Onkyo TX-SR333(B) Service Manual
  1. Manuals
  2. Brands
  3. Onkyo Manuals
  4. Stereo Receiver
  5. TX-SR333(B)
  6. Service manual
Onkyo TX-SR333(B) Service Manual

Onkyo TX-SR333(B) Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
AV RECEIVER
TX-SR333(B)/(S)
MODEL
Black and Silver models
B MDC, B MDF
B MMK, B MMQ, B MMR
B MPP, B MPA, S MPP
(European, Australian
and Asian models)
120V AC, 60Hz
220-240V AC, 50/60Hz
230V AC, 50Hz
TX-SR333
Ref. No. 4470-R4
072014
RC-879M

Advertisement

loading
Need help?

Need help?

Do you have a question about the TX-SR333(B) and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo TX-SR333(B)

Summary of Contents for Onkyo TX-SR333(B)

  • Page 1 TX-SR333 Ref. No. 4470-R4 072014 AV RECEIVER TX-SR333(B)/(S) MODEL (European, Australian and Asian models) RC-879M Black and Silver models B MDC, B MDF 120V AC, 60Hz B MMK, B MMQ, B MMR 220-240V AC, 50/60Hz B MPP, B MPA, S MPP 230V AC, 50Hz...
  • Page 2 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-1 AUDIO DEBUG MODE-1/5 The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode. This information will help to analysing digital audio no sound trouble. To set in Debug mode 1.
  • Page 3 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-2 AUDIO DEBUG MODE-2/5 FL Display Step-1 1. st_srd.lmd 3. st_srd.extdecmd C_LM_ASC C_LM_LAST C_EXTDECMD_OFF C_LM_FLASH C_LM_PURE C_EXTDECMD_10 C_LM_DEBUGMODE C_LM_DIRECT C_EXTDECMD_20 C_LM_FLASH2 C_LM_STEREO C_EXTDECMD_MOVIE C_LM_FLASH3 C_LM_MONO C_EXTDECMD_MUSIC C_LM_FLASH4 C_LM_SURR C_EXTDECMD_GAME C_LM_FLASH_CHECK C_LM_THX_MUSIC C_EXTDECMD_HEIGHT C_LM_RPG C_LM_THX_GAME C_EXTDECMD_WIDE C_LM_ACTION C_LM_THX_CINEMA C_LM_ROCKBAND C_LM_THX_U2GAME...
  • Page 4 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-3 AUDIO DEBUG MODE-3/5 Step-3 1 1 1 1 1 1 1 1 1 2 1 2 1 2 1 3 1 3 1 3 11. Source_format 12. st_srd.fs 13. st_hd_display.fs DTSC DDR_DTSCD UNLK DDR_UNLOCK unknown unknown DDR_AAC DDR_ANALOG...
  • Page 5 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-4 AUDIO DEBUG MODE-4/5 Step-5 1 9 1 9 1 9 1 9 2 0 2 0 2 0 2 0 18. Audio output OK/NG 19. Details of input format 20. Details of the format for the FL display C_SRC_ANA decode OK C_SRC_ANA...
  • Page 6 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-5 AUDIO DEBUG MODE-5/5 Step-7 26. AudioIF DA830 input 31. DIR switch sequence number SEQ_SWITCH_POWEROFF AUD_IF_I2S_H CLOCK_FREQ_88K SEQ_SWITCH_RESET AUD_IF_DSD CLOCK_FREQ_96K AUD_IF_I2S SEQ_SWITCH_POWERON_WAIT CLOCK_FREQ_128K SEQ_SWITCH_CHANGE AUD_IF_NET CLOCK_FREQ_176K SEQ_SWITCH_FREE AUD_IF_SPDIF CLOCK_FREQ_192K AUD_IF_ADC 30. DIR sequence number 32. DAC sequence number AUD_IF_DDDTSHR SEQ_DIG_POWEROFF SEQ_DAC_POWEROFF...
  • Page 7 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-6 HDMI RESOLUTION DISPLAY-1/6 HDMI-related operations can be checked to some extent by displaying HDMI resolution display mode. To enter this mode Hold down DISPLAY button for 3 seconds. Information display will last for about 8 seconds. 9 10 11 12 13 Resolution display 1 0 8 0 p /...
