Summary of Contents for GM MOBILITY PEUGEOT BOXER UTAH

  • Page 1 O W N E R S H A N D B O O K...

  • Page 2: Table Of Contents

    OPERATING INSTRUCTIONS OPTIONAL EXTRAS Operating the lift Warranty terms Securing the restraints Addendum Fastening the wheelchair WIrIng dIagrams Wheelchair occupant seatbelt After sales support Removable rear seats ServIce and maIntenance PAS 2012...

  • Page 3: Operating The Lift

    OPERATING THE LIFT P EU G EOT BOX ER UTAH | 1. Ensure there is sufficient access space behind the vehicle to open the rear doors and operate the lift. 2. Open the rear doors. 3. Flick the chrome toggle switch, located on the lift, to the ON position.
  • Page 4 OPERATING THE LIFT | P E UG E OT B OXE R UTA H 6. Position the wheelchair centrally on the lift and Release the brakes on the wheelchair and move it apply the brakes. (See figure 4) inside the vehicle and fully off the lift. 7.

  • Page 5: Securing The Restraints

    SECURING THE RESTRAINTS P EU GE OT B OXE R UTA H | 1. Align the circular fixings of the restraint with the circular holes in the tracking floor. 2. Push down and the coloured plastic section will lift up. This indicates that the fixings have aligned. 3.

  • Page 6: Fastening The Wheelchair

    FASTENING THE WHEELCHAIR | PEU GE OT BOX ER UTAH 1. Position the wheelchair in the desired location, wheelchair back to ensure they are tight. Then attach centrally to the tracking system and apply the and secure the rear restraints, ensuring all four points brakes.
  • Page 7 FASTENING THE WHEELCHAIR - ALTERNATIVE P EU GE OT B OXE R UTA H | 1. Slide the restraint over the floor fastener to towards the wheelchair until the extendable belt is secure the restraint. ( See Figure 1) tight. This will fully secure the wheelchair. 2.

  • Page 8: Wheelchair Occupant Seatbelt

    WHEELCHAIR OCCUPANT SEATBELT | PE U G E OT B OXE R UTAH 1. Secure the 3 point restraint in the tracking system to the side of the wheelchair. ( See Figure 1) 2. Secure the floor mounted socket on the opposite side of the wheelchair to the restraint.
  • Page 9 OPTIONAL EXTRAS This section features the most popular optional extras. The majority of optional extras will come supplied with a manufacturers product manual. This section is designed to be a brief summary. For full details please refer to manufacturers product manual.

  • Page 10: Removable Rear Seats

    REMOVABLE REAR SALOON SEAT | P E UG E OT BOX E R UTA H 1. To move the rear saloon seat twist the handle on top of the floor fixing anti-clockwise. (See figure 1) 2. Then pull the handle up and rotate it 90 degrees. This will retain LIFT AND it in the ‘up’...
  • Page 11 WARRANTY P EU G EOT BOX ER UTAH | GM Coachwork undertakes that each new conversion for wheelchair access including all accessories supplied by GM Coachwork in the manufacture of each wheelchair accessible conversion (excluding the original manufacturer’s base vehicle) will be free from defect in material or workmanship under normal use and service.
  • Page 12 WARRANTY | P E UG E OT B OXE R UTA H to be defective. This warranty is not transferrable covered by the conversion warranty. Items covered should the original purchaser sell the car within by warranty (if fitted during the manufacture of the the three years.

  • Page 13: Addendum

    P EU G EOT BOX ER UTAH | FUSES USED IN THE CONVERSION: TYPE OF WAV: DEVICE FUSE LOCATION The Peugeot Boxer UTAH is categorised as an AWAV (Assisted wheelchair access vehicle) Electric 100A Fuse located on wheelchair lift the slam panel...

  • Page 14: Wiring Diagrams

    WIRING DIAGRAMS | P E UG E OT B OXE R UTA H...

  • Page 15: After Sales Support

    AFTER SALES SUPPORT P EU GE OT B OXE R UTA H | If you are considering upgrading your vehicle then please talk to one of our Mobility Advisors about the possibility of part exchanging your old vehicle for a new model. Alternatively, if you are considering selling WARRANTY AND BREAKDOWN your vehicle please get in touch as we may be...

  • Page 16: Service And Maintenance

    SERVICE & MAINTENANCE | PEUG EOT BOX ER UTA H If your WAV has been purchased VAT exempt, all vehicle are specially made for our converted vehicles, subsequent repairs, maintenance and parts relating to e.g wheelchair restraints, wheelchair occupant belt, that vehicle may be VAT free and an exemption form electric winch, parts of the exhaust system and rear must be completed in each case.

  • Page 17: Pas 2012

    PAS 2012 P EU GE OT B OXE R UTA H | FEATURE PARAMETER VALUE Wheelchair access entrance Width (mm) Height (mm) 1464 Designated travelling position Central location width (mm) Offset location width (mm) 1230 Length (mm) 1113-2230 Wheelchair space gradient (degrees) Wheelchair occupant maximum seated eyeline height (mm) 1434 Internal roof height (mm)
  • Page 18 GET IN TOUCH VW CAD DY | SECTION t: 01626 244090 e: service@gmcoachwork.co.uk w: www.gmcoachwork.co.uk Every endeavour has been made to ensure that the information and details contained in this brochure were accurate at the time of going to press November 2021. However the company reserves the right, whilst preserving the essential characteristics of the models described, to introduce at any time modifications, changes of details, equipment or accessories.
