Summary of Contents for Kohler K-3901-NPR-0
- Page 1 Installation Guide Premium Remote Control K-7420 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1” 1197249-2-A...
- Page 2 This device must not be co-located or operated in conjunction with any other antenna or transmitter. CANADA IC: 4554A-KOHLER005 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 1197249-2-A Kohler Co.
-
Page 3: Tools And Materials
NOTE: The remote control connects to the docking station magnetically. Carefully inspect the remote control and docking station for damage. Confirm all the listed components are packed. Remote Control Box Contents Docking Station Remote Control Docking Station Power Cord Kohler Co. 1197249-2-A... - Page 4 Before You Begin (cont.) FM External Antenna AUX In Audio Cord 1197249-2-A Kohler Co.
- Page 5 Make sure all installations adhere to applicable codes and standards. NOTE: The remote docking station is equipped with a 15’ (4.5 m) power cord. The station mounting location shown for the docking station is ADA compliant. Kohler Co. 1197249-2-A...
-
Page 6: Install The Power Cord
If the finished wall is installed, drill a 3/8″ (10 mm) hole in the wall behind the toilet location for the power cord. If the power cord is routed through the wall, route the power cord to the docking station location from the toilet end. 1197249-2-A Kohler Co. - Page 7 When the cord is routed externally along the face of the wall, use the bottom cord opening. For installations using the back cord opening, route the power cord through the back cord opening. Kohler Co. 1197249-2-A...
- Page 8 Mark the screw locations using the rear plate as a template. Drill appropriate size mounting holes at the screw mounting locations. The size of the hole will depend on the need for wall anchors, wall material, and installation requirements. Install wall anchors in the holes if needed. 1197249-2-A Kohler Co.
-
Page 9: Connect The Power Cord
NOTE: There is a wiring schematic on the inside of the docking station. Refer to the schematic when attaching the wires. Slide the bare ends of the wires into the correct ports (as shown) and tighten each screw to secure the wires in place. Kohler Co. 1197249-2-A... -
Page 10: Complete The Installation
30 minutes before it will be functional. Position the remote control on the docking station. It attaches magnetically. After the toilet is installed, pair the remote control with the toilet following the instructions in the toilet installation guide. 1197249-2-A Kohler Co.