  • Page 8 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-7 HDMI RESOLUTION DISPLAY-2/6 Status Input Mode HDMI input 4 4 4 2 4 b i DVI input 4 4 4 2 4 b i 4 4 4 2 4 b i H 1 0 7 4 4 4 2 4 b i Input Color...
  • Page 9 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-8 HDMI RESOLUTION DISPLAY-3/6 9 10 11 12 13 3 8 4 0 x 2 1 6 0 p / Resolution display Press RETURN button Status display 4 2 0 2 4 b i Display list Resolution video Code 3 8 4 0 x 2 1 6 0 p /...
  • Page 10 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-9 HDMI RESOLUTION DISPLAY-4/6 3D Display 10 11 12 13 Resolution display 1 0 8 0 p / 3 D ) Status display F r a m e P a c k i n g 3D format 3D format Frame Packing F r a m e...
  • Page 11 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-10 HDMI RESOLUTION DISPLAY-5/6 PC RESOLUTION 9 10 11 12 13 Input Resolution display 1 0 2 4 x 7 6 8 p / Press RETURN button Status display H 2 5 6 R G B 2 4 b i Display of Input resolution * * * *...
  • Page 12 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-11 HDMI RESOLUTION DISPLAY-6/6 21:9 (1680 x 720 / 2560 x 1080) 9 10 11 12 13 Input Resolution display 2 5 6 0 x 1 0 8 0 p / Press RETURN button Status display R G B 2 4 b i Display of Input resolution...
  • Page 13 TX-SR333/ HT-R393/ HT-RC630 DEBUG MODE-12 SERVICE INFORMATION MODE Displaying Service information This service information display system is helpful in analyze the status when the unit goes into Protect mode and is powered off. Pay attention that the status will change if a button is pushed. 1.
  • Page 14 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-1 NOTATION ABOUT ENTERING TEST MODE BY PRESSING BUTTON In this procedure, the following notations are used to simplify explanation of how to press button. e.g.-1 [TV/CD] + [ON/STANDBY] → [BD/DVD] This means "While holding down TV/CD button, press ON/STANDBY button then release both buttons and then press BD/DVD button".
  • Page 15 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-2 CONFIRMATION OF MODEL NAME AND DESTINATION Model name and destination can be confirmed the following operation. [TV/CD] + [ON/STANDBY] → [DIMMER](RT/PTY/TP) → [TONE] *4 e.g. S R 3 3 3 D x 2 2 0 0 A:Value of AD port of BAND B:Value of AD port of INIT1 C:Value of AD port of INIT2...
  • Page 16 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-3 CONFIRMATION OF VOLTAGE-DETECTION PROTECTORS. <NOTE> Don't connect load nor short speaker terminals. 1. Do the following operation. 1-1. set the volume level to 25. 1-2. [TV/CD] + [ON/STANDBY] → [BD/DVD] 1-3. [TONE +] to the following test mode. TEST 1-01 2.
  • Page 17 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-4 CONFIRMATION OF CURRENT DETECTION PROTECTORS 1. Do the following operation. 1-1. set the volume level to 25. 1-2. [TV/CD] + [ON/STANDBY] → [CBL/SAT] 1-3. [TONE - ] to the following test mode. TEST 1-09 2. Confirm that relay is not cut off even if you connect the following load A to the following channels one by one. 3.
  • Page 18 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-5 CONFIRMATION OF FL TUBE AND LED 1. Do the following operation. [TV/CD] + [ON/STANDBY] → [DIMMER] 2. Confirm that all LEDs and all segments of FL tube are lit. CONFIRMATION OF HEAD PHONE OPERATION Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted into the PHONES jack.
  • Page 19 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-6 CONFIRMATION OF VIDEO SIGNAL-DETECTION 1. Do the following operation. 1-1. set the volume level to 25. 1-2. [TV/CD] + [ON/STANDBY] → [PC] 1-3. [TONE +] to the following test mode. TEST 5-01 2. Confirm the following indicator lights up on the FL TUBE when the following video signal is input. 3.
