Device Connection
1. Turn on the Bluetooth button on the panel. Connect your smartphone or tablet to the panel
via Bluetooth. The panel is connected to the PoE switch via an Ethernet cable.
2. Connect your smartphone or tablet directly to the panel using a 3.5mm to dual RCA cable.
The panel is connected to the PoE switch via an Ethernet cable.
Device Installation
This content outlines the steps for connecting and installing audio devices using both wireless
and wired methods, with a focus on integrating with a PoE switch and Dante audio network.
Common Troubleshooting
If the panel indicator light is off, check whether the network cable or switch is functioning
properly.
Precautions
Be careful when installing the panel to avoid scratching its surface.
Maintain an appropriate working temperature.
Avoid using the device in a humid environment.
Do not place any corrosive chemicals or liquid alcohol on or near the device.
Packing List
Panel
1 piece
Quick Guide
1 copy
Installation Accessories
1 piece
Warranty card
1 copy
Certificate of conformity
1 copy
Quick Guide
MDM-BT
Advertisement
Related Manuals for Dateq MDM-BT
Summary of Contents for Dateq MDM-BT
- Page 1 Be careful when installing the panel to avoid scratching its surface. Maintain an appropriate working temperature. Avoid using the device in a humid environment. Do not place any corrosive chemicals or liquid alcohol on or near the device. Packing List MDM-BT Panel 1 piece Warranty card 1 copy...
- Page 2 Equipment Introduction Device Connection & Installation Wireless devices such as smartphones and iPads can connect to the panel via Bluetooth or a 3.5mm to RCA cable. The panel is powered by a PoE (Power over Ethernet) switch, converts analog audio to Dante audio, and outputs it to the switch. Finally, the Dante Controller software on the computer configures the output to the backend.
