  • Page 1 TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 22.04.2024, ID: 312567, 312570, 312569, 312558, ... (V2)

  • Page 3: Table Of Contents

    5.2 Bodypack transmitter........................24 5.3 Handheld transmitter........................26 Technical specifications........................27 6.1 Receiver............................... 27 6.2 Bodypack transmitter........................28 6.3 Handheld transmitter........................29 Plug and connection assignment....................31 TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 4 Table of contents Troubleshooting............................33 Protecting the environment......................35 TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 5 TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 6: General Information

    This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 7 General information Warning signs Type of danger Warning – danger zone. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 8: Safety Instructions

    Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that children could play with. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 9 Batteries can leak and cause permanent damage to the device. Take the batteries out of the device if it is not going to be used for an extended period of time. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 10 The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 11: Features And Scope Of Delivery

    The transmission range of the system under normal conditions is approximately 50 metres. The system operates at a fixed frequency of 863,100 MHz. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 12 The transmission range of the system under normal conditions is approximately 50 metres. The system operates at a fixed frequency according to the following table: TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 13 The UHF wireless system TWS One Headset is particularly suitable for professional audio trans‐ (item no. 312567, 312569, mission, for example, at events, on rock stages and in concert halls, theatres, musicals or disco‐ 312570) theques. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 14 The transmission range of the system under normal conditions is approximately 50 metres. The system operates at a fixed frequency according to the following table: TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 15 TWS One A Headset (item no. 312567) 863.100 MHz TWS One C Headset (item no. 312569) 864.500 MHz TWS One D Headset (item no. 312570) 864.900 MHz TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 16: Installation And Starting Up

    For more information, please visit: http://www.thomann.de. Make sure that no metal objects are located between transmitter and receiver. Avoid interference by other radio and in-ear systems. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 17: Receiver

    If you are using a line input of your mixer, turn the knob clockwise all the way to the stop. To get the best sound quality, a fine adjustment of the controller may be required. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 18: Bodypack Transmitter

    Insert the batteries. Pay attention to the correct location of the poles. Close the battery compartment and turn on the transmitter. Slide the power switch to the 'ON' position. The LED lights up briefly. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 19 Turn on the transmitter and check the transmission by speaking of singing. If necessary, toggle the sensitivity switch on the transmitter or adjust the level on the receiver, your mixer or your amplifier. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 20: Handheld Transmitter

    Turn on the transmitter and check the transmission by speaking or singing. If necessary, adjust the level on the receiver, on your mixing console or your amplifier. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 21: Connections And Controls

    Connections and controls Connections and controls 5.1 Receiver Front panel ö & TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 22 3 [RF] | The LED lights up orange when there is a radio connection to the transmitter. 4 [AUDIO] | The indicator lights green when an audio signal is received. 5 [VOLUME] | Rotary control for adjusting the output level TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 23 3 [DC IN] | Socket for connecting the supplied power adapter. If you are using a different power supply, observe the correct voltage, the polarity of the plug and the power consumption. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 24: Bodypack Transmitter

    Connections and controls 5.2 Bodypack transmitter & & ö STANDBY TWS ONE PT UHF Bodypack Transmitter TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 25 7 Retaining clamp 8 Indication of the frequency range in which the device operates. The indication here must match the information on the bottom of the receiver. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 26: Handheld Transmitter

    Inside the battery compartment is a sticker with the indica‐ tion of the frequency range in which the device operates. The indication here must match the information on the bottom of the receiver. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 27: Technical Specifications

    60 Hz…16 kHz (±3 dB) Total harmonic distortion (THD) < 1% Signal-to-noise ratio > 92 dB (A) Power supply External power adapter, 100 - 240 V 50/60 Hz TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 28: Bodypack Transmitter

    Maximum input level > 1,200 mV Bandwidth 200 kHz Modulation type Frequency modulation (FM) Input impedance 470 KΩ Range in clear field of vision 40 m TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 29: Handheld Transmitter

    Frequency range UHF band (863 MHz…865 MHz) Max. transmission power 10 dBm Maximum input level +0 dBV Bandwidth 200 kHz Modulation type Frequency modulation (FM) TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 30 > 8 h Dimensions (L × Ø) 245 mm × 53 mm Weight 200 g Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...

  • Page 31: Plug And Connection Assignment

    Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 32 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 33 1. Modify the orientation of the antenna. 2. If you are using more than one wireless system at the same time, check the used frequencies and channels. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 34 [VOLUME] control settings on the receiver. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 35 Before disposing of your old device, remove the batteries if this is possible without destroying Dispose of the batteries or rechargeable batteries at suitable collection points or through your local waste facility. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 36 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. If your old device contains personal data, delete those data before disposing of it. TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 37 Notes TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 38 Notes TWS One A Lapel, TWS One A/B/C/D Vocal, TWS One A/C/D Headset UHF Wireless System...
  • Page 40 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
