CLASSIC GABLE SHED
STOP!
CONTACT US FIRST!
DO NOT RETURN TO STORE
For help with assembly or product information
contact us at...
CALL: 1-330-893-4212
EMAIL: support@cottagekits.com
LIVE CHAT: www.cottagekits.com
SUPPORT HOURS: M-F 8:00 AM to 4:30 PM EST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLASSIC GABLE SHED and is the answer not in the manual?

Questions and answers

Related Manuals for Little Cottage CLASSIC GABLE SHED

Summary of Contents for Little Cottage CLASSIC GABLE SHED

  • Page 1 CLASSIC GABLE SHED STOP! CONTACT US FIRST! DO NOT RETURN TO STORE For help with assembly or product information contact us at... CALL: 1-330-893-4212 EMAIL: support@cottagekits.com LIVE CHAT: www.cottagekits.com SUPPORT HOURS: M-F 8:00 AM to 4:30 PM EST...
  • Page 2 (This page intentionally left blank.)
  • Page 4 (This page intentionally left blank.)

  • Page 5: Assembly Manual

    CLASSIC GABLE SHED ASSEMBLY MANUAL SIZES: 8x8, 8x10, 8x12, 8x14, 8x16, 10x10, 10x12, 10x14, 10x16, 10x18, 10x20, 12x12, 12x14, 12x16, 12x18, 12x20, 12x24 -CUSTOMER SERVICE- www.cottagekits.com SUPPORT HOURS Monday-Friday support@cottagekits.com 8:00am-4:30pm EST 1-330-893-4212 ©2024 Little Cottage Co.

  • Page 6: Before You Begin

    BEFORE YOU BEGIN VERIFY PARTS Ensure all components listed on the parts lists are present and undamaged. SITE PREPARATION Ensure proper assembly by building your shed on a level surface. See our recommendations for site preparation on pages 4-5. LOCAL BUILDING CODES Confirm compliance with local regulations and obtain any necessary permits.

  • Page 7: Additional Materials

    ADDITIONAL MATERIALS You will need these additional materials to complete your shed. For best results, we recommend using 100% acrylic latex exterior paint and applying two coats of paint to the siding. SIZE 3-TAB SHINGLES PAINT FOR SIDING PAINT FOR TRIM DRIP EDGE (Bundles) (Gallons)

  • Page 8: Site Preparation

    Note: Before assembling your shed, preparing a solid and level foundation is necessary. Failure to construct a proper foundation may lead to settling, which can cause distortion and damage to the structure. Little Cottage Co. is not responsible for replacing parts damaged or property lost due to incorrect assembly.
  • Page 9 SITE PREPARATION c. 4x4 Runners and Blocks: Level the ground using treated 4x4 runners supported by concrete blocks. Place blocks on a gravel bed at regular intervals to ensure stability and elevation above ground, which helps in preventing moisture buildup. 4x4 Runner Level Shingle...
  • Page 10 INDEX A 10x14 Classic Gable Shed was used in this assembly manual. You will be following the Parts Lists and Layout NOTE: Diagrams provided for placement and using this assembly manual as a guideline. Parts Lists Layout Diagrams Manual Section Page(s) A.
  • Page 11 PARTS RE UIRED: Refer to Floor Parts List Some type of flooring is required. If you did not purchase a floor from Little Cottage Co. you must provide your own. Sidewalls must not be in direct contact with the ground.
  • Page 12 FLOOR PARTS RE UIRED: Refer to Floor Parts List Note: This step applies only to 10-foot & 12-foot wide units. If your unit is 8-foot wide, proceed to the next step. Once both sections are assembled, position them side by side ensuring they are flush on the ends.
  • Page 13 FLOOR PARTS RE UIRED: Refer to Floor Parts List Locate the floor panels using the Floor Parts Lists. Following the Floor Layout Diagram, set 1 corner floor panel in place. Ensure the panel is flush with the 2x4s on the floor frame by using a speed square.
  • Page 14 FLOOR PARTS RE UIRED: Refer to Floor Parts List Following the Floor Layout Diagram, continue installing floor panels until they are all complete. Flush Flush Flush Door 12" 6" 6" Flush Check if the floor frame is level after installing floor panels, and re-level if needed. Door You have completed the floor installation.

