- Page 1 GigA Pro Body Set Wireless System...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 06.03.2024, ID: 313903 (V6)
-
Page 3: Table Of Contents
5.1 Receiver............................... 16 5.2 Bodypack transmitter........................21 5.3 Battery charging station........................ 22 Operating..............................24 6.1 Receiver............................... 24 6.2 Bodypack transmitter........................31 Technical specifications........................33 7.1 Receiver............................... 33 7.2 Bodypack transmitter........................34 7.3 Battery charging station........................ 35 GigA Pro Body Set Wireless System... - Page 4 Table of contents Plug and connection assignment....................37 Troubleshooting............................39 Protecting the environment....................... 41 GigA Pro Body Set Wireless System...
- Page 5 GigA Pro Body Set Wireless System...
-
Page 6: General Information
Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. GigA Pro Body Set Wireless System... - Page 7 This combination of symbol and signal word indicates a possible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – dangers due to batteries. Warning – danger zone. GigA Pro Body Set Wireless System...
-
Page 8: Safety Instructions
Always dispose of packaging material properly when it is not in use. Never allow children to use the device without supervision. Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that children could play with. GigA Pro Body Set Wireless System... - Page 9 Possible damage due to leaking batteries! Batteries can leak and cause permanent damage to the device. Take the batteries out of the device if it is not going to be used for an extended period of time. GigA Pro Body Set Wireless System...
- Page 10 The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. GigA Pro Body Set Wireless System...
-
Page 11: Features
Features 3 Features The Wireless System GigA Pro Body Set consists of the following components: 9.5-inch Diversity receiver: – Two antennas for optimum reception quality – Automatic frequency scan, four to six frequencies in parallel – Infrared interface for sending the frequency selection from the receiver to the trans‐... - Page 12 Features The system operates at 2.400 GHz … 2.4835 GHz worldwide at no charge and without registra‐ tion. GigA Pro Body Set Wireless System...
-
Page 13: Installation And Starting Up
Make sure that transmitter and receiver are both tuned to the same channel. Never set multiple transmitters to the same channel. Make sure that there are no metal objects between the transmitter and receiver. Avoid interference from other radio or in-ear systems. GigA Pro Body Set Wireless System... -
Page 14: Receiver
As a precaution, disconnect the power supply from the power grid when storms are approaching or it the device will not be used for a longer period. First, connect the power supply to the receiver and then plug the power supply into the power outlet. GigA Pro Body Set Wireless System... - Page 15 Connect one of the audio outputs of the receiver to your mixer or your amplifier. Ensure that only one of the two outputs is ever used at a time, because faults might occur otherwise. GigA Pro Body Set Wireless System...
-
Page 16: Connections And Controls
Connections and controls 5 Connections and controls 5.1 Receiver Front ö ö & GigA Pro Body Set Wireless System... - Page 17 3 [CONTROL] | Press the jog wheel to open the menu and rotate it to select a menu item. Press the jog wheel again to call up the menu item. 4 Display 5 [ACT] | Starts the synchronisation of the settings with the transmitter. GigA Pro Body Set Wireless System...
- Page 18 4 [DC IN] | Socket for connecting the supplied power adapter. If you are using a different power supply, observe the correct voltage, the polarity of the plug and the power consumption. GigA Pro Body Set Wireless System...
- Page 19 6 [ID] | Displays the set ID 7 Displays the battery status of the transmitter from which the device just received a signal. ‘10%’ : Battery change required ‘T×OFF’ : The transmitter is turned off. GigA Pro Body Set Wireless System...
- Page 20 The ‘T!’ symbol is displayed for channels that are occupied by other devices. The symbols flash for the channel currently being tested. 2 ‘CH’ | Available channel numbers. The channel currently selected with the jog wheel is highlighted. 3 ‘Scan’ | Scanned channels GigA Pro Body Set Wireless System...
-
Page 21: Bodypack Transmitter
8 [ACT] | Infrared sensor 9 [ON] | Main switch. Press the switch for several seconds to switch the device on or off. Under the battery compartment cover is the button for resetting the battery monitor. GigA Pro Body Set Wireless System... -
Page 22: Battery Charging Station
Connections and controls 5.3 Battery charging station ö & GigA Pro Body Set Wireless System... - Page 23 3 Charging indicator for both charging bays. The red LED lights during charging, while the green LED lights up when the device is charged. 4 Storage options for IMR-18500 type lithium-ion batteries. 5 Connector for the supplied power supply. GigA Pro Body Set Wireless System...
