Essence Security MyShield ES900MS Installation Manual

Hide thumbs Also See for MyShield ES900MS:
Table of Contents

Advertisement

Quick Links

Download this manual
Essence Security
MyShield
Installation Guide
October 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MyShield ES900MS and is the answer not in the manual?

Questions and answers

Related Manuals for Essence Security MyShield ES900MS

Summary of Contents for Essence Security MyShield ES900MS

  • Page 1 Essence Security MyShield Installation Guide October 2023...

  • Page 2: Table Of Contents

    11. Perform an Intrusion Test with the Monitoring Center ..............14 12. Replace the Simulation Canister with a Live Smoke Canister ............14 Essence Security MyShield Installation Guide © 2023 Essence Security International (E.S.I.) Ltd.- All Rights Reserved - Proprietary and Confidential...

  • Page 3: Introduction

     Eight CR-123A 3V batteries (six for MyShield, two for the simulation canister)  A CAT-M micro-SIM (3FF) card recommended by your vendor  A plastic PIR sensor cover (order separately)  Essence Security MyShield Installation Guide...

  • Page 4: Choose An Installation Location

    On a wall or in a corner at a height of 2 m (6.5 ft.)  Perpendicular to the floor  Not above an entry door  Out of direct sunlight  In accordance with the following recommended distances:  Essence Security MyShield Installation Guide...

  • Page 5: Test The Installation Location

    1. With the bottom of MyShield facing up, slide the bottom panel until it clicks. 2. Remove the bottom panel. 3. Pull the wall mount up until it clicks. 4. Remove the wall mount. 5. Insert the SIM card into the slot until it clicks. Essence Security MyShield Installation Guide...
  • Page 6 6. While pressing the red release button, pull out the battery holder. 7. Insert the batteries into the battery holder, observing the correct polarity. WARNING! A new battery may explode if incorrectly installed. Use only the same or equivalent battery type recommended by the manufacturer. Essence Security MyShield Installation Guide...
  • Page 7 10. To repeat the test, simply remove the battery holder by pressing the red release button, and then reinsert it. 11. Place MyShield as close as possible to the new chosen location and wait for the new scoring result. Essence Security MyShield Installation Guide...

  • Page 8: Mount Myshield

    6. Screw the screws through the wall mount, into the wall anchors. 7. Place MyShield over the wall mount so that the top of MyShield is slightly higher than the top of the wall mount and slide MyShield down until it clicks. Essence Security MyShield Installation Guide...
  • Page 9 8. Turn on the simulation canister and insert it, as described in the Started Guide 9. Place the bottom panel over the bottom of MyShield. 10. Slide the bottom panel toward the back of MyShield until it clicks. Essence Security MyShield Installation Guide...

  • Page 10: Install The Myshield Application On A Mobile Phone

    3. Before registering for the first time, tap the Server URL link in the top left corner of the screen. 4. In the URL string alpha@https://csprod-external.esi-cloud.com/, replace “alpha” with the name provided by your vendor (using lower-case characters only). Essence Security MyShield Installation Guide...

  • Page 11: Register As A New Myshield User

    If the LED blinks red, the motion detector has detected your movement. It is working  correctly. If the LED does not blink red, the motion detector has not detected your movement. Stand  outside MyShield’s FOV for at least five minutes, and then repeat the test. Essence Security MyShield Installation Guide...

  • Page 12: Test Myshield Operation

    Operational information displays for the selected MyShield device. NOTE: In case of a tamper error message, contact your help desk. 3. Verify that there are no error messages. 4. Return to the main screen and tap Arm. Essence Security MyShield Installation Guide...
  • Page 13 10. After the confirmation photo shows on your app , tap OK in the top right corner. 11. Disarm the system. 12. After each intrusion event, the unit must be reset by removing and reinserting the canister and battery. Essence Security MyShield Installation Guide...

  • Page 14: Perform An Intrusion Test With The Monitoring Center

    3. Remove the batteries to reset the device. 4. Wait a few seconds and reinsert the batteries. 5. Pull down the handle on the live smoke canister. 6. Slide the canister into MyShield until it stops. Essence Security MyShield Installation Guide...
  • Page 15 10. Wait until you hear an announcement indicating the quality of the reception. Installation is now complete. NOTE: The system is now live with the real smoke cannister. An intrusion and activation will deploy actual smoke. Essence Security MyShield Installation Guide...
  • Page 16 REPLACE THE SIMULATION CANISTER WITH A LIVE SMOKE CANISTER NOTE: When working with a monitoring center, verify that MyShield has successfully connected to the alarm response center. Essence Security MyShield Installation Guide...

  • Page 17: Legal Notice

    If you do not agree with these terms, please do not access or use the remainder of this document. This document contains highly confidential information, which is proprietary to Essence Security International (E.S.I.) Ltd. and/or its affiliates (hereafter, "Essence").