  • Page 15: Front Wall

    FRONT WALL PARTS RE UIRED: Refer to Wall Parts List The floor should serve as a stable work surface for constructing the walls. Plan your assembly process carefully during the build to minimize excessive handling of the walls. Front Wall Sidewall Sidewall Back Wall...
  • Page 16 FRONT WALL PARTS RE UIRED: Refer to Wall Parts List 72" Door Header 72" 72" Stud Double Studs To create the double 72” studs To install the door header, ensure that go next to the door opening, it is aligned with the end of one 72”...
  • Page 17 FRONT WALL PARTS RE UIRED: Refer to Wall Parts List Align the top plate(s) so they meet at the center of the door header. Use a tape measure to make sure the door header is centered. Using 3-inch nails, fasten the top plate(s) to the ends of the 72”...
  • Page 18 FRONT WALL PARTS RE UIRED: Refer to Wall Parts List Locate a temporary 20” long 2x4 block and secure it to the top plate using 3” screws, leaving a 5-1/2 inch overhang. Repeat on the opposite side. 2x4x20" Top Plate 2x4x20"...
  • Page 19 FRONT WALL PARTS RE UIRED: Refer to Wall Parts List If your Wall Layout Diagram Secure one gusset to rafters with 2-inch indicates a collar tie, fasten it to nails, staggered, as illustrated. the rafters with 3-inch nails. Contact at Peak Note: Smaller sizes may not require collar ties Gusset...
  • Page 20 FRONT WALL PARTS RE UIRED: Refer to Siding Parts List Locate the parts required for this Before fastening the siding, keep a section B using the Siding Parts List. 3-inch skirt past the bottom plate of Referring to the Siding Layout Diagram, wall and a 3 1/2-inch skirt past the place the siding on the front wall as sides of the wall.
  • Page 21 FRONT WALL PARTS RE UIRED: Refer to Siding Parts List Install each piece of siding in order of the siding numbers listed on the Siding Layout Diagram. Fasten the siding to the wall frame using 2-inch nails spaced 6” to 8”. Remember to keep a 3-inch skirt past the bottom plate of wall and a 3 1/2-inch skirt past the sides of the wall.
  • Page 22 FRONT WALL PARTS RE UIRED: Refer to Siding Parts List Note: Larger sizes may have smaller piece(s) of siding to install at the top of the wall. We recommend caulking these pieces at the seam. Caulk Flush Primed side UP Siding #4 Siding #5 Siding #5...
  • Page 23 BACK WALL PARTS RE UIRED: Refer to Wall Parts List Locate the parts required for this section C using the Wall Parts List. Following the Wall Layout Diagram, arrange the components for the back wall on a level surface. The diagram will indicate the required spacing between each part. Collar Tie Rafters Top Plate(s)
  • Page 24 BACK WALL PARTS RE UIRED: Refer to Wall Parts List Locate the temporary 20” long 2x4 blocks and 3-inch screws from step 21. Secure them on both sides of the wall ensuring they measure 5-1/2 inches from the edge. 2x4x20" Top Plate 2x4x20"...
  • Page 25 FRONT WALL PARTS RE UIRED: Refer to Wall Parts List If your Wall Layout Diagram indicates a collar tie, fasten it to the rafters with 3" nails. Note: Smaller sizes may not require collar ties Peak Rafter Collar Tie Rafter You have finished building your front wall frame.
  • Page 26 BACK WALL PARTS RE UIRED: Refer to Siding Parts List Locate the parts required for this Before fastening the siding, keep a section C using the Siding Parts List. 3-inch skirt past the bottom plate of Referring to the Siding Layout Diagram, wall and a 3 1/2-inch skirt past the place the siding on the back wall as sides of the wall.
  • Page 27 BACK WALL PARTS RE UIRED: Refer to Siding Parts List Install each piece of siding in order of the siding numbers listed on the Siding Layout Diagram. Fasten the siding to the wall frame using 2-inch nails spaced 6” to 8”. Remember to keep a 3-inch skirt past the bottom plate of wall and a 3 1/2-inch skirt past the sides of the wall.
  • Page 28 BACK WALL PARTS RE UIRED: Refer to Siding Parts List Note: Larger sizes may have smaller piece(s) of siding to install at the top of the wall. We recommend caulking these pieces at the seam. Caulk Siding #9 Siding #10 Siding #10 Primed side UP Flush...

