2025 OWNERS MANUAL

Table of Contents

Need help?

Do you have a question about the EX 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tiara Yachts EX 60

Page 1 2025 OWNERS MANUAL...
Page 2 CALIFORNIA PROPOSITION 65 WARNING WARNING WARNING: Operating, servicing and maintaining a recre- ational marine vessel can expose you to chemicals includ- ing engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, service your vessel in a well-ventilated area and wear gloves or wash your hands frequently when servicing this vessel.
Page 3 Welcome to the family of Tiara Yachts boat owners and congratulations on your purchase of your new Tiara. We understand there are many choices available to you, and we appreciate the investment that you’ve made and the subsequent faith and confidence that you’ve placed into our product.
Page 4 This page intentionally left blank.
Page 6 SUPPLEMENTAL LIMITED WARRANTY INFORMATION ON FINISHED WOOD COMPONENTS Your Tiara Yachts ® Boat may be furnished with certain finished wood panels and components that require periodic maintenance and refinishing to maintain their appearance and finish. S2 Yachts, Inc.’s Limited Warranty coverage does not include the match- ing of wood grains, or the condition or durability of any finishes for such panels and components.
Page 7: Safety Information
Safety Information Your owner’s manual was written to include All instructions in this manual should be safety instructions to ensure safe operation viewed from the stern looking toward the bow, and maintenance of your boat. This manual with starboard to your right and port to your uses safety symbols to alert you to potential left.
Page 8 Safety Information Operator Notes...
Page 9: Table Of Contents
....... 2-2 arbon onoxide ........6-1 . Automatic ire uppression ystem ..2-3 6.3 Bilge Ventilation ........6-1 teering ystem ........2-3 6.4 Maintenance ..........6-1 olvo nterceptor oat rim ystem ..2-4 ompass ..........2-4 oystic ........... 2-5 EX 60...
Page 10 11.9 Generator ..........11-7 ire afety ..........9-2 Seasonal Maintenance arbon onoxide afety ......9-4 irst Aid............. 9-6 equired afety quipment...... 9-6 . Winteri ing ..........12-1 . Additional afety quipment..... 9-8 torage and ay up ......12-3 ecommissioning ......... 12-5 EX 60...
Page 11 Table of Contents Appendices lossary of erms ...........A-1 aintenance uides........B-1 aintenance chedule ........C-1 Boating Accident Report ........ D-1 Float Plan ............E-1 roubleshooting uide ........F-1 lectrical chematics ........G-1 EX 60...
Page 12 Table of Contents Operator Notes EX 60...
Page 13: Safety Labels
To obtain replacement labels refer to the part number of the label in the table and contact your Tiara dealer. Label placement and content are accurate at the time of printing. Interior EX 60...
Page 14: Exterior
Safety Labels Exterior 17 18 EX 60...
Page 15 Safety Labels EX 60...
Page 16 P/N: 5453130 Location: Under helm seat YACHT CERTIFICATION PLATE P/N: 5450570 Location: Under helm seat PRIDE OF OWNERSHIP P/N: 5450058 Location: Under the starboard galley switch panel DANGER: CARBON MONOXIDE P/N: 5453670 Location: Starboard side of transom buffet EX 60...
Page 17 Location: Under helm seat and inside the port al fresco cockpit cabinet FILL WITH DIESEL ONLY P/N: 5454580 ocation At port and starboard fuel fills WARNING: SUNSHADE STOWAGE P/N: 5450054 Location: Above the port al fresco cockpit cabinet EX 60...
Page 18 Locations: Anchor locker and shorepower connection locker under the starboard tran- som step NOTICE: FIXED FIRE EXTINGUISHER SYSTEM P/N 5450132 Location: Engine room hatch FRESH WATER P/N: 5455490 Locations: Anchor locker and washdown connection under port transom step EX 60...
Page 19 TAG: HEAD OVERBOARD DISCHARGE P/N: 5435240 Location: Overboard discharge seacock in forward mechanical space beneath the master stateroom hallway sole TAG: FUEL SYSTEM WITHDRAWAL STBD P/N: 5451290 Location: Forward engine room bulkhead EX 60...
