Onkyo TX-SR373 Service Manual
Hide thumbs Also See for TX-SR373:

Advertisement

Quick Links

AV RECEIVER
TX-SR373
✔ Pre Issue (2016-Nov)
✔ Final Issue (2017-Feb)
Service Manual
CONTENTS
Title Page (This page)
Note for Parts List
Panel
Reset
Amp Diag Mode after Abnormal Conditions
Model and Destination
Firmware
Adjustment
Hookup and Setting
Trouble Shoot
Disassembly
Schematic Diagram
Exploded View
Appendix
SAFETY-RELATED COMPONENT WARNING!! : COMPONENTS IDENTIFIED BY MARK
IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE
MESUREMENTS TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT
BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER.
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified
technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex
products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are
not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to
a qualified service technician.
Published by Onkyo & Pioneer Corporation Grobal CS Department
Ref.No. : 4625
ON THE SCHEMATIC DIAGRAM AND

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-SR373 and is the answer not in the manual?

Questions and answers

Summary of Contents for Onkyo TX-SR373

  • Page 1 SAFETY-RELATED COMPONENT WARNING!! : COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE MESUREMENTS TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER.
  • Page 2: Note For Parts List

    File Name of Parts List File (EXCEL File) Note for Parts List When parts list is EXCEL file, please refer to the following explanation about file name. P L _ T X – S R 3 4 3 ( B ) M J J . x l s x Model No.
  • Page 3: Front Panel

    AM loop antenna --- (1) Setup microphone --- (1) Dimensions : 435 mm (W) x 168 mm (H) x 326.5 mm (D) (17 in. (W) 6 in. (H) 12 in. (D) ) Weight (without package) : 8.0 kg (17.6 lbs) TX-SR373...
  • Page 4 Reset How to Reset the Unit TX-SR373...
  • Page 5 At this time, When you press the " ENTER "key to display each UCOM version, Each time the " ENTER "key is pressed, then indications on the FL display change as follows: "ENTER" "ENTER" "ENTER" "ENTER" MAIN Ucom SUB Ucom All segments MAIN Xx.xx lit. firmware zzz.zz Vy,yy "ENTER" 2. Turn the unit off. TX-SR373...
  • Page 6 No Necessary connect Main and HDMI&CEC at the same time GGF1642 When you update Main, you connect Main only. When you update HDMI&CEC, you connect HDMI&CEC only. When you have no “UPDATE jig GGF1642, Please order ONKYO service parts dept. Straight Cable Adapter JIG's side TX-SR373...
  • Page 7 3. Press the OK button. Press the OK button. Select for COM port. Note: You need COM port number on Windows system “My computer”, “Right Click”, “Properties”, “Device manager” Click COM port properaties and Make sure COM port number. TX-SR373...
  • Page 8 File Selection window. Select Intel Hex files (*.hex) in File Type. 6. Update Finished MAIN microcomputer. 7. Unplug the AC cord. Disconnect the FFC cable. Press the OK button. Press the Exit button. Please wait for until this window disappears. TX-SR373...
  • Page 9 5. After the window shown below is displayed, turn the main unit on. Press the Reset button of the updating jig for updating. When it is appeared below window, Then power turn on unit (ON) Click on "OK" 8. TX-SR373...
  • Page 10 Or You have to make sure that It is necessary to turn on the unit at procedure 7 11. Turn the main unit off then disconnect the updating jig for updating. 10. Updating has been successfully completed if 12. Perform Factory Reset on the main unit. "Full Operation OK!" is displayed. TX-SR373...
  • Page 11 4. After playback is finished and "ENTER" is displayed, press the ENTER key on the front panel. ("ENTER" is displayed.) 5. "WRITING" is automatically displayed. 6. After writing is completed, "COMPLETE" is displayed. 7. Turn the unit off then confirm that the version has been updated. TX-SR373...
  • Page 12 Hookup and Setting No Sound ■ No sound from connected player □ Chose input selector which is assigned to connected input terminal ? □ Isn’t muting on ? ■ No sound from connected TV □ Chose wrong input selector ? □...
  • Page 13 Hookup and Setting No Picture ■ In general □ Connection cable is bent , twisted or damaged ? □ Input is switched on TV ? ■ No picture from connected player by HDMI input terminal □ Chose input selector which is connected to player ? □...
  • Page 14 Hookup and Setting No Power ■ In general □ Doesn't be connection cable bent, be it twisted and be it damaged? ■ There is time when indication on the front panel doesn't just light up. □ Please check the connecting cord of a DISPLAY PCB. ■...
  • Page 15: Troubleshoot

