- Page 1 MONSIEUR TRICOT STANDING LAMP WIRED User manual English US Version 7 - 02-2025...
-
Page 3: Table Of Contents
CONTENTS Contents Product overview standing lamps wired Introduction Parts list The story of Monsieur Tricot Specifications Power source specifications Collection overview Installation Safety instructions Check the contents of the package Connecting the LED light Intended use Operating the lamp with the button... -
Page 4: Introduction
Monsieur Tricot is his first creation, a family of in- and outdoor lamps, knitted or hand-crocheted with an innovative, weatherproof yarn. The sphere shaped lights give a warm glow and the different patterns cast beautiful shadows. The knitting and crocheting is done in Belgium by a network of artisans and every item is checked by Ilia and his mother. -
Page 5: Collection Overview
Madame Latoque dia 30 cm dia 40 cm dia 60 cm dia 30 cm dia 40 cm D081130S D081140S D081160S D081230S D081240S Madame Cachet dia 30 cm dia 40 cm dia 50 cm D081330S D081340S D081350S Monsieur Tricot collection • User manual... - Page 6 Monsieur Lebonnet Madame Latoque dia 30 cm dia 40 cm dia 30 cm dia 40 cm dia 60 cm D080230H D080240H D080130H D080140H D080160H Madame Cachet Monsieur Ellipse dia 30 cm dia 40 cm dia 50 cm dia 40 cm D080330H D080340H D080350H...
-
Page 7: Safety Instructions
Do not unscrew the screws of the product and never open the product to avoid dagage. STANDING LAMPS WIRED ⚠ Keep the power source away from water sources. ⚠ The power cable can be placed underground if a protective sheath that provides extra protection is provided. Monsieur Tricot collection • User manual... -
Page 8: Intended Use
INTENDED USE The product is only intended as indoor or outdoor LED lighting. Any change to the product can have consequences for safety, warranty and correct operation. DISCLAIMER Designs and specifications are subject to change without notice. All logos, brands and product names are trademarks or registered trademarks of their respective owners and are hereby recognised as such RECYCLING... -
Page 9: Compliance
COMPLIANCE Monsieur Tricot complies with Low Voltage, EMC, Ecodesign and RoHS directives. FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device must not cause harmful interference, and (2) the user must accept any interference received, including interference that may cause undesired operation. - Page 10 Pour maintenir la conformité aux directives d’exposition aux radiofréquences, cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. Standing lamp Wired Monsieur Tricot...
-
Page 11: Product Overview Standing Lamps Wired
PRODUCT OVERVIEW STANDING LAMPS WIRED PARTS LIST Base Protective cover power source Sphere Extension cord for power source Removeable cover Power source with plug Protective cover screws Monsieur Tricot collection • User manual... -
Page 12: Specifications
SPECIFICATIONS Power 2.5W Light source LED lamp (non-replaceable) Voltage 9-12.6V Wattage 2.5W-3W Light source lifetime 30.000 hrs On/off cycles ≥ 10.000 Starting time Within 1 second Warm-up time to 60% of Immediate full light output the full light output Light source dimensions 178 x 85 mm Luminous flux 166-200 Lumen... -
Page 13: Installation
Connect the adapter to a wall socket and the lamp. Optional: Unscrew the power source housing to attach the power source to a surface. ⚠ Never attach the power source in a location where it could become submerged in water. Monsieur Tricot collection • User manual... -
Page 14: Operating The Lamp With The Button
OPERATING THE LAMP WITH THE BUTTON Every Monsieur Tricot standing lamp has a physical button on the base. When pressing the button you can toggle between different levels of brightness. 33 % brightness 66 % brightness 100 % brightness 0 % brightness (OFF) -
Page 15: Maintenance
MAINTENANCE CLEANING THE COVER Turn the sphere clockwise until it is free of the bayonet catch. Remove the sphere. Loosen the elastic band of the removable cover. Monsieur Tricot collection • User manual... - Page 16 Pull the cover off the sphere. Wash at 40ºC (104ºF) with a pH-neutral washing agent. ⚠ Do not tumble dry the cover. Use a clean, microfibre cloth, lukewarm/warm water and a pH-neutral wash- ing agent to clean the sphere. Pull the cover back over the sphere.
- Page 17 Tighten the elastic band to create a loop. Twist and pull the loop over the rim of the sphere. Monsieur Tricot collection • User manual...
- Page 18 10. Place the sphere in the bayonet catch. 11. Turn the sphere counterclockwise until it is fastened.
-
Page 19: Notes
NOTES Monsieur Tricot collection • User manual... - Page 20 Produced by: TRIBÙ Oude Heidestraat 72 3740 Bilzen België www.tribu.com...