Page 20 TAG: FUEL SYSTEM GENERATOR RE- TURN P/N: 5451360 Location: Forward engine room bulkhead TAG: BATTERY MOUNTING REQUIRE- MENTS P/N: 5450160 Locations: Batteries in the engine room WARNING: DO NOT DRILL P/N: 5455830 Locations: Engine room port and starboard bulkheads EX 60...
Page 21 TAG: ANCHOR ROPE WARNING P/N: 5455970 Location: Underside of anchor locker hatch TAG: GELCOAT DAMAGE NOTICE P/N: 5450720 Location: Underside of anchor locker hatch TAG: NMMA CERTIFIED BADGE P/N: 5455250 Location: Outboard of starboard transom steps EX 60...
Page 22 TAG: WATER HEATER WINTERIZED P/N: 5451840 Location: Water heater breaker on the AC Main Panel TAG: CA PROP 65 P/N: 9253280 Location: Steering wheel WARNING: UNATTACHED SEAT P/N: 5453160 Location: Port and starboard inboard face of glass patio bookends (if equipped) EX 60...
Page 23: General Information
Clearance with Hardtop (from waterline) ..........12' " (3.29 m) Approximate Dry Weight ............5 0 lbs. (2 Fuel Capacity..............700 U.S. gallons (2,649 L) Water Capacity ..............150 U.S. gallons (568 L) Holding Tank Capacity ............86 U.S. gallons (325.5 L) Deadrise at Transom ..................... 14° EX 60...
Page 24: Boat Information
Tiara Name: hone hone Representative: Sales Associate: Address: Service Manager: Address: Tiara Yachts reserves the right to make changes and improvements in equipment, design and vendor supplied e uipmen a any ime wi hou no i a ion EX 60...
Page 25: Owner/Operator Responsibilities
Tiara Yachts within 30 days of the know, if and when you may need service or date of resale. Contact Tiara Customer Rela- technical information.
Page 26: Reporting Boating Accidents
If you are not an experienced boater, we fuel vent systems. It is unlawful to remove or recommend that you and other people that intentionally defeat these emission related normally accompany you enroll in a boating components. safety course. Organizations such as the EX 60...
Page 27: Pre-Cruise Checklist
. . oast uard standards for the operate your boat. correct type required for your boat. • a e sure signal its are onboard, in good operating condition, and not ex pired. EX 60...
Page 28: Ropellers
Wire connector set The spare parts kit should include: xtra light bulbs par plugs uses and circuit brea ers lashlight and batteries rain plugs ngine oil ropellers uel filters ropeller nuts uel hose and clamps EX 60...
Page 29: Ngine Nstrumentation
GRID (Garmin Remote Input Device) the oil level before each use and use only the found on the helm seat armrest aft of the joy- type specified by the engine manufacturer. stick. Refer to the Garmin owners manual for more information. EX 60...
Page 30: Propulsion Systems
Voltmeter The voltmeter displays the voltage for the batteries and the charging system. The nor-mal voltage for a fully charged battery is 12.6 volts with the engine(s) off and 13 to 14.5 volts with the engine(s) running. EX 60...
Page 31: Helm Systems
Service or repairs to equipment inside your console should be performed by The helm controls consist of the engine throt- your Tiara Yachts dealer or other qual- tle with shift and integrated trim tab controls, i ed marine repair e hni ian ailure steering wheel, and joystick control.
Page 32: Tarting Our Ngines
9. Use the ENG ROOM FAN button on the 1. Switch ON all breakers except the OIL System Monitor screen of the power-up CHANGE PUMP breaker on the Master panel or the BLOWER button at the DC Panel in the engine room. EX 60...
Page 33: Automatic Ire Uppression Ystem
Steer your boat using the steering wheel, joy- stick control, or engine controls. For detailed After the fire suppression system discharges, information, see the engine owner’s manual. use the ENG ROOM FAN button on the Sys- tem Monitor screen of the power-up panel, or EX 60...
Page 34: Ompass
The interceptor blades are programmed to cycle into a self-cleaning mode that minimizes marine growth. EX 60...
Page 35 See your engine pack- age owner’s manual for more information. Volvo joystick EX 60...
Page 36 Section 2 Helm Systems Operator Notes EX 60...
Page 37: Fuel Systems
EX 60...