    No Power 1/2 Trouble Shoot TX-SR373...
  • Page 16 No Power 2/2 Trouble Shoot TX-SR373...
  • Page 17 No Display Trouble Shoot TX-SR373...
  • Page 18 No Sound 1/5 Trouble Shoot TX-SR373...
  • Page 19 No Sound 2/5 Trouble Shoot TX-SR373...
  • Page 20 No Sound 3/5 Trouble Shoot TX-SR373...
  • Page 21 No Sound 4/5 Trouble Shoot TX-SR373...
  • Page 22 No Sound 5/5 Trouble Shoot TX-SR373...
  • Page 23: Schematic Diagram

    Q9612 DTC114YUA Q9613 330P-K HPD_3 DTC124EUAT106 R9651 SDA_3 HPD_4 R9652 GND-H SCL_3 CEC_IO VA9612 VA9613 H+3.3V R3XC- R3XC+ 778_SCLK R3X0- 778_MOSI GND-H R3X0+ R3X1- R3X1+ R3X2- 100N-K 330P-K R3X2+ JA9603 GND-H HD043-F19G1BY-A 778_CS 778_MISO CEC_IO 778_SCLK 778_MOSI W25X40CLSSIG (4Mbit) TX-SR373...
  • Page 24 C2098 C2097 100N-K 100N-K IIS_SD0/DSD0_L IIS_WS IIS_SD1 L2008 L2007 10UH 10UH C2113 C2088 VOUT = 0.925(R1/R2 + 1) 100N-K 100N-K C2099 2N2-K C2085 10P-J C2083 330P-J C2082 1N-K C2081 100/16(6.3*5.3)-RV2 C2079 100N-K C2077 100P-J CN2003 FROM REGULATOR B'D SF125Z-15T TX-SR373...
  • Page 25 SO/SIO1 R2221 IIS_SCLK AXR1[1] HOLD# SCLK IIS_SD0/DSD0_L SI/SIO0 R2222 DAI_SD0/DSD0_L C2220 C2225 IIS_SD3/DSD0_R IIS_SD3/DSD0_R 1000P-J IIS_SD2 IIS_SD2 1000P-J IIS_SD1 IIS_SD1` SDIN4SB SDIN3C SDIN2S SDIN1F R2195 L2029 BD121T R2288 R2201 R2289 R2224 /EMU1 /EMU0 R2225 R2479 C2249 10N-K /TRST CN2000 TX-SR373...
  • Page 26 DSP_SCL XTAL2003 R246 DSP_SDA 4588_SCL 4M(20P) 4588_SDA 4588_PDN R247 R248 100K 4588_INT CEC_IO D+5.6V_ON GND-H GND-H DSD_SEL D+3.3V_ON D+1.8V_ON D+1.2V_ON D+12V GND-H CB2014 CB2010 CPU_ST_VCC SUB_SCK IC2004 NJM2831F33 SUB_SDO SUB_PDN MAIN_IRQ SUB_SIN DMAIN+5V6 UP_VDD C2015 SUB_TXD SUB_RXD GND-H H+5V TX-SR373...
  • Page 27 D206 LBAS16HT1G 10N-K D211 D207 LBAS16HT1G LBAS16HT1G CPU_+3.3V CPU_+3.3V PROTECT1 DC_DET4 DC_DET3 R249 PTC_DET Q303 2SC3052 ASO_DET R250 POWER_DOWN R256 R257 GNDU ASO_DET DC_DET3 CPU_+3.3V DC_DET4 Q206 C227 2SC3052 2.2/50 IC204 R281 CW24C16DR C219 1N-K R280 DC_PRO C255 C256 TX-SR373...
  • Page 28: Speaker Terminal

