- Page 1 MONSIEUR TRICOT User manual English Version 1.0 issued on 11-06-2019 Monsieur_Tricot_User_Manual_V2.indd 1 Monsieur_Tricot_User_Manual_V2.indd 1 15/09/2020 15:17:50 15/09/2020 15:17:50...
- Page 2 MONSIEUR TRICOT Preface The story of Monsieur Tricot Collection overview Intended use Safety instructions STANDING Product overview standing Parts list Specifications Adapter specifications Accessories Monsieur_Tricot_User_Manual_V2.indd 2 Monsieur_Tricot_User_Manual_V2.indd 2 15/09/2020 15:17:50 15/09/2020 15:17:50...
- Page 3 Installation Check the content of the package Charging the led light Installation of the Casambi app Making connection with the lamp(s) Change the lamp profile Create a group Switching the lamp(s) on and off Dimming lamp(s) and groups Gallery Create a scene Set a timer Wireless remote Product overview...
- Page 4 PREFACE Congratulations on the purchase of your Monsieur Tricot lamp. Its warm glow and hand-crocheted or knitted fabric will cast beautiful shadows as a magical backdrop for long, cosy summer nights. The Monsieur Tricot hanging and standing objects form a complete family of lights – you can read their story below. This user manual contains all the necessary information for a correct, efficient and safe use of your lamp.
- Page 5 COLLECTION OVERVIEW Monsieur Lebonnet Madame Latoque dia 30cm dia 40cm dia 60cm dia 30cm dia 40cm 080130S 080140S 080160S 080230S 080240S Madame Cachet dia 30cm dia 40cm dia 50cm 080330S 080340S 080350S 00-White 10-Linen 89-Wengé 60-Brick 30-Moss Wireless Switch 08010 Monsieur Tricot collection •...
-
Page 6: Intended Use
INTENDED USE The product is only intended as in- or outdoor led lighting. Any change to the product can have consequences for safety, warranty and correct operation. SAFETY INSTRUCTIONS Only use the product as described in this manual. Do not use a damaged product. Do not drop the product and avoid bumping. -
Page 7: Parts List
PRODUCT OVERVIEW STANDING PARTS LIST Base Lamp lid Strain relief Charging port Allen screw LED light Lamp holder Sphere Countersunk head screw Removable cover Monsieur Tricot collection • User manual Monsieur_Tricot_User_Manual_V2.indd 19 Monsieur_Tricot_User_Manual_V2.indd 19 15/09/2020 15:17:56 15/09/2020 15:17:56... -
Page 8: Adapter Specifications
SPECIFICATIONS Power Light source Dimmable LED included Voltage Wattage 3.5W (+15.6W when charging) Average lifetime ≥ 5000 hrs Cycles on/off ≥ 45000 Starting time Within 1 sec Warm-up time to 60% of Immediately full light output the full light output Light source dimensions 178 x 85 mm Luminous flux... -
Page 9: Installation
INSTALLATION CHECK THE CONTENT OF THE PACKAGE Check if all parts from the parts list are present and that no damage is visible on the parts. In case parts are missing or damaged, please contact your local Tribù dealer. CHARGING THE LED LIGHT Plug in the adapter. - Page 10 MAKING CONNECTION WITH THE LAMP(S) Tap ‘Nearby devices’. All light sources supported by the Casambi app are shown. Select a lamp. Tap ‘Identify lamp’ to check which lamp is activated. The lamp will start blink- ing. Tap ‘Add to…’. The existing networks are shown. When you use the Casambi app for the first time it will automatically create a network that can only be accessed with the device that has created this network.
-
Page 11: Create A Group
CHANGE THE LAMP PROFILE In the ‘Lamps’ tab, double tap a lamp. Under ‘Information’ you can change the name of the lamp and give it an icon. Under ‘Start status for activation’ you can select the ‘Standard mode’ and ‘Last status’. In the ‘Standard mode’... - Page 12 Tap ‘All lamps’ to switch on all lamps. Tap again to switch off all lamps. DIMMING LAMP(S) AND GROUPS Go to the ‘Lamps’ tab. Touch and hold any lamp or group on the screen and move your finger to the left or right to determine the dimming percentage. Open a group by double tapping it.
-
Page 13: Create A Scene
CREATE A SCENE The ‘Scenes” tab allows you to save different scenes. Set up your lamps to the desired intensity. Tap the ‘Scenes’ tab. Tap ‘Edit’ in the top right corner. Tap the plus icon in the top left corner. Enter a scene name. -
Page 14: Wireless Remote
WIRELESS REMOTE PRODUCT OVERVIEW The wireless remote is a wall control button that you can use to easily control your lamp(s). Preset button 1 Preset button 3 Multi-purpose button 1 Multi-purpose button 2 Preset button 2 Preset button 4 Dim up Dim down Monsieur_Tricot_User_Manual_V2.indd 26 Monsieur_Tricot_User_Manual_V2.indd 26... -
Page 15: Adding Scenes
INSTALLATION Open the Casambi app on your phone. Tap ‘Nearby devices’ and select the Casambi Express. Make sure that the Casambi Express is active by pressing two buttons simultaneously. Tap ‘Add to…’. The existing networks are shown. Select the desired network. The Casambi Express is connected to the network. -
Page 16: Maintenance
MAINTENANCE REPLACING THE LIGHT SOURCE Turn the sphere counter clockwise until it is free of the bayonet catch. Remove the sphere. Loosen the countersunk head screws of the lamp holder. Remove the lamp holder. Monsieur_Tricot_User_Manual_V2.indd 28 Monsieur_Tricot_User_Manual_V2.indd 28 15/09/2020 15:17:57 15/09/2020 15:17:57... - Page 17 Loosen the Allen screws of the strain relief. Turn the lamp lid counter clockwise to remove the lamp holder. Replace the LED light with a new LED light. Monsieur Tricot collection • User manual Monsieur_Tricot_User_Manual_V2.indd 29 Monsieur_Tricot_User_Manual_V2.indd 29 15/09/2020 15:17:58 15/09/2020 15:17:58...
- Page 18 Fasten the lamp holder by turning the lamp lid on to the LED light. Place the charging port on the strain relief. Make sure to point the white marking on the charging port upwards. 10. Fasten the Allen screws of the strain relief. Monsieur_Tricot_User_Manual_V2.indd 30 Monsieur_Tricot_User_Manual_V2.indd 30 15/09/2020 15:17:58...
- Page 19 11. Place the lamp holder. Make sure to place the lamp holder correctly by using the bayonet catch. 12. Fasten the countersunk head screws of the lamp holder. Monsieur Tricot collection • User manual Monsieur_Tricot_User_Manual_V2.indd 31 Monsieur_Tricot_User_Manual_V2.indd 31 15/09/2020 15:17:58 15/09/2020 15:17:58...
- Page 20 13. Place the sphere in the bayonet catch. 14. Turn the sphere clockwise until it is fastened. 15. Test whether the lamp is functioning properly. Monsieur_Tricot_User_Manual_V2.indd 32 Monsieur_Tricot_User_Manual_V2.indd 32 15/09/2020 15:17:58 15/09/2020 15:17:58...
-
Page 21: Cleaning The Cover
CLEANING THE COVER Turn the sphere counter clockwise until it is free of the bayonet catch. Remove the sphere. Loosen the elastic band of the removable cover. Monsieur Tricot collection • User manual Monsieur_Tricot_User_Manual_V2.indd 33 Monsieur_Tricot_User_Manual_V2.indd 33 15/09/2020 15:17:59 15/09/2020 15:17:59...
