- Page 1 O W N E R S H A N D B O O K...
-
Page 2: Table Of Contents
OPERATING INSTRUCTIONS Operating the ramp and access Maintenance Seating positions Addendum Tip and fold seats Wiring diagrams Wheelchair restraints WAV TechnIcal Specification Securing the wheelchair Alighting the vehicle After Sales Support Wheelchair occupant seatbelt Tyre inflator Winch This handbook is to be used in conjunction with the manufacturers original handbook and safety !MPORTANT information and operator instructions for any equipment as per the specification of your vehicle. -
Page 3: Operating The Ramp And Access
P EU GEOT T RAVELLE R T UR IN | OPERATING THE RAMP 1. Ensure there is sufficient access space behind the vehicle to open the tailgate and operate the ramp. 2. With your hand at the top of the ramp, push it MOVE THE YELLOW towards the front of the vehicle to release the LEVER FROM RIGHT... -
Page 4: Seating Positions
P E UG E OT TR AV E L L E R T UR I N SEATING POSITIONS WHEELCHAIR OCCUPANT SECURELY IN PLACE WITH RESTRAINTS AND BELT WHEELCHAIR OCCUPANT IN THE UP-FRONT POSITION... -
Page 5: Tip And Fold Seats
P E U GEOT T R AV EL LE R TU R I N | OPTIONAL REAR TIP AND FOLD SEATS 1. To unfold the seat press down on the coloured footplate located at the base of the chair until it clicks. -
Page 6: Wheelchair Restraints
P EUG EOT TRAVELLER T URIN WHEELCHAIR RESTRAINTS 1. Slot the removable Q-Straint/Unwin retractable system into the floor anchor until it is securely in place. (See figure 1) 2. Push down the coloured lever, this will allow for the extendable belt to be released. (See figure 2) 3. -
Page 7: Securing The Wheelchair
P EU GEOT T R AV EL LE R TU R IN | SECURING THE WHEELCHAIR 1. Position the wheelchair at the foot of the ramp and CONNECT AND ADJUST apply the brakes. THE REAR RESTRAINTS 2. Switch on the electric reels by pressing the button by the rear tailgate. -
Page 8: Alighting The Vehicle
PE U G E OT TRAV E LL E R T URI N ALIGHTING THE VEHICLE 1. Switch on the electric reels. 2. Remove the rear restraints. 3. Move the wheelchair forwards slightly (e.g 2-3”, 5-7cm). This will release the safety latches. Guide the wheelchair carefully down the ramp. -
Page 9: Wheelchair Occupant Seatbelt
P E U GEOT T R AV E LL E R T UR I N | WHEELCHAIR OCCUPANT BELT 1. Extend, adjust and secure the wheelchair occupants belt taking care that the shoulder belt fits correctly over the shoulder. 2. Ensure the lap belt is positioned across pelvis and not over the wheelchair frame. -
Page 10: Tyre Inflator
PEUG EOT TRAVELLE R T URIN TYRE INFLATOR Your Peugeot comes with a tyre inflator which you will find under the front seat. Information about using the ContiComfortKit can be found in the ContiComfortKit manual which comes with the vehicle. Instructions to use the tyre inflator can be found at www.conticomfortkit.co.uk... -
Page 11: Winch
P E U G EOT TR AVELLER T UR I N | OPTIONAL WINCH 1. Remove rear wheelchair restraints 2. Switch on electric reels 3. Moving the wheelchair forward slightly (2-3”, 5-7cm) will release the reel safety lock 4. Guide the wheelchair down the ramp keeping the winch strap in tension. -
Page 12: Maintenance
P E UG E OT TR AV E L L E R T UR IN MAINTENANCE If your WAV has been purchased VAT exempt, all e.g wheelchair restraints, wheelchair occupant belt, subsequent repairs, maintenance and parts relating to electric winch, parts of the exhaust system and rear that vehicle may be VAT free and an exemption form ramp. -
Page 13: Type Approval
P EU G EOT TR AVELLER T URI N | ADDENDUM FUSES USED IN THE CONVERSION: TYPE APPROVAL: DEVICE FUSE LOCATION Electric reels Connected to the TYPE OF WAV: battery under the The Peugeot Expert TRAVELLER is categorised as an AWAV bonnet (Assisted wheelchair access vehicle) HOW TO SOURCE PARTS:... -
Page 14: Wiring Diagrams
PE U G E OT TRAV E L L ER T URI N WIRING DIAGRAMS Wiring Diagram B-Pillar side load door Loom to be located N/S B-Pillar and cable run in N/S foot well . Plastic Trim Drill BulkHead 12mm Hole. Tape 7mm Conduit 4.8 Terminals... -
Page 15: Wav Technical Specification
P EU G EOT T R AV E LL E R T U R I N | WAV TECH SPECIFICATION WHEELCHAIR ACCESS ENTRANCE DIMENSIONS Width (mm) Height (mm) 1370 DESIGNATED TRAVELLING POSITION Variant 1 Variant 2 Width (mm) Length (mm) 1215 1260 Height (mm) - Page 16 PE UG EOT TRAV ELLER T URIN WAV TECH SPECIFICATION Max permitted front axle weight (kg) 1500 Max permitted rear axle weight (kg) 1500 Gross vehicle weight (GVW) 2740 Kerb weight (kg) 2296 Fuel tank capacity (litres) Ground clearance (mm) SEATING PROVISIONS Variant 1 Variant 2...
-
Page 17: Faq
P EU G EOT T R AV EL L E R T UR I N | FAQ When trying to exit the vehicle the straps do not release. Ensure that the switch for the electric reels is on and the red LED lights up. -
Page 18: After Sales Support
PE U G E OT TRAV E L L ER T URI N AFTER SALES SUPPORT If you are considering upgrading your vehicle then please talk to one of our Mobility Advisors about the possibility of part exchanging your old vehicle for a new model. Alternatively, if you are considering selling WARRANTY AND BREAKDOWN your vehicle please get in touch as we may be... - Page 19 P E UG E OT T U R I N | SEC- GET IN TOUCH t: 01626 853050 e: sales@gmmobility.co.uk w: www.gmmobility.co.uk Every endeavour has been made to ensure that the information and details contained in this brochure were accurate at the time of going to press January 2020. However the company reserves the right, whilst preserving the essential characteristics of the models described, to introduce at any time modifications, changes of details, equipment or accessories.