  • Page 20 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-7 TEST Config. Master Speaker etc. Output Output Output SW/F/C/S Vol. Relay Frequency Voltage Analog Input Only 1-00 SELECTOR MUTING TIME REDUCTION MODE Y/L/L/L 64(Ref) 1-01 IDLING TIMER Timer start Y/L/L/L Min(Min) IDLING TIMER V Protect (FL) +Max Y/L/L/L Max(Max)
  • Page 21 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-8 Auto Measurement Mode TEST DSP Output channel Config. Master Speaker etc. Output Output Vol. Relay Frequency Voltage DSP Gain 4-00 -20dBFS Y/L/L/L 64(Ref) F/CS 1kHz (SW:30Hz) DSP Freq.Response 4-01 -20dBFS Y/L/L/L 64(Ref) F/CS 30Hz (SW:1kHz) 4-02 20kHz -20dBFS...
  • Page 22 TX-SR333/ HT-R393/ HT-RC630 OPERATION CHECK-9 TEST-3-00 Following frequencies are automatically written in the preset memory, when the unit goes into "TEST 3-00". PRESET No. MP*,MG* MW*(10k) MW*(9k) 89.9MHz 89.90MHz 89.90MHz 76.0MHz 97.9MHz 97.90MHz 97.90MHz 82.0MHz 98.9MHz 98.90MHz 98.90MHz 83.0MHz 107.1MHz 107.10MHz 107.10MHz 84.0MHz...
  • Page 23 TX-SR333/HT-RC630 ADJUSTMENT PROCEDURE ADJUSTMENT OF IDLING CURRENT Applied to the following model. (Model) TX-SR333/HT-RC630 Procedure a. Pre-adjustment Set the following registers to minimum position before POWER ON. Set the voltages at the following terminals to the following voltage by adjusting the following registers, under the condition of no input and no load, immediately after POWER ON.
  • Page 24 The contents of the “Firmware Update” is “Confidential Information” as defined in the applicable “Service Center Agreement”. It is for the exclusive use of Onkyo/Integra Authorized Independent Service Centers. Dissemination or posting of this Firmware Update to any non-authorized individual or company is strictly prohibited.
  • Page 25 TX-SR333 / HT-R393 / HT-RC630 FIRMWARE UPDATE-2/2 USB Update (service mode) [Procedure] Overwriting is also possible. 1. Turn on the unit. It takes some time to start after you switch on the unit. 2. Select the USB input source. 3. Connect the USB storage device to USB port (rear panel) on the unit. Wait until Initializing of USB/NET finishes. 4.
  • Page 26 TX-SR333 TX-SR333 EXPLODED VIEW OVERALL <NOTE> A401 Silver Model only No description screw is 3TTB+8B(3BC). 3TTB+8B(BC) 3TTB+8B(3CM)SR Unit : mm x 9 pcs. MDF only WiFi & Bluetooth Module has already been certificated by FCC and IC. 3TTF+10B(3BC) Information to the user. Indicate "Contains FCC ID: TX2-RTL8723AS", "Contains IC: 6317A- RTL8723AS"...
  • Page 27 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-01 BLOCK DIAGRAM(1/2) MODEL NO. TX-SR333/HT-RC630/HT-R393 BLOCK DIAGRAM (PART-1) BAETC-1662 WiFi BAPRC-1670 Module P605 BAAF-1650 BACLA-1552 SR333/RC630 P7201 BACLA-1654 HT-R393 P3101 USB2.0 VDD_VBUS0_5V MAIN USB1 IN-L6 FL_OUT Tone +29dB SPLE IN-R6 USB1.1 TV/CD HPDET USB_POWER C_OUT IN-L5 2:D3 SW_OUT HP GND...
  • Page 28 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-02 BLOCK DIAGRAM(2/2) T901 MODEL NO. TX-SR333/HT-RC630/HT-R393 BLOCK DIAGRAM (PART-2) BAPS-1663 BAVD-1661 P901A P901A D201 T902 BAETC POFF -1660 +12V_ST +12V F201 GNDDG +10VS GND_12V POWERD S1H- 1:K4 SEC1H F901 S1H+ RL901 RL644 F6402 AC_S1L- D6401 P911 F6401 RL643 +B1H_B...