Page 38: Fueling Instructions
Also, monitor the fuel level sure there are no fuel fumes in the bilge to avoid overfilling. or engine compartment of your boat. Fuel vapors are explosive and may ignite during engine start-up, causing serious injury or death. EX 60...
Page 39 EX 60...
Page 40: Diesel Generator Fuel System
Algae needed. EX 60...
Page 41 Adding a high quality diesel fuel additive containing an algaecide may be required periodically to control algae in your diesel system, depending on your boating area. ontact your iara achts dealer or engine manufacturer for additional informa- tion regarding fuels and additives. EX 60...
Page 42 Section 3 Fuel Systems Operator Notes EX 60...
Page 43: Electrical Systems
Battery Status screen dix G to assist technicians in the servicing of the electrical systems. Tiara recommends you take your boat to an authorized Tiara Yachts Buttons on the System Monitor screen allow you to check the levels of the fresh- dealer for service or installation of additional electrical equipment.
Page 44: Ystem
The three banks are the battery status screen of the power-up divided into a house bank and a bank for panel, installed on the port helm console. each of the engines. The house bank provides power to EX 60...
Page 45 These transform- power to the BLOWER button on the helm. ers convert 24VDC to 12VDC. The transform- Cablemaster breaker: Supplies power to the ers are automatic and need no monitoring or Glendinning Cablemaster shorepower cord switching. retraction reel. EX 60...
Page 46 Cabin Main breakers: Supply power to the DC distribution panel. Washdown Pump breaker: Supplies power to the pressure-demand raw water Master DC panel 2 wash-down pump. The pump is also protected by EX 60...
Page 47 There are a number of DC buttons on the Terrace Door button: Supplies power to helm. For any of the buttons to function, the the terrace door up/down buttons in the aft corresponding circuit breaker on the Master cockpit. EX 60...
Page 48: Dc Distribution Panel
Cabin Lights 1, 2 and 3 breakers: Supply sewage discharge area. See section 5, power to cabin light switches. Plumbing Systems, for more information. Courtesy Lights breaker: Supplies power to the switches that control interior indirect light- ing and exterior pop-up lights. EX 60...
Page 49 DO NOT work on an buttons installed on the port alfresco cockpit energi ed sys em or allow un uali ed switch panel (if equipped with cockpit TV). personnel to work on the system. AC Power screen, power-up panel DC distribution panel EX 60...
Page 50: Power Source Selection
This breaker must be ON in order to use the backup key. Insert the key into the key switch air conditioning unit(s). on the side of the box. The key switch will manually switch the contactors from shore- power to generator. EX 60...
Page 51: Ac Distribution Panel
ONLY when the grill is being used. See to the battery charger that charges the two the grill owner’s manual for more information. engine battery banks. Refrigerator breakers: Supply AC electrical current to the galley refrigerator/freezers. EX 60...
Page 52: Shore Power
NOT swim in marinas or near boats cord, the CABLEMASTER breaker on the DC connected to shore power. Keep chil- distribution panel must be ON. dren away from any electrical cables or equipment and use grounded appli- ances onboard only. 4-10 EX 60...
Page 53: Generator
6. Turn the breaker at dock outlet ON. 7. The SHORE button on the power-up It is important to activate the house battery panel (installed on the port helm con- charger to maintain the house batteries whenever the generator is running. Because 4-11 EX 60...
Page 54 1. Open all hatches to the bilge area. in raw water contamination of the Investigate and remedy any fuel vapors generator’s cylinders and damage the that are detected. engine. 4-12 EX 60...
Page 55: Electrical System Maintenance
Keep the tops of any battery clean and dry. in the plugs with a protector specific for elec- Dirt and water can conduct electricity from trical connections. one post to the other and can cause battery discharge or engine warnings. 4-13 EX 60...
Page 56: Generator Maintenance
Whenever possible, have electrical work show signs of corrosion or fraying. Deterio- done by a qualified electrician or your rated cables cause a considerable voltage Tiara Yachts dealer. loss when high currents are drawn, such as • DO NOT work on an energized system;...
Page 57: Plumbing Systems
An automatic pressure sensor nel only. Fuel in the freshwater systems will eeps the system pressuri ed. f the system also require replacement of that system and/ has been recently filled or has not been used or many components. EX 60...
