SGS FI-5A Instructions

Fault indicator

Advertisement

Quick Links

MANUAL TEST
Place reset tool over fault indicator's dome so reset tool's magnet is over
the label on the side opposite from battery caps. Hold magnet in place
for approximately 1 second. The LEDs will begin to flash through a test
sequence and will stop flashing once the test sequence is complete.
MANUAL RESET
While LEDs are flashing, place reset tool over fault indicator's dome so
reset tool's magnet is over the label on the side opposite from battery
caps. Hold magnet in place for approximately 1 second. The LEDs will
stop flashing.
BATTERY REPLACEMENT
The FI-5A uses one 3.6V AA battery and one 3.6V C battery; both
batteries have a wired connector. Replacement batteries are best
purchased from SGS or an authorized distributor. Best practice dictates
that when replacing batteries, users should replace both AA and C
batteries.
To replace batteries, unscrew battery caps using a screwdriver that
fills the screw cap channel. Disconnect existing batteries at white 2-pin
connector; then connect replacement battery. Screw on battery caps.
To ensure water-tight seal, apply 30-32 in-lbs force to AA cap and 32-34
in-lbs force to C cap until cap is flush with body.
FOR ADDITIONAL INSTRUCTIONS,
SCAN QR CODE OR VISIT:
SMARTGRIDSOLUTIONS.COM/INSTRUCTIONS/FI5A
FI-5A FAULT
INDICATOR
INSTRUCTIONS
v325250HN