  • Page 29 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-03 ASP SECTION MODEL NO. TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM (PART-3) ASP U0090 U0080(2/5) TUNER PACK HDMI TUNER PACK to P101A to P8001B TUNER 2.5mm FFC CABLE FROM BAPRC-1670(PART-15) TO MAIN AMP P101B P8001B 1.0mm Pitch FFC (PART4) 1 2 3 4 5 6 7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 BAAF-1672(1/2) TUNER_VCC...
  • Page 30 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-04 AMP SECTION MODEL NO. TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM (PART-4) P6401B P6402B CRIMP AS CRIMP AS (RED) (BLU) BAAF-1672(2/2) GNDSP L ASP/AMP +B1C +B1C HPDET AV=29dB AV=29dB +57V GNDDG IPRO IPRO U0010(2/2) R6080 Q6050 R6083 Q6053 0.6V 0.6V 2SC5198-O 2SC5198-O 0.22...
  • Page 31 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-05 DIGITAL/VIDEO SECTION MODEL NO.TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM(PART-6)DG SECTION U0080(2/5) MODEL No. TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM (PART-8) VIDEO SECTION HDMI to P8003A TO BAPRC-1670(PART-15) NSCT-9P2243 BAVD-1661 P8003B U0043 1 2 3 4 5 6 7 8 9 BADG-1664 U0013 DIGITAL IN C2116 103K...
  • Page 32 TX-SR333/HT-RC630 TX-SR333/HT-RC630 SCHEMATIC DIAGRAMS-06 CLASS-A SECTION MODEL NO. TX-SR333/HT-RC630 SCHEMATIC DIAGRAM(PART-7) AMP SECTION BACLA-1522 U0030 R5183 CLASS A 1/4W R6023 1/4W Q5033 INA6006AP1-T111-1W NFSL GNDIN SL IN_SL C5013 +B1SL 47u 50V R5003 R5023 R5033 -B1SL +BSL 1/4W +BSL2 -BSL2 TRIMSL R5043 R5293 1.8k...
  • Page 33 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-07 DISPLAY SECTION BADIS-1658 MODELNO.TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM (PART-12) DISPLAY SECTION U0040 Q7002 16-BT-168GNK FLAC2 C7012 C7011 Ek(+8.2V) 223K 223K C7010 223K R7007 R7008 FLDCLK FLDSDO L7032 FLDCS LBC2518T2R2M KEYINT0 FLDRST KEYINT1 REMIN R7022 +3 3S VP(-32V) KEY3 R7023 VOLA KEY2...
  • Page 34 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-08 KEY /PHONE SECTION MODEL NO.TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM (PART-11) HEADPHONE SECTION U0044 BAETC-1662 HEADPHONE MODEL NO. TX-SR333/HT-R393/HT-RC630 J7201 SCHEMATIC DIAGRAM (PART-10) DISPLAY SECTION GND DG P7201 HPDET L7201 BLUE R7201 U0041 BASW-1659 D7654 R7605 PURE AUDIO:OTHER BLUETOOTH:T5US LBC2518T2R2M 1/2W GND_HP...
  • Page 35 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-09 POWER SUPPLY SECTION MODEL NO. TX-SR333/HT-R393/HT-RC630 SCHEMATIC DIAGRAM (PART-13) PS SECTION THE COMPONENTS IDENTIFIED MARK ARE CRITICAL FOR SAFETY, REPLACE ONLY WITH PART NUMBER SPECFIED. CAUTION VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE. (NO INPUT SIGNAL) FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, ELECTRLYTIC CAPACITORS ( ) ARE IN uF/WV.
  • Page 36 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-10 PRC SECTION-1/5 ModelNo.TX-SR333/HT-RC630/HT-R393 SCHEMATICDIAGRAM (PART-14) MPU Section UPGRADE MAIN_J-TAG P751A P752A NSCT-9P2472 NSCT-9P2472 1 2 3 4 5 6 7 8 9 BAPRC-1670 (1/5) U0040(1/5) R7143 Q705 R7142 VOUT 4 NC 3 S-58LM20A-N4T1U R152 Q153 VCC 8 R151 HOLD 7 SCK 6...
