Garmin GMR Fantom 18 Field Service Manual

GMR Fantom™ 18/18x/24/24x
Field Service Manual
The GMR Fantom 18/18x/24/24x radar generates and transmits non-ionizing
radiation. The radar must be turned off before approaching the scanner for
service. Avoid looking directly at the scanner while it is transmitting, as the
eyes are the most sensitive part of the body to electromagnetic radiation.
Failure to properly turn off the radar may expose the service technician to
harmful electromagnetic radiation that can result in personal injury or death.
The GMR Fantom 18/18x/24/24x radar contains high voltages. The scanner
must be turned off before the covers are removed. While servicing the unit, be
aware high voltages are present and take the necessary precautions. The high
voltages in the scanner can take some time to decay. Failure to adhere to this
warning can result in personal injury or death.
Repairing and performing maintenance on Garmin electronics is complex
work that can result in serious personal injury or product damage if not done
correctly.
Garmin is not responsible for, and does not warrant, the work that you or a
non-authorized repair provider perform on your product.
Important Information Regarding Field Service of the
GMR Fantom 18/18x/24/24x Radar
• Before you install or service the radar, ensure that the system software is
up to date. For instructions on updating your Garmin chartplotter software,
see your chartplotter owner's manual at support.garmin.com. Proceed with
servicing the radar only if the software update does not resolve the issue.
• Record the serial number of your radar. You will need the serial number
when you order replacement parts.
Contacting Garmin Product Support
Replacement parts are available only through Garmin Product Support.
• For dealer specific support, call 1-866-418-9438
• Go to support.garmin.com.
• In the USA, call (913) 397.8200 or (800) 800.1020.
• In the UK, call 0808 2380000.
• In Europe, call +44 (0) 870.8501241.
Getting Started
Tools Needed
• Screwdrivers
◦ #2 Phillips
◦ 5 mm hex
• Digital multimeter (volt/ohm meter)
• Compatible chartplotter
• 10 to 32 Vdc power supply
• High viscosity, electronics-compatible RTV compound
Radar Software Update
You must update the Garmin chartplotter software when you install this device.
For instructions on updating the software, see your chartplotter owner's
manual at support.garmin.com.
Before using this manual to troubleshoot a problem, ensure all Garmin devices
on the boat are operating on the latest-released software version. Software
updates may resolve the problem.
GMR Fantom 18/18x/24/24x Field Service Manual
WARNING
 
NOTICE

Table of Contents

Getting Started ������������������������������������������������������������������������������������
Tools Needed .....................................................................................................1
Radar Software Update .....................................................................................1
Troubleshooting ���������������������������������������������������������������������������������
Radar Satus LED ...............................................................................................2
Error Codes and Messages ...............................................................................2
1003 - Hardware FPGA Program
1004 - Input Voltage Low .............................................................................2
1005 - Input Voltage High ............................................................................2
1013 - High System Temperature
1019 - Spin Up Time Out, Speed Did Not Reach Specified RPMs
1025 - Transmit Speed Lost, Could Not Maintain Rotation Speed
Major Component Locations �������������������������������������������������������������
Notes ...........................................................................................................6
Radar Disassembly ����������������������������������������������������������������������������
Removing the Dome ..........................................................................................7
Reinstalling the Dome .......................................................................................7
Removing the Antenna ......................................................................................7
Reinstalling the Antenna ....................................................................................7
Replacing the Fan .............................................................................................8
Removing the Fan Cover and
Reinstalling the Fan .....................................................................................8
Replacing the Motor ..........................................................................................8
Removing the Electronics Box
Reinstalling the Electronics Box
Connector Locations ��������������������������������������������������������������������������
Electronics Box ..................................................................................................9
Antenna Position Sensor PCB ...........................................................................9
Replaceable Service Parts ���������������������������������������������������������������
Replaceable Cables ........................................................................................10
Replaceable Service Parts ���������������������������������������������������������������
Replaceable Components ...............................................................................11
Fault........................................................2
................................................................2
Fan...............................................................8
.....................................................................8
..................................................................8
1
2
..............3
6
7
9
10
11
