VADI VH-220 Manual

VH-220
Bacteria Filter Heater
Made In Taiwan
2021.12.23 VA-1-VH-220-EN.MDR_01
2. Intended Use
The heater is intended to use for heating the expiratory
filter to prevent the condensation accumulated in the
filter when exhalation gas passes the filter.
Symbols Glossary
Symbol Title and Meaning
Use-by date
Manufacturer
Date of manufacture Protective earth
Consult instructions for use
Caution
MD Medical device
Fragile, handle with care
Temperature limit
Keep dry
Storage Humidity limitation
Use no hooks
Batch code
Handle with care
Catalogue number
CE Mark
2460
Unique device identifier
UDI
EU Authorized Representative
Switzerland Authorized
CH
Representative
Serial number
SN
-2-
Table of Content
1.General Information
2.Intended Use
........................................P.3
3.Principle
4.Specification
5.Optional Accessories
6.Use Instruction
7.Disposition
...........................................P.9
8.Clean
9.Warnings
2460
10.Cautions
3. Principle
The heater takes advantage of heating to prevent water
condensation in filter and decreased gas flow
resistance. When the filter is kept warm and dry, it will
continue to work efficiently according to specification. A
water trap can be used below the device to collect
water condensation.
The filter system is generally used to prevent the
spread of infectious disease and protect sensitive flow
monitoring equipment as used in mechanical
ventilators.
.........................P.1
..................................P.2
..................................P.4
.......................P.5
........................P.6~P.8
....................................P.9
.....................................P.9
....................................P.10
-3-
1. General Information
VADI Medical Technology Co., Ltd. Yangmei
No. 198, Lane 298, Huandong Road, Zhongshan
Village, Yangmei District, Taoyuan City 32665, Taiwan
TEL：+886-3-475-9911
FAX：+886-3-475-9922
E-mail：sales@vadimedical.com.tw
Website：www.vadimedical.com.tw
MedNet EC-REP IIb GmbH
Borkstrasse 10, 48163 Münster, Germany
MedNet SWISS GmbH
CH
Bäderstrasse 18, 5400 Baden, Switzerland
-1-
4. Specification
Dimension:11.2cmX11.5cmX11cm Weight: 650g
L-Connector
Bacteria Filter Heater
Water Trap
Heated Temp.: 70±7℃.
I/P: 200-240Vac, 50/60 Hz, 20W
This device life cycle is 3 years.
Operating Environment Temperature:18~26℃,
Humidity RH:15%~95%, Pressure: 700 to 1060hPa
Storage Temperature: 25~40℃, Humidity RH:15%~95%
without condensation
Transport Temperature: -10~60℃, Humidity RH:15%~95%
without condensation, Pressure: 595 to 1013 hPa
-4- -4-