  • Page 37 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-11 PRC SECTION-2/5 ModelNo.TX-SR333/HT-RC630/HT-R393 U0013 U0010(2/2) U0010(1/2) SCHEMATICDIAGRAM(PART-15) to P8003B BAAF-1672 (PART-3) ASP Sec. to P801A to P8001B BADG-1664 (PART-7) DIR/DAC Section P8001A P801B NSCT-9P2472 IMSA-9618S-21A IMSA-9618S-07A P8003A 1 2 3 4 5 6 7 8 9 BAPRC-1670 (2/5) U0080(2/5) To Micon section...
  • Page 38 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-12 PRC SECTION-3/5 ModelNo.TX-SR333/HT-RC630/HT-R393 SCHEMATICDIAGRAM(PART-16) NET/USB Section BAPRC-1670 (3/5) U0080(3/5) forDebugging BootOpt. NAND UART1 SPI0 +5.2V R3115orR3116 BOOT2 +5 2VHD BOOT7 +5.2VHD Q3101 BOOT1 R3111orR3112 BOOT5 TPD2E001DRLR BOOT0 R3109orR3110 BOOT6 IO2 5 BOOT3 R3100 BOOT2 ARM_SCLK,ARM_MINO,ARM_MONI R3107orR3108 BOOT7 Shield GND 4...
  • Page 39 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-13 PRC SECTION-4/5 ModelNo.TX-SR333/HT-RC630/HT-R393 SchematicDiagram(Part-17) HDMI Section U0080(4/5) BAPRC-1670(4/5) C8661 D8663 102K To DIR/DAC Section Part-15 RXF_2+ NC4 10 RXF_2- NC3 9 D2_Shield VN2 8 RXF_1+ NC2 7 NC1 6 RXF_1- D1_Shield D8664 RXF_0+ NC4 10 D0_Shield RXF_0- NC3 9 VN2 8...
  • Page 40 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-14 PRC SECTION-5/5 ModelNo.TX-SR333/HT-RC630/HT-R393 SCHEMATICDIAGRAM(PART-18) DSP/Memory Section BAPRC-1670(5/5) U0080(5/5) GND_ARM GNDDG +3.3VNET GNDDG PD [0-31] C3070 C3071 VDD_MPU3.3V EMA D[0-7] 226M 226M PA [0-12],PBA [0,1] MB_A[0-12] MB BA[0,1] Q3070 R3009 C3001 PA_12 MB_A12 FP6861C-B1AS5CTR 105K VOUT 1 PBA_0 MB_BA0 GND 2...
  • Page 41 TX-SR333/HT-RC630/HT-R393 TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAMS-15 RF SECTION Model No. TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAM (PART-19) Wi-Fi/Bluetooth Connector Section MODEL NO. TX-SR333/HT-RC630/HT-R393 SCHEMATIC DIAGRAM (PART-20) TUNER SECTION BARF-1567 U0090 P791A DF40HC-25-30DS-0.4V70 BARF-1450 -3A/-3B U0120 Wi-Fi/Bluetooth antenna BPF MODEL NO.TX-SR333/HT-RC630/HT-R393 VDDRF EXCEPT MDC/MDF/MMR VDD2 +3.3V USB data +/- line 90ohm 332K 0.1501 mm width...
  • Page 42 1/38 PAGE TX-SR333(B)MDC <Note> Parts marked by "NSP" are generally unavailable because <Notes> they are not in our Master Spare Parts List. (B) : Black color model <MDC> : 120V NOTE : THE COMPONENTS IDENTIFIED BY THE MARK Canadian/USA/(Mexico) model ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
  • Page 43 2/38 PAGE A207 KNOB (TONE)(B) 28326912 A209 KNOB (INP)B_535 28327172A A211 KNOB (SEL) 28326906B A213 KNOB (INP-L)B_535 28327174C A214 KNOB (INP-R)B_535 28327175C A215 FACET (KNOB)_535 28200076 A217 KNOB (STBY)(B) 28326904 A219 KNOB (CUR) 28326907B A221 KNOB (VOL)AS(B)_525 28327142 A401 COVER (B) (Bent) 28210089A A401...
  • Page 44 3/38 PAGE TX-SR333(B)MDC PACKING PROCEDURES PARTS LIST REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [PACKING] A601 (AS)309 29092570B A601A (L)309 { 1} 29092571B A601B (R)309 { 1} 29092572B A605 (650 x 600 x 0.515) 29100267 A606 TAPE (SEROHAN)NITTO NO.29...
