- Page 1 Installation manual Awning Blokhus...
-
Page 2: Icon Overview
Icon overview Use with sun Class by N. of cicles Don’t use with snow 38 Km/h Don’t use with rain Made in Europe Don’t use with hail CE standards Faber installation manual - Blokhus... -
Page 3: Product Parts
Product parts 1. Split view - parts list Wall mount Front slat cover Base box Front slat Descrip�on: Wall mount Side cover Front slat carriage 11 Front slat Base box 12 Front slat carriage Side cover 13 Guide rail Mounting plate Guide rail 4 Mounting plate 14 Inlay... - Page 4 (Picture 3.). Picture 1: Fastening elements - spacer plates, wall fastening www.sunshade-experts.com *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Faber installation manual - Blokhus...
-
Page 5: Installation Instructions
00 mm Min. 500 Max. 1000 mm) Installation instructions o the wall The product should be fixed to the wall, in case of wall irregularities > 5 mm spacing plates of different thickness can be used. wall ckness wall nd the n the ture 3.). - Page 6 4/15 L 1/10 L 4/5 L 1/10 L cassette Picture 4: Spacing of wall elements. outline Marking the places for mounting wall fixings. /2 L 1/2 L 8/10 L 1/10 L cassette Faber installation manual - Blokhus 1/2 L outline...
- Page 7 3. Mount the box on the wall mount Remove the side cover and mount the cradle to the box with the same spacing as Remove the side cover and mount the cradle to the box with the same spacing as the wall mount. the wall mount.
- Page 8 *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Picture 10. Placing the guide rails in the side. www.sunshade-experts.com *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Faber installation manual - Blokhus...
- Page 9 Insert the runners on both sides of the product. 5. Installing the support beam and connecting the LED strip and the electrically c 5. Installing the support beam and connecting the LED strip and the electrically controlled leg. 5. Installing the support beam and connecting the LED strip and the electrically controlled leg. If you have LEDs or electric legs, run the LED/leg power cable through the marked groove in the guide If you have LEDs or electric legs, run the LED/leg power cable through the marked groove in the guide rail.
- Page 10 Check the verticality of the leg with a spirit level and check the product diagonals for smooth operation. V1 = V2 L1 = L2 Then lock the item by tightening the screws in the guide rails and anchor the feet to the ground. Faber installation manual - Blokhus...
- Page 11 In case of Blokhus with LED-light Connect the cables sticking out from the movable leg to those in the guide rail. Cut the cable cap to size and press it into the groove of the guide rails. Check the screws for looseness at the wall mount during installation.
- Page 12 6.3 In case of Matera with an electric leg - the somfy louver control 6.3 In case of Matera with an electric leg - the somfy louver control In case of Blokhus with electric leg 1. determine the mounting location for the controller and power supply on the electrical leg side.
- Page 13 * Remove the insulation from the wires wires in the connectors. (between 9 and 10mm) and tighten the Connect the Blokhus leg actuator to section M1. wires in the connectors. www.sunshade-experts.com - 0VDCV MOTOR - Power (0 VDC0) - black cable, 4.
- Page 14 - The ACN wire (white or blue) of the LED power supply should be connected to the neutral wire (white or blue). Press simultaneously “UP” and “DOWN” of the control point on the selected channel. The leg will make a quick movement in one direction and back again. Faber installation manual - Blokhus...
- Page 15 Control the direction of operation. Press the “UP” button. If the leg open (extends), this means the direction is correct and proceed to the next step. If not proceed to the following step. * If the leg closes, the direction is wrong and you need to press the “MY” button until the powered product moves in one direction and back: The direction of rotation has been changed.
- Page 16 - Press the "UP" button 6.4 In case of Matera with electric leg and LED - driver somfy In case of Blokhus with electric leg and/or LED-light Somfy Louver Control IO-receiver for LED-light 1.
- Page 17 * For Matera with Somfy Louver con common 24V power supply to con Unscrew the hermetic case and connect the appropriate wires to the controller. - 0VDCV - Power (0 VDC0) - black wire with blue wie (B), - +VDC - Power (+24 VDC) - red wire with brown wire (B). 3.Unscrew the hermetic case and connect the appropriate wires to the controller.
- Page 18 Press simultaneously “UP” and “DOWN” of the control point on the selected channel. If the LED light comes on and then goes off go to step 34. If no LED light turns on go to step 35. Faber installation manual - Blokhus...
- Page 19 One LED section lights up and then goes out: Variant 1: Save the control point for this LED section. The LED was programmed correctly. Variant 2: Not for this LED section, save the control point. Press “UP” and “DOWN” simultaneously and repeat until the selected LED section lights up.
- Page 20 Incorrect connection Wiring Inspection Item 3 of the supply lines One/two/three of Incorrect connection the four sections of the LED wires Wiring Inspection Item 3 does not light up to the driver Faber installation manual - Blokhus...
- Page 21 No LED section lighted Battery change Observations remote control Cause Solution up during setup. Incorrect connection Tips and advice during installation Incorrect controller Perform all steps in the Wiring Inspection Item 3 of the supply lines con guration instructions again Tips and advice during installation Incorrect connection Low battery in the...
- Page 22 After cut the strips remove it from front slat. Reassemble and screw together again the front slat with cover. Remove the sticker from front slat cover. After the assembly is complete make a trial run. Faber installation manual - Blokhus...
- Page 23 Check the tension of the sheating, check the guide rails for tension and proper working (no falling off the guide wheels), check if the locks of the covering are guided in the Inlay. Basic notes on assembly and installation: - Assembly and installation should be done by - If the awning is to be installed in windy areas trained personnel.
-
Page 24: Information To The User
The drop leg option is only used to flush any standingwater on the sheating, after the water is flushed you must raise the leg to the initial setting. Do not modify the structure without consulting the manufacturer, the element properly installed is made in accordance with the instructions. Faber installation manual - Blokhus... - Page 25 During opening or closing the product, ensure that there are no obstacles in the way. Any failure of the product to function properly during use, if any repair is required, please contact your installer. Do not lean on the legs or attach anything to the product. Steer the product only when you have it in your field of vision.
- Page 26 Do a full leg movement, check that the product exits and retracts correctly. Check the operation of the LEDs with the remote control. Remove the front slat flap and check that springs and components are in the right place. Faber installation manual - Blokhus...
- Page 27 Short Check for loose connecting elements. To properly tension the cables on your Blokhus product, follow the step-by-step instructions. Do not perform the operation by yourself and observe the safety precautions. Assembly parts and tools must be kept out of reach of children or persons not involved in the assembly.
- Page 28 Max. length Check if the springs have the correct length. free length Maximum length Free length Kind of Free spring Maximum spring length (cm) length (cm) Long Short Faber installation manual - Blokhus...
- Page 29 If the cables are correctly tensioned, install and tighten the flap. Make a test run to check that the product is working correctly. IMPORTANT SAFETY INSTRUCTIONS. The system has powerful springs inside it. In the event of poor installation, these may cause the awning to open sharply. If any irregularities are observed during opening and/or closing, call a professional installer.
- Page 30 If you would like more information and/or you are having problems, please contact the dealer where you bought your Faber product. All rights reserved. Unauthorised copying is prohibited. Technical data subject to change without notice. No rights can be derived from copy, text pertaining to illustrations or samples. Subject to changes in materials, parts, compositions, designs, versions, colours etc., even without notice.
