- Page 1 Models: 6ftCHSS 7ftCHSS 8ftCHSS OWNER’S MANUAL OWNER’S MANUAL C-SERIES C-SERIES Single Hydraulic SKID STEER GRADER Read, Understand, and Follow this manual, which provides information and procedures to operate and maintain your Roadrunner Equipment grader safely. MADE IN THE USA...
-
Page 3: Table Of Contents
Blade Adjustment 3.5.2 Level Grading 3.5.3 Crowning 3.5.4 Example of Use 3.6 Detaching From Machine 4. Transporting 4.1 Highway and Transport Safety Pre-Transport Checklist 5. Storage 5.1 Placing in Storage Removing from Storage Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 4: Introduction
Do not use this grader for any other purpose space provided for easy reference when than its intended use of grading and contacting Roadrunner Eqpt. LLC with contouring dirt and gravel surfaces. questions. Do not use an oversized machine; the grader... -
Page 5: Product Improvements
1.7 Disposal of Equipment at End of Useful Life Roadrunner Eqpt. LLC Graders are designed for the specific purpose of leveling, grading, and contouring gravel and dirt surfaces, such as roadways, dirt ditches, or field/yard surfaces. -
Page 6: Safety
NOTICE Roadrunner Eqpt LLC cannot anticipate every Indicates that grader or property damage can possible circumstance that might involve a result if instructions are not followed. -
Page 7: Safety Icons
This manual and the grader has numerous safety icons. These safety icons provide important operating instructions which alert you to potential personal injury hazards. 2.3.1 Personal Protection / Important Information 2.3.3 Hazard Avoidance 2.3.2 Prohibited Actions Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 8: General Safety
Consult your doctor before using the operation, causing severe injury. grader while taking prescription medications. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 9: Safety Signs
Make sure components in the hydraulic system understand any information in this manual, see are kept clean and in good working condition. your dealer or contact Roadrunner Eqpt LLC The most common reason for hydraulic before proceeding. Do not use or allow anyone component failure is contamination of the oil. -
Page 10: Operation
Operator Manual to be familiar with the location, settings, and function of the Be certain only physically-able persons will controls. Be familiar with all controls before use the grader. using this grader. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 11: Machine Specifications
Operate the cutting blade lift cylinder throughout the entire range of travel, several times, to purge air from the hoses and cylinder. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 12: Pre-Operation Checklist
The grader uses the least amount of oil in the “+2” position and the level should be checked in this position to prevent overfilling. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 13: Level Grading
When working on a curve, bank the roadway in the POTHOLE direction of travel and do not crown the surface. BASE Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 14: Detaching From Machine
Move grader to a storage location. Release all hydraulic pressure. Disconnect the hydraulic hoses. Do not allow the hoses to lie on the ground. Board the machine and detach the grader. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 15: Transporting
Do not coast. Be a safe and courteous driver. Always yield to oncoming traffic in all situations, including narrow bridges, intersections, etc. Plan your route to avoid heavy traffic. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 16: Storage
Move the Grader to Storage: Safely relocate the grader to its designated storage area, ensuring the path is clear of obstacles. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 17: Maintenance
Always set the grader on blocks or on shorten the life of the grader and invite various the ground when performing maintenance. problems. Roadrunner Eqpt. LLC will not accept OEM Replacement Parts responsibility for the use of unapproved parts If replacement parts are necessary,... -
Page 18: Bolt Torque Requirements
Before performing any type of welding The torque values indicated in the chart are for repair to the grader, contact Roadrunner non-greased or non-oiled threads unless Equipment for approval. Repair welding should be otherwise specified. Therefore, do not grease or... -
Page 19: Service Record
Make sure all fasteners are tightened to proper torque. Refer to “8.2 Bolt Torque Requirements” on page *** Inspect the hydraulic cylinder and hoses for damage. Wash the grader. Inspect the frame for cracking or damage. Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 20: Parts Section
7. Parts Section 7.1 Ordering Parts Roadrunner Eqpt LLC produces high-quality products that require minimal maintenance or repairs. However, if a part happens to break or get damaged, our expert team is ready to ensure you receive the necessary replacement parts to get your grader back in operation quickly. -
Page 21: Main Bill Of Materials
7.3 Main Bill of Materials Item Description Side Panel, C-Series Blades Hydraulics, CHSS, Single Manual Adjusment Handle Depth Gauge Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 22: Side Panel
7.4 Side Panel, C-Series Item Description Side Panel, C-Series Skid Bar, C-Series Hex Bolt, 3/4"-10, 2" Long Split Washer, 3/4" Hex Nut, 3/4"-10 Flat Head Screw, 3/8"-16, 1-1/2" Long Washer, 3/8" Hex Nut, 3/8"-16 Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 23: Cutting/ Grading Blades
7.5 Cutting / Grading Blades DETAIL A Item Description Serrated Blade * Smooth Blade * Plow Bolt, 5/8"-11, 3" Long Split Washer, 5/8" Nut, 5/8"-11 *Part# dependent on model. -6ft, 7ft, 8ft Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 24: Hydraulics
7.6 Hydraulics Item Description Cylinder, 3X4 Elbow, Cylinder Connector Hydraulic Hose * Quick Connect, Male Quick Connect, Female Hose Clamp Spring, Hose Saver *Length dependent on model. -6ft, 7ft, 8ft Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 25: Depth Gauge
7.7 Depth Gauge Item Description Depth Gauge Depth Gauge Mount Plate Locknut, 3/8"-16 Thread Washer, SAE, 3/8" Nut, 3/8"-16 Thread Bolt, 1/4"-20 Thread, 1" Long Locknut, 1/4"-20 Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 26: Decals
7.4 Decals Part#: Decal_C_SP Description: Decal, C-Series Side Panel Part#: Decal_DG Description: Decal, Depth Gauge Roadrunner Eqpt. LLC (717) 405-7785 C-Series Grader... -
Page 27: Warranty
Roadrunner Equipment LLC with freight or delivery charges prepaid. This Limited Warranty does not render Roadrunner Equipment LLC liable for any injury or damage to persons, businesses, or property of any kind, nor for expenses or losses incurred for labor, supplies, substitute machinery rental, or any other reason. - Page 28 Roadrunner Equipment LLC 2198 Pequea Lane Lancaster, PA 17601 717.405.7785 www.RoadRunnerBlade.com contact@roadrunnerblade.com 10142024 REV A Revised 10-2024...