Page 58: Water Heater
The water heater uses an tion panel (installed in the third state- A element that is thermostatically controlled room electrical cabinet). The pump is at the heater. A high pressure relief valve pro- self priming. tects the system from excessive pressure. EX 60...
Page 59 (hot and cold), the water heater and pump, is drained then close the tap. You should be able to completely. f the system was filled with smell chlorine out of each tap. EX 60...
Page 60 When all faucets The freshwater system is now commissioned are closed, the pump will shut off as and ready for use. the system pressure increases. Any air should now be purged from the system 10. Repeat if necessary. EX 60...
Page 61: Arine Ead Ystem
1. At a marine facility pump out station, the holding tan . he system vacuum is mon- remove the cap from the WA itored by a vacuum switch, which is located plate, located on the starboard gunwale, EX 60...
Page 62 (located on the port helm con- local laws and restrictions. sole . Allow the discharge pump to run until the waste tank is empty. The sound EX 60...
Page 63: Holding Tank Maintenance
Fresh and raw washdown inlets are down system pump is supplied by hoses installed in the water connection locker connected to a ball valve and a thru hull fit- under the aft transom port step and in the upper anchor locker EX 60...
Page 64: Bilge Drainage
Also, chec the drain system to ensure it is free owing Bilge pump (typical) and that the hoses on the thru hull fittings are secure and not lea ing. EX 60...
Page 65: Lumbing Ystem Aintenance
A debris build up can cause the When the boat is out of the water, the bilge water pump to cycle excessively. can be drained by unplugging the thru hull EX 60...
Page 66: Raw Water System
• perate all thru hull valves at least once screwing it countercloc wise. A span- a month to eep them operating properly. ner wrench has been provided for this purpose. 5-10 EX 60...
Page 67: Drainage Systems
• Clean the cockpit drain rails with a hose washdown hoses lubricated. Apply a and water to remove all debris. mild liquid soap such as a liquid dish 5-11 EX 60...
Page 68 CAUTION use harsh hemi al drain leaners in drain sys ems permanen damage o he hoses i ings and sys em an resul rains and pumps mus be properly win eri ed be ore winter lay-up. 5-12 EX 60...
Page 69: Ventilation Systems
Sea water is supplied to the pump from a ual for more information. thru hull fitting located in the hull near the pump. A sea strainer between the pump and EX 60...
Page 70 Section 6 Ventilation Systems Operator Notes EX 60...
Page 71: Exterior Equipment
Do not use for securing fenders or anchor bouncing in the locker is not mooring lines, which must be secured to the covered by the Tiara Yachts warranty. cleats. Make sure mooring lines are clear of rails or stanchions, or damage can result.
Page 72: Foredeck Lounge
CAUTION DO NOT use the windlass as the only method of securing the anchor in the bow pulpit. Secure the anchor line to a cleat or chain snubber before oper- ating your boat. Bow storage lockers EX 60...
Page 73 In the event power to the sunroof is lost or the The FLIR camera can be operated using the motor malfunctions, pull down the headliner Garmin displays. See the camera owner’s panel on centerline (immediately aft of the manual for more information. EX 60...
Page 74: Ighting
If equipped, the breakfast bar Boarding and Exit Lighting module also includes ottomans that may be stowed below the bar. Turning the battery switch off will activate pre programmed exit lighting all courtesy lights and some exterior rope lighting will be EX 60...
Page 75 Failure to do so could result in serious Two minutes before the engine light turns off injury or death. automatically, it will start to ash. o override and keep the light on for another 15 minutes, press the button once. EX 60...
Page 76 Familiarize yourself with the following instructions before deploy ing the terraces. Hullside terrace deployed EX 60...
Page 77: Xterior Alley
Link™ app on your mobile device. Refer to To use the grill, the DECK GRILL breaker on the Fusion stereo system user’s manual for the AC distribution panel must be ON. Turn additional operating information. the breaker OFF whenever the grill is not being used. EX 60...
Page 78: Stern
Do not leave the grill unattended when it is hot. Close supervision is required when the grill is being used or is hot. Do not use the grill while underway. EX 60...
Page 79 DO NOT use the swim/boarding strained in any way as the boat moves platform when the engine is running. within its slip. Do not allow cables or hoses to dangle into the water. EX 60...