  • Page 29: Rafter Assembly

    RAFTER ASSEMBLY PARTS RE UIRED: Refer to Rafter Parts List Locate the parts required for this section D using the Rafter Parts List. You will be assembling the remaining rafters with gussets to create trusses. Check the Rafter Layout Diagram to determine the amount needed to assemble. Place the back wall upside down on the floor.
  • Page 30 RAFTER ASSEMBLY PARTS RE UIRED: Refer to Rafter Parts List Repeat steps 32-34 and assemble the rafters until they are all complete. Set them aside for later installation. Remove the temporary 20” long 2x4 blocks on both sides of the back wall. 2x4x20"...
  • Page 31 SIDEWALL PARTS RE UIRED: Refer to Wall Parts List Locate the parts required for this section E using Wall Parts List. Following the Wall Layout Diagram, arrange the components for one sidewall on a level surface. The diagram will indicate the required spacing between each part. The bottom and top plates will also be marked for placement.
  • Page 32 SIDEWALL PARTS RE UIRED: Refer to Wall Parts List Place the 2x6 top plate on top of the 2x4 top plate as shown. Using a speed square, keep flush on the inside of the wall and flush on the end. 2x6 Top Plate Flush 2x4 Top...
  • Page 33 SIDEWALL PARTS RE UIRED: Refer to Siding Parts List Locate the parts required for this section E using Siding Parts List. Referring to the Siding Layout Diagram, place the siding on the side wall as shown in the diagram. There will be a 3-inch skirt at the bottom of the wall.
  • Page 34 SIDEWALL PARTS RE UIRED: Refer to Siding Parts List Next, fasten the siding to the bottom plate using 2-inch nails. Use a speed square to make sure it is flush on the side of the wall. Flush 3" Remember to keep a 3-inch skirt past the bottom plate of wall. Continue installing the piece of siding on the wall frame.
  • Page 35 SIDEWALL PARTS RE UIRED: Refer to Siding Parts List Continue installing the remaining siding panels in the same manner as described in steps 42-45, assembling from left to right. Arrange the components for the second Sidewall and assemble it following the same method as outlined in steps 38-46.

