- Page 1 EAUZONE PLUS EWL - RADIUS 20 WET ROOM PANEL INSTALLATION PARTS LIST MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL TELEPHONE:01454 328816 (AFTER SALES) FAX:01454 328821 EMAIL: techsupport@matki.co.uk 1197 AF 02/17...
- Page 2 CAUTION: TEMPERED GLASS CANNOT BE CUT, POLISHED METAL AND CHROME CAN BE SCRATCHED. AREFULLY REMOVE ASSEMBLY FROM CARTON, DO NOT PLACE GLASS ON HARD FLOOR OR EXPOSE EDGES TO IMPACT. DIMENSIONS *dimensions are approximate EWL - RADIUS 20 WET ROOM PANEL MODEL TOTAL WIDTH ‘A’ EWL800: 754mm – 764mm EWL900: 854mm –...
- Page 3 THE STAGES IN THIS INSTALLATION BOOKLET SHOW AN LH INSTALLATION REVERSE FOR RH...
- Page 4 STAGE 1 STAGE 1 TOP VIEW WALL MOUNT TOP VIEW Ø6 This stage is describing the Wall Mount installation. Position the wall mount on to the wall in the desired position. If fitting the panel close to the edge of a shower tray take into account that the front face of the wall mount sits approximately 7.5mm forward from the glass panel.
- Page 5 Left Hand STAGE 2 STAGE 2 Right Hand RUBBER PART INSIDE Remove Redundant 7462 BLACK UNIT Top Edge Protectors (x2) RUBBER PART INSIDE 7462 BLACK UNIT PLASTIC PARTS NOT USED SOAPY WATER Left Hand Right Hand SOAPY WATER This stage is describing the fitting of the glass panel. We recommend two people are available for this stage. The Panel Top Bracket is unhanded.
- Page 6 STAGE 3 SILICON WALL MOUNT ON OUTSIDE OF UNIT ONLY GLASS SILICON FLOOR/GLASS GLASS BOTH SIDES EDGE OF UNIT PROTECTOR ONLY TILES/TRAY/FLOOR This stage is describing the Silicon Sealant of the Panel. Apply a thin bead of Silicon all the way up the outside of the Wall Mount - between the Wall Mount and the tiles. Silicone along the bottom edge of the Wall Mount - where the Wall Mount meets the Tiles/Tray/Flooring.
- Page 7 PARTS LIST (RUBBER PART) 7462 BLACK (PLASTIC PARTS) NOT USED WALL MOUNT & TOP BRACKET PARTS KIT 6178 AF 6178 AF No.8 x 32 PAN HEAD SELF TAP SCREW No.8 x 32 PAN HEAD SELF TAP SCREW 1471 A SILVER 1471 A SILVER WALL PLUG WALL PLUG...
- Page 8 Cleaning Instructions Matki Glass Guard allows water to form minute beads which easily trickle off the surface of the glass. This makes the glass easier to clean - the glass does not need to be cleaned as frequently, but it does require occasional maintenance. As less cleaning is required the use of detergents can be minimised thus helping to protect the environment.
