STAGE 1 TOP VIEW FIXED PANEL WALL MOUNT WALL MOUNT Ø6 This stage is describing the fitting of the wall mount. Before fitting the enclosure, please check that your product will fit the finished aperture size. (See dimensions) Mark position for wall mount onto the wall. Check that this measurement is within the max and min width measurements. Position the side panel wall mount onto the wall.
- Page 6 STAGE 2 GLASS EDGE PROTECTOR SOAPY WATER GLASS EDGE PROTECTOR This stage is describing the fitting of the glass panel. Make sure the glass guard edge is the downwards edge placed onto the tray. Lightly wet the edge of the glass panel with soapy water and gently lower the panel down onto the tray/floor then along into the wall mount.
- Page 7 STAGE 3 GLASS CLAMP ASSEMBLY CROSS SECTION MANDRIL A + 6 STAR CUT END TWIST TAPE CONNECTOR BRACKET ASSEMBLY WOOD BLOCK This stage is describing the measuring and cutting of the brace bar. Twist the Glass Clamp assembly (found in the kit of parts) onto the coated/coloured end, which was uncut and had the star nut inside already.
- Page 8 STAGE 4 TAPE Position Brace Bar 100mm Min From 2.5mm Conenctor Conenctor Bracket This stage is describing the fitting of the connector and brace bar. Tape up the Fixed brace bar, approx. 100mm from the end. Fit the connector around the brace bar and the glass clamp assembly over the top of the glass panel.
-
Page 9: Parts List
8854 A SILVER / 8854 BLACK / 8854 C WHITE / 8854 BRONZE 5mm FOAM BEAD 1752 AF GLASS EDGE PROTECTOR (MATKI ONE WETROOM PANEL 1200) GLASS DEPENDENT MOWP KIT OF PARTS 8912 AF/COPPER/BRASS x1 : 8913 AF/COPPER/BRASS x1 ITEM...
