USER GUIDE TB-9020
733 Dual Remote Splitter Kit for 724 Workstation Monitor
Instructions
Contents:
1 - SCS
733
Remote Input Jack with cable
1 - Plastic Hole Plug-Black
2 - Screw, Round Head
2 - Cable Clip
To connect a second remote input jack to a SCS
1. Mount the remote input jack using the two round head screws, at the desired locations within the length of the
cable.
2. Ensure the cable is connected to the 733 Remote Input Jack.
3. Route the cable to the 724 Monitor and secure with cable clips.
4. Plug the other end of the cable into the socket identified 733 at the rear of the monitor.
5. Fully insert the plastic hole plug into the #2 of the existing remote input jack. Note: This action disables this
connection, preventing simultaneous usage of the #2 input.
For additional information and a diagram showing how to create two separate workstations refer to the instruction
manual for the 724 Monitor.
Limited Warranty, Warranty Exclusions, Limit of Liability and RMA Request Instructions
See the SCS Warranty -
http://staticcontrol.descoindustries.com/warranty.aspx
Made in China.
TB-9020 Page 1 of 1
June 2015
SCS - 926 JR Industrial Drive, Sanford, NC 27332 • (919) 718-0000 • Website:
724
Workstation Monitor perform the following steps:
StaticControl.com
© 2015 DESCO INDUSTRIES, INC.
Employee Owned