  • Page 45 4/38 PAGE TX-SR333(B)MDC PC BOARD PARTS LIST U001 BAAF-1672-1A : NSP CIRCUIT NO.PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [SEMI CONDUCTOR] D4173 ZENER DIODE DZ2J068M0L 224760680R2 D4173 or ZENER DIODE UDZS6.8B ( 1) 224550680R2 D4174 ZENER DIODE DZ2J068M0L 224760680R2...
  • Page 46 5/38 PAGE Q4117 or TRANSISTOR RN1441 ( 1) 2215410R2 Q4130 HYBRID IC NJM4580M-D 22241448R2 Q4170 HYBRID IC 78M15HF(NJM78M15FA) 222780155JRC Q4170A HEAT SINK ME151025402170 27160692 Q4170B SCREW 3P+10FN(3BC) 82143010GR Q4171 HYBRID IC 79M15HF(NJM79M15FA) 222790155JRC Q4171A HEAT SINK ME151025402170 27160692 Q4171B SCREW 3P+10FN(3BC) 82143010GR Q4302...
  • Page 47 6/38 PAGE C4014 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4015 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4016 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4017 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4018 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4019 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 376332214T C4020...
  • Page 48 7/38 PAGE C6051 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 374721034T C6052 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 374721034T C6053 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 374721034T C6054 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 374721034T C6250 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 374724734T C6251...
  • Page 49 8/38 PAGE R4056 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 435032244R1 R4057 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 435032244R1 R4058 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 435032244R1 R4059 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 435032244R1 R4060 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 435032244R1 R4077 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 435032234R1 R4078...
  • Page 50 9/38 PAGE R4305 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 435031014R1 R4306 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 435032224R1 R4307 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 435032224R1 R4308 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 435032224R1 R4309 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 435032224R1 R4400 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 435031024R1 R4401...
  • Page 51 10/38 PAGE R6200 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R6201 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R6202 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R6203 CHIP TYPE CARBON RESISTOR RN72K1J-104FE 435031042R1 R6204 CHIP TYPE CARBON RESISTOR RN72K1J-104FE 435031042R1 R6210 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 435034724R1 R6211...
  • Page 52 11/38 PAGE P5508 TRM-423(SCREW) NEJITANSI ST3 25060495 P5509A TERMINAL NTM-1P232(M1700) 25060301 P6000B PLUG NPLG-9P0964 25056014 P6001B PLUG NPLG-9P0964 25056014 P6002B PLUG NPLG-9P0964 25056014 P6004B PLUG NPLG-9P0964 25056014 P6013B PLUG NPLG-9P0964 25056014 P603A WIRE HOL NSCT-9P900 25051113 P603Aor WIRE HOL CHD-2.5-9 ( 1) 25053543 P603B...
  • Page 53 12/38 PAGE Q5004 TRANSISTOR 2SC2713-BL 2213136R2 Q5010 TRANSISTOR 2SC2713-BL 2213136R2 Q5011 TRANSISTOR 2SC2713-BL 2213136R2 Q5012 TRANSISTOR 2SC2713-BL 2213136R2 Q5013 TRANSISTOR 2SC2713-BL 2213136R2 Q5014 TRANSISTOR 2SC2713-BL 2213136R2 Q5030 TRANSISTOR INA6006AP1-T111 2217980R2 Q5030 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2 Q5031 TRANSISTOR INA6006AP1-T111 2217980R2 Q5031 or TRANSISTOR...
  • Page 54 13/38 PAGE C5020 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 397581007AT C5021 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 397581007AT C5022 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 397581007AT C5023 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 397581007AT C5024 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 397581007AT C5040 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 397552217T C5041...
  • Page 55 14/38 PAGE R5041 CHIP TYPE CARBON RESISTOR RN72K1J-182JE 435031824R1 R5042 CHIP TYPE CARBON RESISTOR RN72K1J-182JE 435031824R1 R5043 CHIP TYPE CARBON RESISTOR RN72K1J-182JE 435031824R1 R5044 CHIP TYPE CARBON RESISTOR RN72K1J-182JE 435031824R1 R5050 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R5051 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R5052...
