NTense 8141872COM Instruction Booklet

Floating tv stand
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

8141872COM
Floating TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B348141872COM 00KX
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8141872COM and is the answer not in the manual?

Questions and answers

Related Manuals for NTense 8141872COM

Summary of Contents for NTense 8141872COM

  • Page 1 8141872COM Floating TV Stand B348141872COM 00KX Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.

  • Page 2: Helpful Hints

    Contact Us! Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 1.5 HOUR ameriwoodhome.com...

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not Actual Size ameriwoodhome.com...
  • Page 5 Board Identification Not Actual Size ameriwoodhome.com...
  • Page 6 Board Identification Not Actual Size ameriwoodhome.com...

  • Page 7: Part List

    Part List Actual Size Ø8X30mm Ø4X30mm × 20 × 6 Ø5/16"X19mm Ø3X12mm × 12 × 6 Ø5X100mm × 4 ameriwoodhome.com...
  • Page 8 Part List Not Actual Size Ø15X12 mm Ø20 × 6 × 18 × 6 × 8 × 1 × 1 × 1 x 16 ameriwoodhome.com...
  • Page 9 STEP 1 1.1 Attach (3) to (H), (G) as illustrated. ameriwoodhome.com...
  • Page 10 STEP 2 Ø8X30mm × 20 2.1 Use one drop glue on the dowel hole. 2.2 Attach (1) to (A), (B) , (C), (I) as illustrated. 2.3 Attach (3) to (A), (B) as illustrated. ameriwoodhome.com...
  • Page 11 STEP 3 Ø3X12mm × 12 × 6 3.1 Attach part (K) to (G) with (4) and (10) as shown. ameriwoodhome.com...
  • Page 12 STEP 4 Ø15X12 mm × 4 4.1 Attach (I) to (B), (A) with (7) as illustrated. ameriwoodhome.com...
  • Page 13 STEP 5 Ø15X12 mm Ø20 × 2 × 2 5.1 Attach part (C) to (G) with (7) as illustrated. 5.2 Use (8) to cover cam lock holes as illustrated. ameriwoodhome.com...
  • Page 14 STEP 6 Ø15X12 mm Ø20 × 8 × 4 6.1 Attach part (A) ,(I), (B) to (G) with (7) as illustrated. 6.2 Use (8) to cover cam lock holes at front as illustrated. ameriwoodhome.com...
  • Page 15 STEP 7 Ø4X30mm Ø15X12 mm × 6 × 4 7.1 Insert (F) to rail on (G) as illustrated. 7.2 Attach (H) to (A), (B), (C), (I) with (2) and (7) as illustrated. ameriwoodhome.com...
  • Page 16 STEP 8 Ø5/16"X19mm × 6 × 1 8.1 Attach part (L) to (I) with (5) and (12) as illustrated. ameriwoodhome.com...
  • Page 17 STEP 9 Ø5X100mm × 4 IMPORTANT: THIS UNIT MUST BE SECURED TO THE WALL STUDS. 9.1 Locate stud in the wall. Place metal strip (J) against the wall at desired height. Drive the screw (6) through the pilot hole on (J) into the wall stud as illustrated. ameriwoodhome.com...
  • Page 18 STEP 10 IMPORTANT: TWO PEOPLE ARE REQUIRED FOR THIS ASSEMBLY STEP. 10.1 Place the entire TV cabinet on the metal strip (J) that has been fixed to the wall as shown in the figure. ameriwoodhome.com...
  • Page 19 STEP 11 × 8 11.1 Insert (9) to (A), (B) ,(C) as illustrated. ameriwoodhome.com...
  • Page 20 STEP 12 x 16 12.1 Insert (13) to (E) as illustrated. 12.2 Attach (D) to (E) with as illustrated. ameriwoodhome.com...
  • Page 21 STEP 13 × 1 WARNING ameriwoodhome.com...
  • Page 22 STEP 14 This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Notice: Please apply the TV warning label to your unit so you'll always have the model's weight and TV size limits.
  • Page 23 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
  • Page 24 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 25 Español Página 9 1.1 Conecte (3) a (H), (G) como se ilustra. Página 10 2.1 Use una gota de pegamento en el orificio de la clavija. 2.2 Adjunte (1) a (A), (B), (C), (I) como se ilustra. 2.3 Conecte (3) a (A), (B) como se ilustra. Página 11 3.1 Conecte la pieza (K) a (G) con (4) y (10) como se muestra.
  • Page 26 Español Página 18 IMPORTANTE: SE NECESITAN DOS PERSONAS PARA ESTE PASO DE MONTAJE. 10.1 Coloque todo el mueble de TV sobre la tira de metal (J) que se ha fijado a la pared como se muestra en la figura. Página 19 11.1 Inserte (9) en (A), (B), (C) como se ilustra.
  • Page 27 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
  • Page 28 Français Page 9 1.1 Fixez (3) à (H), (G) comme illustré. Page 10 2.1 Utilisez une goutte de colle sur le trou du goujon. 2.2 Fixez (1) à (A), (B) , (C), (I) comme illustré. 2.3 Fixez (3) à (A), (B) comme illustré. Page 11 3.1 Fixez la partie (K) à...

  • Page 29: Charge Maximale

    Français Page 18 IMPORTANT : DEUX PERSONNES SONT NÉCESSAIRES POUR CETTE ÉTAPE D'ASSEMBLAGE. 10.1 Placez l'ensemble du meuble TV sur la bande métallique (J) qui a été fixée au mur comme indiqué sur la figure. Page 19 11.1 Insérez (9) à (A), (B) , (C) comme illustré. Page 20 12.1 Insérez (13) à...
