- Page 1 IS-IR-WIFI-1 User Manual Issue date: 03/2016 r1.4...
- Page 2 ® IntesisHome IS-IR-WIFI-1 User Manual r1.4 eng Intesis Software S.L. © 2016 Intesis Software S.L. All rights reserved. This document has been carefully written by Intesis Software SL. and a lot of effort has been made to ensure no errors or mistakes are present in the document. Intesis Software S.L. is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
® IntesisHome IS-IR-WIFI-1 User Manual r1.4 eng Table of contents Welcome ..................................3 About this document ..............................3 1 Description ................................4 2 Before starting ................................. 5 3 Quick Start ................................6 4 Device installation ..............................7 Wall mounted position ........................... 7 Desktop position ............................ -
Page 4: Welcome
(www.intesishome.com) or the manufacturers’ website. Depending on the IntesisHome device installation, you can receive the feedback offered by the IR wireless remote controller from the AC unit. This will help you in knowing the last status sent by the remote controller to the AC unit. -
Page 5: Description
User Manual r1.4 eng 1 Description The IntesisHome Universal device is an external module capable of connecting your Air Conditioning units into your Wi-Fi network in order to provide global connectivity and remote control applications through a friendly user interface. -
Page 6: Before Starting
IntesisHome devices can be purchased in your usual air conditioner or heat pump reseller center. Costs related with Internet access are not included in the IntesisHome price. Ask your Internet Service Provider about the associated costs of your Internet connection. -
Page 7: Quick Start
Next, there is a step by step guide to help you going through all this process. 1. Device installation Place the IntesisHome Universal device in the final location and connect the power supply to the device. More information about the installation process can be found in section 4. -
Page 8: Device Installation
IntesisHome device to the AC unit tacking advantage of the rebounds on the floor or other furniture present in the room. Case B: Installed in front of the AC unit. In that case, the signal will travel from the IntesisHome device directly to the AC unit. -
Page 9: Desktop Position
User Manual r1.4 eng Case C: Installed below the AC unit. In that case, the signal will travel from the IntesisHome device to the AC unit tacking advantage of the rebounds on the wall in front of it or other furniture present in the room. -
Page 10: Power Connection
User Manual r1.4 eng 4.3 Power connection The IntesisHome device comes with a 5V DC 0,2 A power supply to be connected to the device. We do also provide 4 different types of plugs to match your current location needs: European Union (EU), United Kingdom (UK), United States (US) and Australia (AU). - Page 11 ® IntesisHome IS-IR-WIFI-1 User Manual r1.4 eng 230 VAC Figure 4-7 Additional cable connection Along with the device, there is also an additional cable. One end may be connected to the power supply. First, remove the plug adaptor, you’ll see that the power supply includes an IEC-60320 C8 standard connector and the cable uses an IEC-60320 C7 connector.
-
Page 12: Location Selection
Determining that the IntesisHome device will be working as expected in the installation location is an important stage. In order to determine the best location for your IntesisHome device, we offer you two possible options: use your Wireless Controller (the one of your AC unit) or use the special Parrot Mode. -
Page 13: Using Your Wireless Controller
3. Press the On/Off button of the Wireless Controller. 4. Check if you can control turn your AC unit On/Off from that position. a. If yes, mostly you will be able to control your AC unit with the IntesisHome device from that position. -
Page 14: Using Parrot Mode
4. Pick up the IR wireless controller of the AC system and press any function (On/Off preferably) pointing to the IntesisHome device. 5. Locate the IntesisHome device in the desired location and verify that the AC unit is receiving the command. -
Page 15: Ir Wireless Remote Controller Feedback
IR wireless remote controller to the AC unit. This feature is enabled by default and you only need to consider where you place the IntesisHome device. In order to enjoy this feature, the IntesisHome device needs to receive the same IR signal the AC unit receives from the IR wireless remote controller. -
Page 16: Wi-Fi Configuration
Advanced (for static IP configuration) WPS In order to connect the IntesisHome device to your Access Point or Router, please proceed with the Wi-Fi configuration as follows: 1. Use a Wi-Fi device (smartphone, tablet, laptop or PC) to connect to our device. -
Page 17: Ir Configuration
Please, check that the LED device is Off and the IntesisHome device powered before starting this process. In order to configure the IntesisHome device to start working with your AC unit using the IR, please do as follows: 1. Push the IH button for 4 seconds. The LED will turn into white steady. -
Page 18: Manual Mode
1. Make sure that you have your IntesisHome device Wi-Fi configured. 2. Make sure that you have your IntesisHome device registered (see section 7). 3. Go to the settings/device section. 4. Press “manual mode” (Check Figure 6-1). -
Page 19: Device Registration
After configuring the Wi-Fi connection and the IR communication, there is only one last step to be done: register your device. Please, follow bellow instructions to register your device: 1. Visit user.intesishome.com. 2. Create an account (in case you don’t have it yet). 3. Visit the settings/device/ section and click on add device. -
Page 20: Operation Modes
User Manual r1.4 eng 8 Operation modes The IntesisHome device can be operated in two different ways: standard operation (from the App or Web Interface) or back up operation (using the IH button). 8.1 Standard operation: App and web control of the AC unit. -
Page 21: Back Up Operation: Control Of The Ac Unit From The Ih Button
If you click once or twice on the IH button, the AC unit will turn Off. 9 Control configuration At the settings / device section in the web interface (user.intesishome.com), users have the chance to select which widgets (icons) will be shown and in consequence which functions we want to control from the App (iOS and Android) or from the web (control section). -
Page 22: Advanced Configuration
11 Calendar, Timers and Scenes The IntesisHome application offers you the opportunity to schedule some actions to be applied to the AC unit. This can be done basically using 3 different features of the IntesisHome application: Calendar, Timers and Scenes. -
Page 23: Anti-Frost Function
User Manual r1.4 eng 12 Anti-frost function In order to prevent the indoor temperature reach freezing points, IntesisHome offers the possibility to set the set point temperature on a special set point. It can be enabled/disabled both: from the App (iOS and Android) and from the web interface. - Page 24 IMPORTANT: Before changing the protection temperature below 16ºC, please check if your indoor unit could work at indoor temperatures below 16º or check with the technical department of the AC manufacturer. IntesisHome will be not responsible of any damage in the AC unit. © Intesis Software S.L. - All rights reserved...
-
Page 25: Led Status Summary
Waiting customer pressing the On/Off button of the IR remote controller (up White Steady to 20 seconds) The IR remote controller has been linked as expected with the IntesisHome Green Blinking device The IR remote controller has NOT been linked as expected with the... - Page 26 Command received or sent during Auto mode Cyan Command sent during anti-frost mode Blinking IntesisHome device trying to connect to the Internet © Intesis Software S.L. - All rights reserved 25 / 26 This information is subject to change without notice http://www.intesishome.com...
-
Page 27: Troubleshooting
2. Learning mode is not working (LED is blinking red after several attempts) If the IntesisHome device blinks in red after pressing the On/Off button of your AC unit during the learning mode, please check our compatibility list at www.intesishome.com/downloads/universal...