Page 80: Hydraulic Swim Platform
Always be sure the swim plat operator), pets, and items are cleared form is in the UP and LOCKED position prior away from and not positioned aft of the to getting underway. transom buffet. The hatch will open aft and up. 7-10 EX 60...
Page 81 DO NOT use the swim platform or stairway while engines are running. All engines must be OFF when swimmers are in the water and before allowing anyone to enter or exit the boat. 7-11 EX 60...
Page 82 Section 7 Exterior Equipment Operator Notes 7-12 EX 60...
Page 83: Interior Equipment
Garmin GRID; see section 2 for liner panel on centerline (immediately aft more information. The starboard armrest of the sunroof opening) and use a hex key slides fore and aft to accommodate different wrench to manually close the sunroof. EX 60...
Page 84: Alon And Alley
The port side lounge features seating with ates the foredeck, interior salon, alfresco storage below and a leafing dinette table. cockpit, and aft cockpit speakers. The end table lamps may be operated using switches installed outboard of the forward lamp. EX 60...
Page 85: Air Conditioning
Master stateroom lighting may be controlled head. Hardtop and accent lighting may be using switches on the inboard hallway bulk- controlled using the Garmin OneHelm dis- head and either side of the berth. EX 60...
Page 86: Aster Ead Ompartment
The VIP head compartment is equipped with whenever the boat is underway to prevent a toilet, fresh water sink with faucet, shower, damage to the door. exhaust fan, operable port light, storage, and EX 60...
Page 87: Arine Ead Ystem
See section 6, Ventilation Systems, for more information. Electrical Cabinet The boat’s AC and DC distribution panels are located in the third stateroom aft overhead cabinet. See section 4, Electrical Systems, for more information. EX 60...
Page 88 Section 8 Interior Equipment Operator Notes EX 60...
Page 89: Safety Information
The alarm will sound if one of these systems running, but be aware of loss of engine power begins to fail. Refer to the engine owner’s if the switch is activated. EX 60...
Page 90 While the sys- tions to ensure: tem helps ensure bilge fire protection, it does not eliminate the U.S. Coast Guard require- • Seals and tamper indicators are not ment for hand held fire extinguishers. broken or missing. EX 60...
Page 91 Keep or damage. ave an approved portable fire everyone together for morale and to aid res- extinguisher at hand and ready for use and cue operations. DO NOT breathe fumes or vapors caused by the fire. EX 60...
Page 92: Arbon Onoxide Afety
CO will cause BRAIN DAMAGE CO detectors are very reliable and rarely or DEATH. sound false alarms. If the alarm sounds, DO NOT think it is false. If anyone has been exposed to CO, move them into fresh air immediately. EX 60...
Page 93 Anyone with these (usually the cockpit, helm, and cabin) that symptoms should immediately be moved to can be created by the forward speed of the an area of fresh air. Have the victim breath EX 60...
Page 94: Irst Aid
9.8 Required Safety Equipment soning: What You Can’t See, included with this manual, and the owner’s manual sup- In addition to items installed by Tiara Yachts, plied by the CO detector manufacturer for certain other equipment is required by the additional information regarding the hazards U.S.
Page 95: Non-Pyrotechnic Devices
• Pyrotechnic orange smoke, hand-held or complying with U.S. Coast Guard require- oating. ments. They include: • Launchers for aerial red meteors or parachute ares. EX 60...
Page 96: Navigation Lights
Spare Parts Besides meeting the legal requirements, pru- dent boaters carry additional safety equip- ment. This is particularly important if you operate your boat offshore. You should con- sider the following items, depending on how you use your boat. EX 60...
Page 97: Operation
Wet surfaces can generate slippery they are not involved in the handling of moor- conditions which can result in death ing lines. or serious injury. Use caution on wet surfaces. 10-1 EX 60...
Page 98: Omeland Ecurity Estrictions
The following information describes the for a safe passage of the other vessel and should sound appropriate signals. basic navigation rules and action to be taken by vessels in a crossing, meeting or overtak- ing situation while operating in inland waters. 10-2 EX 60...
Page 99: Operation Section
• Check engine gauges. Make sure all are to avoid immediate danger or a collision. reading normally. • Visibly check engines to be sure there are no apparent water, fuel, or oil leaks. 10-3 EX 60...
