- Page 1 USER MANUAL SMART WIFI RADIATOR VALVES STRV-W1-WH STRV-W1-B STRV-W1-AG Thank you for choosing electriQ. Please read this user manual before using this Smart Valve and keep it safe for future reference. Visit our page, www.electriQ.co.uk, for our entire product range.
-
Page 3: Table Of Contents
CONTENTS SAFETY WARNINGS PRODUCT OVERVIEW PARTS LIST INSTALLATION CONTROL PANEL OPERATION SETTING UP THE APP USING THE APP CLEANING AND MAINTENANCE TROUBLESHOOTING ERROR CODES TECHNICAL SPECIFICATION SUPPORT DECLARATIONS... -
Page 4: Safety Warnings
SAFETY WARNINGS For your continued safety, please follow all the safety precautions listed below: • This device is designed for residential indoor use • Keep small parts and packaging out of reach of only. Please do not use it outdoors or in children to avoid choking hazards. -
Page 5: Battery Installation
VALVE ADAPTER INSTALLATION If your connector type is not M30 x 1.5, you will need to mount the adapter on the valve. Adapter sets and their corresponding installation can be found in the diagrams below: Danfoss RA valves Danfoss RAV valves Danfoss RAVL valves Caleffi valves Giacomini valves... -
Page 6: Control Panel
• Adjust the angle of the thermostat to ensure the LCD display is clearly visible. • Press the middle button to start the adaptation process. A flickering " " will appear on the display, indicating that the thermostat is adjusting itself to fit the radiator valve. -
Page 7: Setting The Temperature
External Thermostat Placement: If using an external thermostat, place it in an area away • from the smart valves and your warmest room. The thermostat will override the smart valves. Anti-Frost Mode: The valves will not operate if your boiler or heat pump is off or in non- •... - Page 8 CUSTOM MODE The “ ” icon on the display signifies custom mode. The device follows the temperature set manually until further changes are made. The screen alternates between displaying the room temperature and the set point temperature (indicated by the "SET" icon). NOTE: Custom Mode is the default setting until the device is connected to the network.
-
Page 9: Setting Up The App
WINDOW OPENING DETECTION The device detects sudden temperature drops to conserve energy when windows are open. How It Works: If the room temperature drops by more than 1.5°C within 5 minutes, the valve will close, stopping heating for 30 minutes. The screen will display "... -
Page 10: Connecting The Device
DOWNLOAD THE APP TO YOUR PHONE You can download the” Tuya SMART” app from your chosen app store by using the QR codes below or searching for the app in your chosen store. CONNECTING THE DEVICE There are two ways to enter connection mode: 1) In customised mode, turn the dial counterclockwise until the screen displays “OFF”. -
Page 11: App Connection
APP CONNECTION NOTE: Some images may differ from the current app due to continuous product improvement. You can download it from the Apple or Google Play Store. 1. Press the register button 2. Read the Privacy policy 3. Enter your email at the bottom of the and press the Agree address or phone... - Page 12 SETTING UP YOUR HOME WITHIN THE APP The app allows you to set up multiple homes, rooms, and devices, so you must set up at least one to get started. 1. Select ‘Me’ at the bottom of 2. Create and name your home, 3.
- Page 13 CONNECTING TO THE UNIT 2. Ensure your phone is 3. Connect to the 2.4 GHz connected to the same 1. Select the 'Add' button in the network. Enter the Wi-Fi Wi-Fi as the unit. Then app in the top corner. Then, password and then wait for select 'Small Home select 'Add Device'.
-
Page 14: Using The App
DEVICE HOME SCREEN... -
Page 15: Advanced Settings
ADVANCED SETTINGS To enter advanced settings, click settings on your home screen, scroll down, and then select advanced settings. This is not the mode of the smart valves but your overall heating system control if you have one. To set the highest temperature the valves can reach. - Page 16 PROFILE TAB The profile tab allows you to edit both your details and use the added features of the unit. HOME MANAGEMENT Home Management provides options for managing your Tuya account, such as adding a home, adding and removing rooms, and sharing devices with family.
-
Page 17: Cleaning And Maintenance
CLEANING AND MAINTENANCE IMPORTANT: Turn off the radiator before cleaning the valve. • Clean the exterior with a dry or slightly damp cloth. Do not use abrasive materials or solvents or immerse the device in water. • Periodically check for signs of damage or wear. Replace the device if its performance is compromised. -
Page 18: Error Codes
Poor quality battery and insufficient power. Replace the batteries immediately. Low battery. Replace the batteries within 1 week. TECHNICAL SPECIFICATION MODEL STRV-W1-WH / STRV-W1-B / STRV-W1-AG DIMENSIONS (LxWxH) 59.4 x 59.4 x 94.7 mm WEIGHT 154 g SUPPLY VOLTAGE 3 x 1.5V Alkaline AA batteries TEMPERATURE SETTING ACCURACY 0.5°C... -
Page 19: Declarations
Compliance and Quality Manager, Buy It Direct, Huddersfield December 2024 EU DECLARATION OF CONFORMITY Hereby, electriQ declares that these air conditioners comply with Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following internet addresses: https://www.electriq.co.uk/content/DOC/EU/STRV-W1-WH.pdf https://www.electriq.co.uk/content/DOC/EU/STRV-W1-B.pdf...
