Hypontech HP51100 Quick Installation Manual

HP51100
1. Product Overview
Parts Introduction(Battery System)
Top View
5 4 7 6
D
[1]
1 . Power Button 2. CAN 1 Port
4. Port Negative X2 5. Port Positive X2
[3]
DC Isolator 8. ADD Switch
7.
[ 1 ] In parallelized batter y system, CAN 1 Port on the Master unit must be connected with inverter.
[2] In parallelized batter y system, CAN 2 Port must be connected with CAN 1 Port of next batter y system.
[3] Add switch is under the metal lid.
Dimensions: W×H×D= 420 × 730 × 199mm
2.
Packing List (Single Unit)
Battery
Mounting
Mounting
Documents
System
Plate
Accessories
1 pcs 1 pcs
1 pcs 1 psc
Configured Parts in Single Unit
Output
Power Cable (+)
1 pcs
1.2m
Output
1 pcs
Power Cable (-)
1.2m
Grounding
1 pcs
Cable
1.5m
Output
Communication
1 pcs
Cable
1.5m
Waterproof
1 pcs
module
H838-00139-01
W
2 3
1
8
H
[2]
3. CAN 2 Port
6. Grounding Point
3.
Installing
Installation Requirements
1. Please install the battery system in places that
can avoid inadvertent contact.
2. Please install the battery on solid/smooth surfaces.
3. The battery(s) should not be installed near inflammable
or explosive objects.
4. The installation place should be clean and well ventilated.
5. The installation place should be convenient for operation on
and maintenance.
AVOID
Direct Rain Snow
Sunlight Exposure Lay up
1
3.1
Installation Clearance
≥200mm
3.2
Mounting
NOTICE
The battery system is 55kg. It's necessary to arrange more than 1 person to install battery module if without lifting
equipment, more than 2 person when install battery module in higher position.
Confirm that the DC isolator is in the OFF state to ensure that there is no live operation.
3.2.1 Floor Mounting
Step 1: Place the mounting plate close to the wall and floor firmly;
Mark the 2 locating points to wall with hole on the mounting plate as shown below.
Step 2: Lift up the mounting plate and align the other 2 holes with the 2 location points marked on the wall in step 1;
Mark the 4 fixed position with the mounting plate.
Measuring distance from floor to bottom of the mounting plate can also ensure the height (76~80mm).
Step 3: Drill 4 holes on the wall using an impact electric driller. Hole diameter : 12mm; Hole depth:70mm.
Step 4: Fix the mounting plate with the expansion screw packed in mounting accessories. Tightening Torque: 12N·m.
Step 5: Remove the cover from the batter y system (Use T20 screwdriver);
Hang the batter y system on the mounting plate.
Step 6: Use M5 bolt in mounting accessories to fix the batter y system for keeping horizontal (Use T25 screwdriver).
Step 1
locating point
-20°C~60°C
5%~95%RH
Step 4
Altitude<3000m
200mm~300mm 200mm~300mm
Step 2
locating point
4X Φ12mm
Depth:70mm
76~80mm
Step 5
3
1
2
2
≥200mm
Step 3
Step 6