Page 100 Avoid sea conditions that are beyond the skill to cool by running at idle for 3 to 5 minutes. and experience of you and your crew. • Turn the ignition OFF. • Raise the trim tabs to full UP position. 10-4 EX 60...
Page 101: Docking, Anchoring And Mooring
Move the stern right If you are new to handling a boat, take les- and left by shifting the engines in and out of 10-5 EX 60...
Page 102 Push the stern off and maneuver to gain stern clearance quickly. Proceed slowly until the Release the anchor by traversing to the point boat has cleared the dock and other boats. where the anchor line becomes vertical. It 10-6 EX 60...
Page 103: Failure
‘over propped’ and can be overloaded if too much throttle is designed as mooring cleats for securing the applied. Contact your dealer or the engine boat to a dock, pier, etc. only. DO NOT use 10-7 EX 60...
Page 104: Looding Or Apsi Ing
Contact your dealer or the to free a grounded vessel. Tiara Yachts Customer Relations Department if you are planning to transport your boat and When towing operations are underway, have have any questions in regard to the proper everyone on both vessels stay clear of the equipment and support for the hull.
Page 105: Trash Disposal
$50,000, and imprisonment for up to ve years or ea h viola ion egional state, and local restrictions on gar- bage discharges also may apply. 10-9 EX 60...
Page 106 Section 10 Operation 10-10 EX 60...
Page 107: Routine Maintenance
• Rinse the boat exterior with clean, fresh wi h he appropria e pads and polish- water. ing ma erials • Wash all exterior surfaces and hardware with a sponge or soft bristle brush and 11-1 EX 60...
Page 108: Bottom Painting
11-2 EX 60...
Page 109: Sacrificial Anodes
After cleaning the surfaces, apply wax and polish all fiberglass surfaces except Fiberglass Gelcoat Surfaces the nons id areas. ormal maintenance requires only washing with mild soap and water. A stiff brush can 11-3 EX 60...
Page 110 • Acetone can cause a corrosive condition that can • Alcohol damage the coating, especially in a salt air or • leaners containing ammonia coastal environment. • Glass cleaners • olvents 11-4 EX 60...
Page 111: Eats And Pholstery
When cleaning, manufacturer for additional information rub gently. use products containing regarding fuels and additives. ammonia, powdered abrasive cleaners, steel 11-5 EX 60...
Page 112: Cabin Interior
Air and sunlight are very good cleansers. your iara achts dealer or other qualified eriodically, place cushions, bedding, etc., marine service facility. on dec , under the sun and in the fresh air to dry and air out. f cushions or equipment 11-6 EX 60...
Page 113: Oil Change System
11-7 EX 60...
Page 114 Section 11 Routine Maintenance Operator Notes 11-8 EX 60...
Page 115: Seasonal Maintenance
1. Switch OFF the WATER HEATER break- Follow the ice maker user manual er on the Master AC Panel in the engine for winterization procedure. room. 12-1 EX 60...
Page 116: Fuel System
The check valve mechanism built into the raw water Algae can grow in the accumulated water in washdown pump will not remove the water diesel fuel tanks, especially in warm climates. 12-2 EX 60...
Page 117: Air Conditioner
Compartments your boat. Make sure the spreader bar at in the bilge that will not drain completely each sling is at least as long as the distance should be pumped out and then sponged until 12-3 EX 60...
Page 118 Remove as much marine growth level surface with the bow high enough as possible. Lightly wax the exterior so water will drain from the bilge and fiberglass components. 12-4 EX 60...
Page 119: Ecommissioning
• Check the engines and generator for ding on the bunks, are available through your damage and follow the manufacturer’s Tiara Yachts dealer. instructions for recommissioning. • Check the mounting bolts of engines to When storing the boat on a lift or cradle: make sure they are tight.
Page 120 Section 12 Seasonal Maintenance Operator Notes 12-6 EX 60...
Page 121: Lossary Of Erms
Glossary of Terms Appendix A Bow: The front end of a boat’s hull. In, near, or toward the stern of a boat. Bow Line: A line that leads forward from the bow Aground: A boat stuck on the bottom. of the boat. Amidships: In or toward the part of a boat mid- Bow Rail:...
Page 122 Appendix A Glossary of Terms Cradle: Fuel pump A framework designed to support a boat : feeds fuel under pressure as she is hauled out or stored. Freeboard: The height from the waterline to the Cutlass Bearing: A rubber bearing in the strut lowest part of the deck.
