Anker SOLIX F3800 Setup Manual

STEP 1
Unpacking and Positioning your F3800 UPS Portable Power Station
1. Carefully unbox and lift your UPS Portable Power Station from its box. The unit is heavy, handle with care.
2. Choose a suitable location you would like to position the UPS Portable Power Station, ensuring there is at least 200mm of clearance around the unit for
proper ventilation.
3. Once you have positioned the UPS Portable Power Station in your desired location, engage the front wheel brakes by locking them to prevent any
movement.
STEP 2
Turning the Power ON/OFF
Press the ON/OFF button for 3 seconds to turn your power station on or off.
When the "Remaining Battery" indicator shows on the LCD screen, your power station is ready to charge devices.
STEP 3
Connecting the Uninterruptible Power Supply (UPS) Feature
To use the UPS feature, connect your power station to a wall outlet with the AC charging cable, then press the AC outlet button and connect your devices via
the UPS AC outlet ports. With the UPS connection, your devices will be powered via bypass charging.
UPS EQUIP PTY LTD. ABN 62 673 120 137
When powered on, press the DISPLAY button to turn the screen on or off.
The auto-off time can be set in the Anker app.
The power station will power off automatically if the output buttons are turned off and no power loads
are detected for 12 hours. The standby duration can be set in the Anker app.
Version: 1.0 Published: 17.10.2024 Form: F07: V01
F3800|
SETUP GUIDE
Page 1 of 2
