- Page 1 Machine Tools OPERATING INSTRUCTION OPERATING INSTRUCTIONS Marks Super SV Part No.: 301490...
- Page 2 Machine Tools OPERATING INSTRUCTION Security instruction Operation manual For your own security read the operation manual before starting the machine. The operation manual should be kept in a secure place. You should know about how to handle the machine, it’s limits and it’s specific dangers. Keep your working place clean Disorder on your working place will result in danger.
- Page 3 Machine Tools OPERATING INSTRUCTION to danger. Children and visitors should be kept in a secure distance to the working area. Keep children away from the machine. Don’t let other people touch the machine or the cable of the machine. Make sure that only authorized persons can reach the workshop. Take care about the Power supply cable Before connecting the power supply cable to the wall socket ensure that the machine is switched off.
- Page 4 Machine Tools OPERATING INSTRUCTION Take care about your hands Make sure, that tools and work pieces are securely fastened. Use only the right tools to clamp and to fasten tools and work pieces. This is more secure than to fasten the work piece with the hand, and you have two hands to handle the machine.
- Page 5 Machine Tools OPERATING INSTRUCTION WARNING:FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS PERSONAL INJURY As with all machinery there are certain hazards involved with operation and use of the machine. Using the machine with respect and caution will considerably lessen the possibility of personal injury.
- Page 6 Machine Tools OPERATING INSTRUCTION appropriate recommendations . Also use face or dust mask if cutting operation is dusty. 13.SECURE WORK. Use clamps or a vise to hold work when practical. It’s safer than using your hand and frees both hands to operate tool. 14.
-
Page 7: Changing The Gear Box Oil
Machine Tools OPERATING INSTRUCTION 6. WARNING: FOR Your Own Safety Don’t wear gloves when operating a mill/drill. SPECIFICATION Model Mark Super SV Drilling capacity cast iron 32mm mild steel 25mm Face mill capacity 76mm End mill capacity 25mm Working table size 800mm X 240mm Working table cross travel 190mm... -
Page 8: Use Of Main Machine Parts
Machine Tools OPERATING INSTRUCTION points with a medium consistency machine oil. LUBRICATION: All ball bearings in your mill/drill are sealed for lift,requiring no lubrication. Points requiring lubrication are: (1) Internal spline drive assembly. Keep this area well lubricated with a good grade grease, insert grease in the hole at the top of spindle pulley spline driver, lube twice yearly. - Page 9 Machine Tools OPERATING INSTRUCTION (2) After Operation (a) Turn off the electric switch. (b) Turn down the tools. (c) Clean the machine and coat it with lubricant. (d) Cover the machine with cloth to keep out the dust. (3) Adjustment of head (a) To raise and lower the head,loosen the leaf screw located on the right side of the raise and lower base.
- Page 10 Machine Tools OPERATING INSTRUCTION (a) Adjust the positive depth stop gauge to highest point position. (b) Turn tight of the knob be use to taper friction force coupling the worm gear and spring base. Then turning the handle wheel by micro set the spindle of work piece machining height.
- Page 11 Machine Tools OPERATING INSTRUCTION wrench. Rpa the top of the arbor bolt with a mallet. After taper has been broken loose, holding chuck arbor on hand and turn detach the arbor bolt with the other hand. (2) To install Face Mill or Cutter Arbor Insert cutter and cutter arbor bolt detach securely, but do not over tighten.
-
Page 12: Troubleshooting Hints
Machine Tools OPERATING INSTRUCTION TROUBLE SHOOTING HINTS TROUBLE PROBABLE CAUSE REMEDY 1 .Balance or replace problem motor. 2.Replace Excessive 1 .Motor out of balance 2.Bad motor motor Vibration Motor stalls 1 .Replace feed rate. 1 .Over feeding. 2.Sharpen drill and keep sharp. 2. - Page 13 Machine Tools OPERATING INSTRUCTION...
- Page 14 Machine Tools OPERATING INSTRUCTION...
- Page 15 Machine Tools OPERATING INSTRUCTION Power feed device This machine be equipped with the power feed device see Fig.l. 1.Power feed switch 2.Speed lever 3.Spindle stroke dial 4. Handle 5. Limited screw 6. Locked nut 7. Micro feed dial 8. Locked screw 9.
-
Page 16: Operation Procedure
Machine Tools OPERATING INSTRUCTION OPERATION PROCEDURE Manual feed Turn the power feed switch 1 off, handle 4 with be vertical with the axis of Spindle stroke dial 3, rotate limited screw 5 and be contacted with handle 4, then can be manually feed spindle. When the power feed switch 1 on, make handle 4 vertical, locked limited screw 5, rotate Speed level 2 to “0”, then can be manually feed spindle. - Page 17 Machine Tools OPERATING INSTRUCTION...
- Page 18 Machine Tools OPERATING INSTRUCTION Code Name Code Name Feed box Gear 20102 20202 20234 Pinion shaft Speed lever 20201 20243 Spindle stroke dial Steel ball S 20242 Clutch bushing set Retainer rmg 12 20241 Backing pin Spring Pm 6X 12 Screw M6 X 20 20247 Ball head pin...
- Page 19 Machine Tools OPERATING INSTRUCTION Pos.55: 33009/P5 (45mmx75mmx24mm) Pos.56: 33007/P5 (35mmx62mmx21mm)
- Page 20 Machine Tools OPERATING INSTRUCTION Head parts for spindle power feed Qty. Code Name Qty. Code Name 20010B head body 20011B head body cover ball retaining ling retaining ring spring 20018B airtight base retaining ring airtight ring key 6X36 motor 20107V III shaft screw washer...
- Page 21 Machine Tools OPERATING INSTRUCTION Code Name Qty. Code Name Qty. 20133B oil tight cover 20205B spring air tight 20108A fixed sleeve oil seal 20118 spring base 20103A washer retaining 20123 spring cap ring 20122 spring plate bearing 20102 washer 20213A I shaft bolt screw...
- Page 22 Machine Tools OPERATING INSTRUCTION...
- Page 23 Machine Tools OPERATING INSTRUCTION Qty. Code Name Qty. Code Name base washer 10010 10013 column M8X25 screw square flange MSX45 screw 10021 10016 raise and lower base M8X15 screw 10025 gib strip 10022 gib strip 10106 screw M8X25 screw 51103 bearing 10108 movable fixed block...
- Page 24 Machine Tools OPERATING INSTRUCTION right flange MS X 25 screw 10020 10019 left flange 5 X 25 pin 10103 table screw dial clutch 10110 10105 fixed block...
- Page 25 Machine Tools OPERATING INSTRUCTION...
- Page 26 Machine Tools OPERATING INSTRUCTION...