Page 123: Oil Pump
Glossary of Terms Appendix A Leeward: Outboard: The direction toward which the wind A boat designed for an engine to be is blowing. mounted on the transom. Also a term that refers to objects away from the center line or beyond the Length On The Waterline (LWL): A length hull sides of a boat.
Page 124 Appendix A Glossary of Terms Reverse Gear: Stow: Changes the direction of rotation To pack away neatly. of the propeller to provide thrust in the opposite Stringer: direction for stopping the boat or giving it stern- Longitudinal members fastened inside way.
Page 125 Glossary of Terms Appendix A Water pump: circulates cooling water Watertight Bulkhead : Bulkheads secured so tightly so as not to let water pass. Wharf: A structure generally parallel to the shore. Windlass: A winch used to raise and lower the anchor.
Page 126 Appendix A Glossary of Terms Operator Notes...
Page 127: Aintenance Uides
Maintenance Guides Maintenance Guides Appendix B Owner’s Guide: Care & Upkeep of Fiberglass Products As the world’s premier gel coat supplier, Polynt Composites has provided this brochure as a guide to properly maintain and care for your gel coat surface. Gel Coats provide a protective layer against Corrective Procedures* weathering on a surface.
Page 128 Appendix B Maintenance Guides Operator Notes...
Page 129: Aintenance Chedule
Maintenance Schedule Maintenance Schedule Appendix C Each Semi Maintenance Weekly Monthly Yearly Annually Needed Clean hull below the waterline Bottom paint hec sacrificial anodes eplace sacrificial anodes Wash boat canvas & hardware Wax exterior gelcoat Clean & protect hardware Polish & protect plastic glass Clean exterior upholstery Clean cabin &...
Page 130 Appendix C Maintenance Schedule Date Hours Dealer Service / Repairs...
Page 131 Maintenance Schedule Appendix C Date Hours Dealer Service / Repairs...
Page 132 Appendix C Maintenance Schedule Date Hours Dealer Service / Repairs...
Page 133: Boating Accident Report
Boating Accident Report Boating Accident Report Appendix D RECREATIONAL BOATING ACCIDENT REPORT INSTRUCTIONS Privacy Act Notice Authority: Purpose: Routine Uses: REPORT SUBMISSION Report required because (select all that apply): To be submitted within: (if injury, disappearance or death) died (if boat/property damage only) required or was in need of treatment beyond first aid (Local State Reporting...
Page 134 Appendix D Boating Accident Report For each question below, please provide answers IF APPLICABLE AND IF KNOWN, otherwise leave blank. YOUR BOAT BOAT IDENTIFICATION Your Boat Name: Manufacturer: Model Name: Model Year: Registration #: Documentation #: Hull Identification # Rented: (HIN): SIZE ESTIMATES Depth from transom (stern)
Page 135 Boating Accident Report Appendix D For each question below, please provide answers IF APPLICABLE AND IF KNOWN, otherwise leave blank. ACCIDENT DETAILS ACTIVITIES AND OPERATIONS ON YOUR BOAT OPERATOR/PASSENGER ACTIVITIES Operator/passenger activities on your boat at time of accident: Activities were Operator/Passenger activities Recreational Fishing...
Page 136 Appendix D Boating Accident Report For each question below, please provide answers IF APPLICABLE AND IF KNOWN, otherwise leave blank. ACCIDENT DETAILS YOUR BOAT- INJURED PEOPLE RECEIVING OR IN NEED OF TREATMENT BEYOND FIRST AID injured people on, struck by, or being towed by , receiving treatment beyond first aid.
Page 137 Boating Accident Report Appendix D For each question below, please provide answers IF APPLICABLE AND IF KNOWN, otherwise leave blank. ACCIDENT DETAILS YOUR BOAT OPERATOR OPERATOR INSTRUCTION OPERATOR SAFETY MEASURES Boating safety instruction completed On board, prior to accident, was operator wearing: None A lifejacket? An engine cut-off switch...