  • Page 36: Wall Installation

    WALL INSTALLATION PARTS REUIRED: SidewallG You will now be installing the sidewalls to the floor. Place one sidewall on the very edge of the floor with the 3-inch skirt against the floor. Keep the wall flush at the end as shown below.
  • Page 37 WALL INSTALLATION PARTS REUIRED: SidewallG From the inside, fasten the sidewall to the floor using 3-inch nails, spacing them every 16 inches. Door 16" 16" 16" 16" 16" 16" 16" 16" 16" 16" Repeat steps 48-50 for the opposite sidewall. Door Your Sidewalls are now installed.
  • Page 38 WALL INSTALLATION PARTS REUIRED: Back WallG You will now be installing the back wall to the floor. Position the back wall in place so the bottom of the wall plate sits on the interior floor and between the two sidewalls. Assistance Required;...
  • Page 39 WALL INSTALLATION PARTS REUIRED: Back WallG Fasten the edges on both sides of the wall using 2-inch nails, spacing them every 8 inches. 8" 8" 8" 8" 8" 8" 8" 8" 8" From the outside, fasten the bottom of the wall to the floor using 2-inch nails. Do not nail in groove.
  • Page 40 WALL INSTALLATION PARTS REUIRED: Front WallG Locate the front wall and set it into place. Using a tape measure, measure the door opening on the bottom. 8-foot wide units should measure exactly 48 inches while 10-foot and 12-foot wide units should measure exactly 60 inches. Assistance Required;...
  • Page 41 ROOF PARTS RE UIRED: Refer to Rafter Parts List Locate the parts required for this section G using the Rafter Parts List. Place one rake block, ensuring it is flush with the 2x6 top plate on both the outside edge and underneath.
  • Page 42 ROOF PARTS RE UIRED: Refer to Rafter Parts List Locate the rafters/trusses you assembled in section D. Place the first truss into place using the pre-marked locations on the top plate. Refer to your Rafter Layout Diagram as a guide. 2x6 Top Plate 2x6 Top Plate Ensure the truss is flush with the...
  • Page 43 ROOF PARTS RE UIRED: Refer to Rafter Parts List Install the remaining trusses at the pre-marked locations, ensuring they are spaced 24-inches on-center. Your wall rafter are now installed. Note: This step applies only to units that are 14 feet in length or longer. If your unit does not require a wall brace, proceed to the next step.
  • Page 44 ROOF PARTS RE UIRED: Refer to Rafter Parts List Use a tape measure to ensure the shed's front and back wall widths match the widths where the wall brace(s) will be installed. X must be the same X" X" X" Secure each brace with 3-inch nails.
  • Page 45 ROOF PARTS RE UIRED: Refer to Roof Parts List Locate the roof paneling required for this section H listed on the Roof Parts List. Using the Roof Layout Diagram as a guide, position the #1 paneling accordingly. Use a tape measure and adjust the panel to allow a 6”...
  • Page 46 ROOF PARTS RE UIRED: Refer to Rafter Parts List Locate the 2 sets of 4 rakes listed on Peak the Rafter Parts List. Fasten 2 rakes together using 3-inch nails so they meet at the peak. Repeat this process with the other set. Lift one assembled rake and position it under the roof paneling.
  • Page 47 TRIM PARTS RE UIRED: Refer to Wall Parts List Locate the fascia trim required for this section H using the Wall Parts List. Referring to the Wall Layout Diagram, align the trim with the 2x6 top plate and rake. Secure the trim with 2-inch nails.
  • Page 48 TRIM PARTS RE UIRED: 2-3/4"x78" Corner Trim 2-3/4"x75" Door Trim 2-3/4"x67" Door Trim Locate the 8 corner trim pieces. Ensure each piece is flush in the corner and against the rake block then fasten two pieces of trim to each corner using 2-inch nails. Repeat this process on all corners of the building.
  • Page 49 DOOR PARTS RE UIRED: 3/4"x60"x3/4" Door Stop Barrel Bolt Block 3/4"x71"x3/4" Door Stop Locate the 3 door stop pieces. Ensure that when installing these, they are flush with the 2x4 door header rather than the siding. Start by attaching the top door stop using 2-inch nails.
  • Page 50 DOOR PARTS RE UIRED: Siding Below Door #1 Siding Below Door #2 Left Door Referring to your Siding Layout Diagram, locate the 3-inch siding piece(s) for installation beneath the door. Make sure it is flush with the top of the floor, then fasten it securely using 2-inch nails.
  • Page 51 DOOR PARTS RE UIRED: 2-1/2" screw 1-1/4" screw Right Door Secure the left door by fastening two 2-1/2-inch black-headed screws per hinge. Then, complete the installation by filling in the remaining screw holes with 1 1/4-inch screws. 2-1/2" screw 1-1/4" screw Place the right door into position, ensuring both doors are aligned with approximately a 1/4”...
  • Page 52 DOOR PARTS RE UIRED: Barrel Bolt 1-1/4" screw Locate the barrel bolts. From the inside, install the barrel bolt at the top left of the right-hand door (when inside) using 1-1/4-inch screws, with the barrel facing upwards. Close the door and gently tap the barrel bolt against the barrel bolt block to make a mark.
  • Page 53 DOOR PARTS RE UIRED: Locate the door handle. Insert the door handle, centered, in the pre-drilled hole. Secure the T-Handle with 1-1/4 inch black headed screws. Pre-drilled Hole Install the D-Handle on the inside of the door. Use an allen wrench to tighten the D-Handle as shown below.
  • Page 54 VENTS PARTS RE UIRED: Vents 1/2" screw Align the vents over the cutout vent holes and secure using (6) 1/2” screws. Repeat on the opposite end. You have finished installing the vents. ASSEMBLY QUESTIONS? CALL: 330-893-4212 - EMAIL: SUPPORT@COTTAGEKITS.COM - LIVE CHAT: COTTAGEKITS.COM...
  • Page 55 DRIP EDGE PARTS RE UIRED: Refer to Page 3. Next you will be installing the drip edge. Drip edge is not included in this kit. Refer to the Parts List to determine the quantity required. Fasten the drip edge around the Continue installing the drip edge perimeter of the roof using 3/4-inch along the front and back.
  • Page 56 SHINGLES PARTS RE UIRED: Refer to Page 3. Shingles are not included in your kit. Refer to the Packing List for the quantity needed to purchase. Follow the instructions provided with your shingle package. Familiarize yourself with a 3-tab shingle Sealing Strips Notch Notch...
  • Page 57 SHINGLES PARTS RE UIRED: Refer to Page 3. Continue to install the remaining shingles in a staggered fashion until both sides of the building are complete. ASSEMBLY QUESTIONS? CALL: 330-893-4212 - EMAIL: SUPPORT@COTTAGEKITS.COM - LIVE CHAT: COTTAGEKITS.COM...
  • Page 58 SHINGLES PARTS RE UIRED: Refer to Page 3. Cut shingles into THREE pieces. 2" 2" 2" 2" 2" 2" Weather Seal Top of slot. Install first ridge cap flush to shingles at front then install second ridge cap 5" back as shown below.
  • Page 59 SHINGLES PARTS RE UIRED: Refer to Page 3. Install flush to shingles. 2 Nails per side You have finished installing your shingles. ASSEMBLY QUESTIONS? CALL: 330-893-4212 - EMAIL: SUPPORT@COTTAGEKITS.COM - LIVE CHAT: COTTAGEKITS.COM...
  • Page 60 ENJOY YOUR PRODUCT! Your Classic Gable Shed is now fully assembled, primed, and ready to paint! For required paint quantities, please refer to page 3. Thank you for purchasing from LITTLE COTTAGE CO. www.cottagekits.com...