-
Page 24: Operating
Press the jog wheel to confirm the selected parameter or value. Turn the jog wheel left or right to select the menu item ‘Exit&Save’ . Press the jog wheel to to save the settings and return to the home screen. GigA Pro Body Set Wireless System... - Page 25 Press the jog wheel to confirm the selection. Turn the jog wheel left or right to select the menu item ‘Exit&Save’ . Press the jog wheel to to save the settings and return to the home screen. GigA Pro Body Set Wireless System...
- Page 26 Enabling / disabling the bass filter Press the jog wheel to open the main menu. Turn the jog wheel until the menu item ‘LowCut’ appears. Press the jog wheel to call up the menu item. GigA Pro Body Set Wireless System...
- Page 27 Press the jog wheel to confirm the selection. Turn the jog wheel left or right to select the menu item ‘Exit&Save’ . Press the jog wheel to to save the settings and return to the home screen. GigA Pro Body Set Wireless System...
- Page 28 The settings of the device can be protected against unintentional changes by a write protec‐ tion. Press the jog wheel to open the main menu. Turn the jog wheel until the menu item ‘SetLock’ appears. Press the jog wheel to call up the menu item. GigA Pro Body Set Wireless System...
- Page 29 ð The current firmware version of the device is displayed. Press the jog wheel to close the display. Turn the jog wheel left or right to select the menu item ‘Exit&Save’ . Press the jog wheel to return to the home screen. GigA Pro Body Set Wireless System...
- Page 30 If the synchronization has failed, the message ‘FAIL’ appears. In this case, hold the transmitter closer to the receiver and restart the synchronization. GigA Pro Body Set Wireless System...
-
Page 31: Bodypack Transmitter
Press [ON] for several seconds until the battery level indicator goes out. Mute Press [AF] to mute or unmute the transmitter. When the button lights up, the transmitter is active. You can also use an optionally available external mute switch instead of the button. GigA Pro Body Set Wireless System... - Page 32 Should the transmitter also fail to work with a freshly charged battery, turn the trans‐ mitter off. Press the button to reset the battery monitor to ‘wake up’ the battery. Close the battery compartment and turn the transmitter back on. GigA Pro Body Set Wireless System...
-
Page 33: Technical Specifications
> 115 dB (A) Audio sampling rate 24 bit / 44.1 kHz NF frequency response 20 Hz … 20 kHz (–2 dB) Power consumption 1.6 W Power supply External power adapter, 100 - 240 V 50/60 Hz GigA Pro Body Set Wireless System... -
Page 34: Bodypack Transmitter
2.400 GHz … 2.4835 GHz Max. transmission power 10 mW Maximum input level 6.5 dBV Input impedance 1.0 MΩ Range in clear field of vision up to 100 m Battery Battery type 1 × Lithium-ion rechargeable battery ICR-18500 GigA Pro Body Set Wireless System... -
Page 35: Battery Charging Station
20%…80% (non-condensing) 7.3 Battery charging station Battery Battery type Lithium-ion rechargeable battery ICR-18500 Voltage 3.7 V Capacity 1,400 mAh Charging current approx. 500 mA Power supply External power adapter, 100 - 240 V 50/60 Hz GigA Pro Body Set Wireless System... - Page 36 313 g Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Further information Diversity Switchable frequencies Detachable antennas Pilot tone Max. number of radio links Power supply of the transmitter 1× Lithium-ion rechargeable battery ICR-18500 GigA Pro Body Set Wireless System...
-
Page 37: Plug And Connection Assignment
180°. Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise interference. GigA Pro Body Set Wireless System... - Page 38 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) Mini XLR Ground Positive signal (+) Negative signal (–) GigA Pro Body Set Wireless System...
-
Page 39: Troubleshooting
5. See if the audio transmission works when you move the transmitter closer to the receiver. 6. Make sure that no metal objects near the transmitter or receiver are obstructing the transmission. Transmission is interrupted 1. Modify the orientation of the antennas. GigA Pro Body Set Wireless System... - Page 40 3. Interference can also be caused by other radio or in-ear systems. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. GigA Pro Body Set Wireless System...
-
Page 41: Protecting The Environment
Dispose the built-in lithium batteries together with the device. Check for an appropriate collection facility. Dispose of the batteries and rechargeable batteries at relevant collection points or through your local waste facility. GigA Pro Body Set Wireless System... - Page 42 You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it. GigA Pro Body Set Wireless System...
- Page 44 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