  • Page 56 15/38 PAGE R5193 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 415471004T R5194 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 415471004T R5200 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 415473334T R5201 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 415473334T R5202 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 415473334T R5203 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 415473334T R5204...
  • Page 57 16/38 PAGE [SEMI CONDUCTOR] D201 DIODE G10XB80-02-60A-T16 22380378F D201 or DIODE D5SBA60 ( 1) 22380070F D202 CHIP TYPE DIODE DA2J10100 223303R2 D202 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2 D203 CHIP TYPE DIODE DA2J10100 223303R2 D203 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2...
  • Page 58 17/38 PAGE Q7006 TRANSISTOR KTC3875-GR 2216175R2 Q7006 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2 Q7010 TRANSISTOR KTC3875-GR 2216175R2 Q7010 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2 Q7011 TRANSISTOR KRA107S 2216350R2 Q7011 or TRANSISTOR RN1407 ( 1) 2216260R2 Q7012 TRANSISTOR KRC107S 2216340R2 Q7012 or TRANSISTOR RN1407 ( 1)
  • Page 59 18/38 PAGE C2111 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 398580227T C2111 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T C2112 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 398580227T C2112 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T C2114 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K1 332101025R1 C2115...
  • Page 60 19/38 PAGE F201 FUSE T4A-SEUL-T250V 252392T R2001 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 435035634R1 R2002 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 435035634R1 R2007 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 435032224R1 R2008 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 435032224R1 R201 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 435031044R1 R202 CHIP TYPE CARBON RESISTOR...
  • Page 61 20/38 PAGE R7121 CHIP TYPE CARBON RESISTOR RN72K1J-271JE 435032714R1 R7122 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 435033314R1 R7123 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 435034714R1 R7124 CHIP TYPE CARBON RESISTOR RN72K1J-561JE 435035614R1 R7125 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 435038214R1 R7126 CHIP TYPE CARBON RESISTOR RN72K1J-122JE 435031224R1 R7127...
  • Page 62 21/38 PAGE P703Aor WIRE HOL CHD-1.5-3 ( 1) 25053535 P705 WIRE HARNESS ASSEMBLY NSAS-5P2112 2009991301UL P705A WIRE HOL NSCT-5P876 25051089 P705Aor WIRE HOL CHD-1.5-5 ( 1) 25053536 P705B PLUG NPLG-5P133 25055149 P7201 ST JACK MSJ-064-05A SR 25045783 P7202 TRM-423(SCREW) NEJITANSI ST3 25060495 P7301 PIN JACK...
  • Page 63 22/38 PAGE CIRCUIT NO.PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [SEMI CONDUCTOR] D110 CHIP TYPE DIODE DA2J10100 223303R2 D110 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2 D182 CHIP TYPE DIODE 1SR154-400 22380284R2 D602 CHIP TYPE DIODE DA2J10100 223303R2 D602 or CHIP TYPE DIODE 1SS352...
  • Page 64 23/38 PAGE Q3109 HYBRID IC S-13A1A12-U5T1U3 22242841R2 Q3121 HYBRID IC FP6861C-B1AS5CT 22242840R2 Q3205 HYBRID IC TC7SZU04FU 22242512R2TO Q501 TRANSISTOR KRA102S 2216220R2 Q501 or TRANSISTOR RN2402 ( 1) 2214530R2 Q660 HYBRID IC BU33TD3WG-TR 22242715R2 Q701 HYBRID IC MPD70F3477AGJA-GAE-G 222W0117R3 firmware Q702 HYBRID IC BU33TD3WG-TR 22242715R2...
  • Page 65 24/38 PAGE L153 CORE BLM15PX181SN1D 2350033R1 L3001 CORE BLM15PX121SN1D 2350034R1 L3002 CORE BLM15PX121SN1D 2350034R1 L3003 CORE BLM15PX121SN1D 2350034R1 L3004 CORE BLM15PX121SN1D 2350034R1 L3005 CORE BLM15PX121SN1D 2350034R1 L3007 CORE BLM15PX181SN1D 2350033R1 L3008 CORE BLM15PX181SN1D 2350033R1 L301 EMI SUPPRESSION FILTER BLM15BD601SN1D 2350037R1 L303 CHOKE COIL LBC2518T4R7M...
