Product Features
Thanks for purchasing this
PL60C is a powerful 60W full-color RGBCW LED video panel light, designed
to deliver high illuminance and a wide color temperature range. With
features like master/slave mode and app control, this light offers versatile
control options. You can easily manage it through the app, onboard
buttons, 2.4G remote, or DMX consoles. These multiple control methods
cater to both professional users and amateurs, ensuring everyone can
make the most of this exceptional lighting experience.
Package Contents
PL60C RGB Video Light X1
Carrying Bag X1
product.
Power AdapterX1
AC Power Cable X1
User Manual X1
Product Overview
INT Dial Sound Detector
Stand Mount Lock
Power Switch
ON/OFF
01
Barndoors
Cooling Fans
SET Dial
MODE/MENU Button
1
5
5
1
2
4
4
2
3
3
Power
DMX
DMX
Input
Input
Output
EN
Tilt Lock
LCD Screen
/2.4G Button
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for NEEWER PL60C
Summary of Contents for NEEWER PL60C
- Page 1 Product Overview Thanks for purchasing this product. PL60C is a powerful 60W full-color RGBCW LED video panel light, designed to deliver high illuminance and a wide color temperature range. With features like master/slave mode and app control, this light offers versatile control options.
- Page 2 , which relates to the Infinity connection. To control with a smartphone, the smartphone needs to connect to the light via the NEEWER APP． detailed information, please scan the QR code on the "APP Introduction" page of the APP prompt card.
- Page 3 Introduction to Functions Introduction to Functions ② FAN MODE Version Number Short press SET Dial, then turn SET Dial to select between S m a r t / M i d - L e v e l / S i l e n t modes ③...
- Page 4 ON. Short press SET 2. Activate Bluetooth on your smartphone DMX ADDR 001-512 Dial, then turn SET Dial to set channel values 3. Open NEEWER APP→Add Devices→Settings → Version→Firmware Update ⑦ INFINITY RESET Short press SET Dial, then turn SET Dial to select "YES"/"NO"...
- Page 5 Introduction to Mode Functions Introduction to Mode Functions RGBCW CH： 08 CH： 08 Short press MODE/MENU Button until "CCT" appears on the screen. Short press MODE/MENU Button until "RGBCW" appears on the screen. Short press SET Dial to switch between settings, turn it to adjust color Short press SET Dial to switch between settings, turn it to adjust temperature (2500K~10000K)/GM correction values (-50~+50).
- Page 6 Introduction to Mode Functions Introduction to Mode Functions CH： 08 CH： 08 0.7080 0.2920 Short press MODE/MENU Button until "FX" appears on the screen. Short Short press MODE/MENU Button until "XY" appears on the screen. Short press SET Dial to switch between settings, turn it to select different press SET Dial to switch between settings, turn quicky to adjust X/Y lighting scenes and lighting effect speed.
-
Page 7: Installation Instructions
Installation Instructions Operating Instructions Method 1: Power the light using the supplied power adapter. Insert one end of the power adapter into the power input jack and the other end into the wall socket. Move the power switch into the ON position, ①... - Page 8 *If the DMX signal is lost, the light will recall the last signal used. DMX console control： ※ In DMX mode, please refer to the "PL60C DMX Channel Table" appendix for related control schemes. 1. Connect the DMX cable to DMX console.
-
Page 9: Troubleshooting
Troubleshooting Operating Instructions When purchasing DMX cables from a third party, please Low voltage protection check the interface protocol and make sure it is compati- ble with the light. DMX interface protocol is shown below: Low Input Voltage High temperature protection High Temperature Data （-）... -
Page 10: Specifications
Caution Specifications 1.Avoid staring directly at the lights to prevent harm to your vision. Model PL60C 2.Ensure efficient heat dissipation by not covering the vents with Number of LEDs clothes or other objects. 3.Refrain from touching the product with wet hands, as it may Power damage the circuit panel.
