Summary of Contents for Kohler K-13925-CP
- Page 1 Installation Guide Bedpan Washer K-13925 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página“Español-1” 1034408-2-A...
-
Page 2: Tools And Materials
Thank You For Choosing Kohler Company We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems please don’t hesitate to contact us. Our phone numbers and web site are listed on the back cover. -
Page 3: Before You Begin
Provide screw holes, bracket, or other features as required for supporting the flange onto the finished wall. Kohler Co. reserves the right to make revisions in the design of bedpan washers without notice, as specified in the Price Book. Kohler Co. - Page 4 Thread the valve body assembly onto the supply nipple. Ensure that the valve body assembly is vertically aligned. Slide the bell shaped flange down the holder until it is snug against the finished wall. Secure with one flange setscrew and two wall screws. 1034408-2-A Kohler Co.
- Page 5 Thread one end of the flexible hose into the body assembly outlet. Securely tighten. Thread the other end of the flexible hose into the sprayer outlet. Securely tighten. Hang the spray nozzle from the rotated valve assembly clamp. Kohler Co. 1034408-2-A...
-
Page 6: Installation Checkout
Two Handle Bedpan Washer For a two handle bedpan washer, repeat with the other check valve and supply valve. Turn the water off. Remove any debris from the sprayer and reinstall. Test and verify that the sprayer operates normally. 1034408-2-A Kohler Co.