  • Page 66 25/38 PAGE C1203 CHIP TYPE CERAMIC CAPACITOR CK725B1A-225K1 332132255R1 C1204 CHIP TYPE CERAMIC CAPACITOR CK725B1A-225K1 332132255R1 C1205 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 332121045R1 C1206 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 332121045R1 C1207 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 332121045R1 C1208 CHIP TYPE CERAMIC CAPACITOR CK725B1H-222K1 332102225R1 C1209...
  • Page 67 26/38 PAGE C305 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3051 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C3052 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C3053 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C3054 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C3056 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C306...
  • Page 68 27/38 PAGE C3166 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C317 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3170 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C3171 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C318 CHIP ELECT C CEWX16V-100M 398141017R2 C319 CHIP ELECT C CEWX16V-47M 398144707R2 C320...
  • Page 69 28/38 PAGE C8303 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C8304 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C8305 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C8306 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C8307 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C8308 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C8309...
  • Page 70 29/38 PAGE C8393 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C8651 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C8652 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C8661 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C8662 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C8902 CHIP TYPE CERAMIC CAPACITOR CK725B1E-106K 332221065R2 C8928...
  • Page 71 30/38 PAGE R1301 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R1302 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R1303 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R1304 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R1305 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R1306 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R1307...
  • Page 72 31/38 PAGE R3048 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R3049 CHIP TYPE CARBON RESISTOR RN72K1J-560JE 435035604R1 R3050 CHIP TYPE CARBON RESISTOR RN72K1J-560JE 435035604R1 R3051 CHIP TYPE CARBON RESISTOR RN72K1J-560JE 435035604R1 R3054 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 435031034R1 R3056 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 435034724R1 R3060...
  • Page 73 32/38 PAGE R321 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 435033314R1 R3212 CHIP TYPE CARBON RESISTOR RN72K1J-220JE 435032204R1 R3215 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R3218 CHIP TYPE CARBON RESISTOR RN72K1J-220JE 435032204R1 R3219 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 435032214R1 R322 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 435033314R1 R3221...
  • Page 74 33/38 PAGE R526 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 435031024R1 R530 CHIP TYPE CARBON RESISTOR RN72K1J-470JE 435034704R1 R531 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 435031044R1 R532 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 435034724R1 R533 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 435034724R1 R534 CHIP RESISTOR NETWORK YCN104-103-JK 43464C10304R1 R534 or...
  • Page 75 34/38 PAGE R647 CHIP RESISTOR NETWORK YCN104-221-JK 43464C22104R1 R647 or CHIP RESISTOR NETWORK RM7LJ221X04 ( 1) 43484722104R2 R651 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 435031034R1 R652 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 435031024R1 R653 CHIP TYPE CARBON RESISTOR RN72K1J-105JE 435031054R1 R655 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 435032234R1 R656...
  • Page 76 35/38 PAGE R8303 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R8304 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 435034724R1 R8305 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R8306 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R8307 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 435034724R1 R8308 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 435035624R1 R8309...
  • Page 77 36/38 PAGE R8654 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 435034734R1 R8655 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R8663 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 435034734R1 R8664 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 435034734R1 R8665 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R8933 CHIP TYPE CARBON RESISTOR RN72K1J-563FE 435035632R1 R8934...
  • Page 78 37/38 PAGE U009 BARF-1567-3A : NSP CIRCUIT NO.PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [SEMI CONDUCTOR] Q792 HYBRID IC S-13A1A33-U5T1U3 22242844R2 [CAPACITOR] C790 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 332071065R2 C794 CHIP TYPE CERAMIC CAPACITOR CK725B1H-103K0 332031035R1 C795 CHIP TYPE CERAMIC CAPACITOR CK725B1H-103K0 332031035R1 C796...
  • Page 79 38/38 PAGE CHIP TYPE CARBON RESISTOR RN72K1J-101JE 435031014R1 [SW TRM] TERMINAL NTM-1PDSC437 25060515 P101A SOCKET NSCT-7P2100 25052203 TERMINAL NTM-2PDML439 25060517...

This manual is also suitable for:

Tx-sr333(s)
