- Page 1 MTS34-54 MTS48-72 OWNER’S MANUAL OWNER’S MANUAL MULTI-TASK MULTI-TASK SKID STEER SKID STEER TRENCH PAVER TRENCH PAVER Read, Understand, and Follow this manual, which provides information and procedures to operate and maintain your Roadrunner Equipment paver safely. MADE IN THE USA...
-
Page 3: Table Of Contents
3.4 Pre-Operation Checklist 3.5 Operation 3.5.1 Adjustment 3.5.2 Paving 3.5.3 Example of Use 3.6 Detaching From Machine 4. Transporting 4.1 Highway and Transport Safety Pre-Transport Checklist 5. Storage 5.1 Placing in Storage Removing from Storage Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 4: Introduction
Roadrunner Eqpt. LLC with questions. Do not use an oversized machine; the paver is intended to be used on machines rated up Serial Number: to 110 HP or a 3000 pound lift capacity. -
Page 5: Product Improvements
1.7 Disposal of Equipment at End of Useful Life Roadrunner Eqpt. LLC pavers are designed for the specific purpose of paving and backfilling trenches. When this paver is no longer capable of performing its intended use, it should be dismantled and scrapped. -
Page 6: Safety
NOTICE Roadrunner Eqpt LLC cannot anticipate every Indicates that paver or property damage can possible circumstance that might involve a result if instructions are not followed. -
Page 7: Safety Icons
This manual and the paver has numerous safety icons. These safety icons provide important operating instructions which alert you to potential personal injury hazards. 2.3.1 Personal Protection / Important Information 2.3.3 Hazard Avoidance 2.3.2 Prohibited Actions Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 8: General Safety
Consult your doctor before using the operation, causing severe injury. paver while taking prescription medications. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 9: Safety Signs
Make sure components in the hydraulic system understand any information in this manual, see are kept clean and in good working condition. your dealer or contact Roadrunner Eqpt LLC The most common reason for hydraulic before proceeding. Do not use or allow anyone component failure is contamination of the oil. -
Page 10: Operation
Operator Manual to be familiar with the location, settings, and function of the Be certain only physically-able persons will controls. Be familiar with all controls before use the paver. using this paver. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 11: Machine Specifications
Whenever traveling on a public roadway, the tractor must be equipped with proper warning lighting and a Slow Moving Vehicle (SMV) emblem which are clearly visible from the rear of the tractor. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 12: Pre-Operation Checklist
3 inches above grade. Width Adjustment The paver is also designed to be able to open and close, using the manual adjustment handle located on the side of the paver (fig.3.5 #2). Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 13: Paving
Screeds can be adjusted in depth, down to 5" below grade, to use in spreading the base layer. Screeds can be adjusted in height, up to 3" above grade, to use in spreading the top coat layer. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 14: Detaching From Machine
Move paver to a storage location. Release all hydraulic pressure. Disconnect the hydraulic hoses. Do not allow the hoses to lie on the ground. Board the machine and detach the paver. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 15: Transporting
Do not coast. Be a safe and courteous driver. Always yield to oncoming traffic in all situations, including narrow bridges, intersections, etc. Plan your route to avoid heavy traffic. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 16: Storage
Move the paver to Storage: Safely relocate the paver to its designated storage area, ensuring the path is clear of obstacles. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 17: Maintenance
Always set the paver on blocks or on shorten the life of the paver and invite various the ground when performing maintenance. problems. Roadrunner Eqpt. LLC will not accept OEM Replacement Parts responsibility for the use of unapproved parts If replacement parts are necessary,... -
Page 18: Bolt Torque Requirements
Before performing any type of welding The torque values indicated in the chart are for repair to the paver, contact Roadrunner non-greased or non-oiled threads unless Equipment for approval. Repair welding should be otherwise specified. Therefore, do not grease or... -
Page 19: Service Record
Make sure all fasteners are tightened to proper torque. Refer to “8.2 Bolt Torque Requirements” on page *** Inspect the hydraulic cylinder and hoses for damage. Wash the paver. Inspect the frame for cracking or damage. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 20: Parts Section
7. Parts Section 7.1 Ordering Parts Roadrunner Eqpt LLC produces high-quality products that require minimal maintenance or repairs. However, if a part happens to break or get damaged, our expert team is ready to ensure you receive the necessary replacement parts to get your paver back in operation quickly. -
Page 21: Bill Of Materials / Parts
Multi-Task Paver Right Side Hydraulic Width Adjustment * TeleTube Assembly * Skid Plate Assembly * Bolt, 1/2"-13 Thread, 1-1/4" Long Split Lock Washer, 1/2" Nut, 1/2"-13 Thread Bolt, 1/2"-13 Thread, 2" Long *Size dependent on model#. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 22: Screeds
7.4 Screeds Item Description Outside Screed * Inside Screed * Handle, Screed Clamp *Size dependent on model#. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 23: Side Panel
MT Skid Bar Bolt, 3/8"-16, 3" Long Jack Locknut, 3/8"-16 Screw, Flat, 3/8"-16, 1" Long Bucket Mount Handle Nut, 3/8"-16 Washer, 3/8" Bolt, 3/8-16", 1" Long Washer, 3/8" Nut, 3/8"-16 *Left side shown. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 24: Width Adjustment
7.6 Hydraulic Width Adjustment Item Description Hydraulic Cylinder * 1/2" Hose * Female, Hydraulic Quick Connector Male, Hydraulic Quick Connector *Size dependent on model #. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 25: Teletubes
7.7 Teletubes Item Description Weldment, TeleTube * Inside, Short Tube * Inside, Long Tube * Grease Zerk *Size dependent on model #. Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 26: Decals
7.8 Decals Part#: Decal_MT_SP Description: Decal, MT-Series Side Panel Roadrunner Eqpt. LLC (717) 405-7785 MTS Paver... -
Page 27: Warranty
Roadrunner Equipment LLC with freight or delivery charges prepaid. This Limited Warranty does not render Roadrunner Equipment LLC liable for any injury or damage to persons, businesses, or property of any kind, nor for expenses or losses incurred for labor, supplies, substitute machinery rental, or any other reason. - Page 28 Roadrunner Equipment LLC 155 Jalyn Drive New Holland, PA 17557 717.405.7785 www.RoadRunnerBlade.com contact@roadrunnerblade.com 11052024 REV A Revised 11-2024...