    D125 LBAS16HT1G LBAS16HT1G 2K2(1) 2K2(1) 2K2(1) 10/50 4R7(1) 22(1/4) 1N4007 WMP/WMB/WMA : 6800/71(35*40) RT1P237C RT1P237C RT1P237C RT1P237C CDC/CDF/WMR :6800/65(30*40) RT1N237C RT1N237C RT1N237C RT1N237C TO CHASSIS 100N(R)-250V 100N(R)-250V C66 100N(R)-250V LBAS16HT1G VSX531 OPTION GND2 LBAS16HT1G 4 3 2 90MM/10P 130MM/5P TX-SR373...
  • Page 29 470K R566 R565 R568 2SK209Y C556 Q426 C520 33P-J RT1P141C C522 33P-J R569 R571 91K R572 RT1P141C R573 10K RT1N441C R576 R574 10K C557 R577 C529 C528 10N-K 10N-K J417 J402 470K R582 470K R583 R609 470K R610 470K TX-SR373...
  • Page 30 Schematic Diagram IC2009 L1412 SN74AHCU04PWR C1465 L1413 L1414 C1459 R1460 2.2UH BLM18PG121SN1D-BD121 100N-K BD121T 22P-J JACK1306 RCA-107A R1455 R1457 C1464 100N-K C1452 C1453 R1456 C1458 CH)330P-J-50 10N-K R1458 C1466 C1467 R1462 R1463 R1464 CN2010 BKT4 JACK1305 L1411 4.7UH C1457 BCR-802-M25 TX-SR373...
  • Page 31 REGULATOR Schematic Diagram KIA7805API KIA7812API KIA7912PI 100/16(6.3*11) 100/10 100/16(6.3*11) 0R22(1) 1N4007 47N(EB)-100V 1N4007 1N4007 0R22(1) 1N4007 R71/R72 R_NO (3216) (3216) OPEN OPEN 2015.5.13 F100 0R22(1) R284 0R22(1) R286 TX-SR373...
  • Page 32 MAIN ---> BT BT ---> MAIN KEY_5 R328 BT MODULE OPTION MODEL CODE APT-X VSX-531 ALL E100-07032-001-1S HTP-074 ALL VSX-531D WMP E100-07053-001-0S VSX-532 CDC E100-07053-002-0S TX-SR353 ALL E100-07032-002-1S HT-S3800 ALL TX-SR373 WMP/WMB/WMA/WMR E100-07051-002-0S TX-SR373 CDC E100-07051-001-0S HT-S3900 CDC E100-07052-001-0S TX-SR373...
  • Page 33 TD03G333FT R29C R28C KSA992FATA C12C C17C R18C ZD3C 0R47(2) 0R47(2) 100/50(8*11.5) ZJ4.3B R11C R23C 1N4148 R12C R13C 470K R25C C13C R42C 560P-K 100(1) 2N2-K 2SB1560-P KTC3206Y R41C C18C C22C 100P-500V R14C R15C 1K2(1) JUMPER R16C 47(1) C15C 100P-J C16C TX-SR373...
  • Page 34 GND5 DHPTHF1608-95T DHPTHF1608-95T SC52136-031A FL-CH SL-CH CL-CH SR-CH FR-CH KTC3964 KTC3964 KTC3964 KTC3964 KTC3964 2SB1560 2SB1560 2SB1560 2SB1560 2SB1560 2SD2390 2SD2390 2SD2390 2SD2390 2SD2390 Q101FL Q102FL Q101FL Q102FL Q101FL Q102FL Q101FL Q102FL Q101FL Q102FL Q103FL Q103FL Q103FL Q103FL Q103FL TX-SR373...
  • Page 35 R783 R785 R786 R776 R761 V+6.8_A GNDA R793 C745 C763 330P-J R789 R790 R791 C741 C764 R798 R796 C939 C940 C740 C739 R816 1N-K - CM2 C773 F_AUX_L GNDA C775 R795 R814 F_AUX_R R817 C768 R799 [TO CPU B'D] TX-SR373...
  • Page 36 BRIDGE Schematic Diagram C104 TX-SR373...
  • Page 37 NEUTRAL 1N4007 D306 SC52136-091A J301 CP301 JUMPER C305 YW396-03AV D307 1N4007 C302 100N-K 1/50 J302 EXCEPT DLXE JUMPER D308 1N4007 CP303 C315 1/50 CP304 TJC14-3A FLAC FLCT FLAC F301 FUSE C310 DLXE ONLY (120V) (220-240V) WMP,WMA WMB,WMR T6.3AL250V T3.15AL250V TX-SR373...
  • Page 38 2SB1560 2SC3964 2SD2390 2SB1560 2SC3964 2SD2390 2SB1560 2SC3964 2SD2390 2SB1560 2SC3964 2SD2390 PTC B'D MIC/HP B'D TONE B'D HP B'D (TX-SR353) (TX-SR353) (VSX-531) VSX-531 : 28PIN F_USB/MIC B'D F_USB B'D TX-SR353 : 27PIN (TX-SR353) (VSX-531) FRONT B'D (VSX-531) (TX-SR353) TX-SR373...
  • Page 39 LBAS16HT1G PDN' ZJ5.1B LBAS16HT1G 1/50 FL_AC1 CPU B'D FL_AC2 -VF(-30V) HDMI_+12V USB+5V CPU_ST_VCC CPU_ST_VCC F-USB B'D Q702 CPU_ST_VCC CPU_+3.3V VCC_1970 1N4007 1N4007 JE202B1T2 STBY_RLY -6V8 1N4007 +6V8 CPU_+3.3V CORD 1N4007 ST-BY B'D BT B'D POWER B'D (TX-SR353) MIC/HP B'D TX-SR373...
  • Page 40: Power Trans

    GND BLOCK Schematic Diagram AC CORD STBY B'D D-MAIN B'D MICOM REGILATOR MAIN B'D FL_HP FR_HP FL_A FR_A CEN_A CEN_A SL_A SR_A REGULATOR B'D A+12V A+12V A+12V A+12V POWER TRANS AMP B'D FRONT B'D TX-SR373...
  • Page 41: Audio Block

    AUDIO BLOCK Schematic Diagram Q419 Q426 IC2016 TX-SR373...
  • Page 42: Exploded View

    Exploded View Packing TX-SR373...
  • Page 43 Exploded View Overview TX-SR373...