Page 138 Appendix D Boating Accident Report For each question below, please provide answers IF APPLICABLE AND IF KNOWN, otherwise leave blank. YOUR BOAT OPERATOR NAME/ADDRESS First Name Last Name Street City State AGE/GENDER/PHONE Date of Birth Phone Gender Male Female YOUR BOAT OWNER If same as boat SKIP rest of YOUR BOAT OWNER section.
Page 139: Float Plan
Float Plan Float Plan Appendix E...
Page 140 Appendix E Float Plan...
Page 141 Float Plan Appendix E Provided as a courtesy by: S2 Yachts, Inc. Holland, MI (616) 392-7163 Get a Vessel Safety Check before you go boating.
Page 142 Appendix E Float Plan Operator Notes...
Page 143: Troubleshooting Guide
Troubleshooting Guide Troubleshooting Guide Appendix F Problem Cause and Solution Control Systems • teering system is low on uid. ill and bleed sys- tem. Hydraulic steering is slow • teering system has air in it. ill and bleed system. to respond and erratic. •...
Page 144: Engine Problems
Appendix F Troubleshooting Guide Problem Cause and Solution • ropeller may be damaged and need repair. • he propeller or propeller shaft is bent. epair or replace damaged components. The boat vibrates at cruis- • he running gear is fouled by marine growth or ing speeds.
Page 145 Troubleshooting Guide Appendix F Problem Cause and Solution • he engine may be having a problem with a stic y anti siphon valve, located in the fuel line near the fuel tan , that is restricting the fuel ow. emove clean or replace the anti siphon valve.
Page 146 Appendix F Troubleshooting Guide Operator Notes...
Page 147 Electrical Schematics Electrical Schematics Appendix G...
Page 148 Appendix G Electrical Schematics...
Page 149 Electrical Schematics Appendix G...
Page 150 Appendix G Electrical Schematics...
Page 151 Electrical Schematics Appendix G...
Page 152 Appendix G Electrical Schematics...
Page 153 Electrical Schematics Appendix G...
Page 154 Appendix G Electrical Schematics...
Page 155 Electrical Schematics Appendix G...
Page 156 Appendix G Electrical Schematics G-10...
Page 157 Electrical Schematics Appendix G G-11...
Page 158 Appendix G Electrical Schematics G-12...
Page 159 Electrical Schematics Appendix G G-13...
Page 160 Appendix G Electrical Schematics G-14...
Page 161 Electrical Schematics Appendix G G-15...
Page 162 Appendix G Electrical Schematics G-16...
Page 163 Electrical Schematics Appendix G G-17...
Page 164 Appendix G Electrical Schematics G-18...
Page 165 Electrical Schematics Appendix G G-19...
Page 166 Appendix G Electrical Schematics G-20...
Page 167 Electrical Schematics Appendix G G-21...
Page 168 Appendix G Electrical Schematics G-22...
Page 169 Electrical Schematics Appendix G G-23...
Page 170 Appendix G Electrical Schematics G-24...
Page 171 Electrical Schematics Appendix G G-25...
Page 172 Appendix G Electrical Schematics G-26...
Page 173 Electrical Schematics Appendix G G-27...
Page 174 Appendix G Electrical Schematics G-28...
Page 175 Electrical Schematics Appendix G G-29...
Page 176 Appendix G Electrical Schematics G-30...
Page 177 Electrical Schematics Appendix G G-31...
Page 178 Appendix G Electrical Schematics G-32...
Page 179 Electrical Schematics Appendix G G-33...
Page 180 Appendix G Electrical Schematics G-34...
Page 181 Electrical Schematics Appendix G G-35...
Page 182 Appendix G Electrical Schematics G-36...
Page 183 Electrical Schematics Appendix G G-37...
Page 184 Appendix G Electrical Schematics G-38...
Page 185 Electrical Schematics Appendix G G-39...
Page 186 Appendix G Electrical Schematics G-40...
Page 187 Electrical Schematics Appendix G G-41...
Page 188 Appendix G Electrical Schematics G-42...
Page 189 Electrical Schematics Appendix G G-43...
Page 190 Appendix G Electrical Schematics G-44...
Page 191: Operator Notes
Operator Notes...
Page 192 725 E 40th Street, Holland, MI 49423 | 616.392.7163 tiarayachts.com...

Tiara Yachts EX 60 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Tiara Yachts EX 60

Summary of Contents for Tiara Yachts EX 60

Table of Contents
