  • Page 2: Table Of Contents

    MF100 Series Medium-frequency Power Supply Contents Contents Contents ............................i Chapter 1 Safety precautions ......................1 1.1 What this chapter contains ....................1 1.2 Safety definition ........................ 1 1.3 Warning signs ........................1 1.4 Safety guide ........................1 1.5 Scrap disposition ......................2 Chapter 2 Product overview ......................
  • Page 3 MF100 Series Medium-frequency Power Supply Contents P10 group Multi-step speed control................38 P11 group Protective parameters ................40 P14 group Serial communication ................43 P17 group State viewing functions ................45 P18 group Special state viewing functions ..............46 P24 group Function group 1 special for the medium-frequency power supply....46 P25 group Function group 2 special for the medium-frequency power supply....
  • Page 4 MF100 Series Medium-frequency Power Supply Contents 8.6.2 Write command 06H examples ................82 8.6.3 Continuously write command 10H examples ............84 8.6.4 Modbus communication commissioning example ..........86 8.7 Common communication faults ..................87 Appendix A Dimension drawings ....................88 A.1 What this chapter contains .....................

  • Page 5: Chapter 1 Safety Precautions

    MF100 Series Medium-frequency Power Supply Safety precautions Chapter 1 Safety precautions 1.1 What this chapter contains Read this manual carefully and follow all safety precautions before moving, installing, operating, and servicing the product. Otherwise, physical injury or death or damage to the devices may be caused.

  • Page 6: Scrap Disposition

    MF100 Series Medium-frequency Power Supply Safety precautions  Do not refit the medium-frequency power supply unauthorizedly; otherwise fire, electric shocks or other injury may occur.  The base may become hot when the machine is running. Do not touch them.

  • Page 7: Chapter 2 Product Overview

    Chapter 2 Product overview 2.1 Basic principle MF100 series medium-frequency power supply is a kind of device which converts 1PH or 3PH fundamental frequency power supply into 1PH medium-frequency power supply. The main circuit diagram is shown as below. The rectifier circuit converts AC voltage into DC voltage, with the capacitor bank in the middle serving for energy storage and filtering, and then converts DC voltage into AC square-wave voltage through the inverter circuit.

  • Page 8: Product Specification

    MF100 Series Medium-frequency Power Supply Product overview 2.2 Product specification Function description Specification Input voltage AC 1PH 220 V(-15%)–240 V(+10%) (220 V by default) AC 3PH 380 V(-15%)–440 V(+10%) (380 V by default) Power input Input 50 Hz or 60 Hz, allowable range: 47–63 Hz...

  • Page 9: Product Nameplate

    MF100 Series Medium-frequency Power Supply Product overview Function description Specification Temperature of the -10–50℃, derate above 40℃. running environment Protective IP20 degree Pollution Level 2 degree Cooling mode Forced air-cooling Selectable C3 filters: meet the degree requirement of IEC61800-3 C3...

  • Page 10: Rated Product Specifications

    6000 MF100-038A-4 MF100-045A-4 18.5 MF100-060A-4 MF100-075A-4 MF100-092A-4 MF100-115A-4 MF100-150A-4 3PH AC380 1PH AC540 MF100-180A-4 MF100-215A-4 MF100-260A-4 MF100-305A-4 MF100-340A-4 4000 MF100-380A-4 MF100-425A-4 MF100-480A-4 MF100-530A-4 3000 MF100-600A-4 MF100-650A-4 Note: If you need products of 350 kW or above, please contact INVT manufacturer.

  • Page 11: Chapter 3 Installation Guide

     Installation must be designed and done according to applicable local laws and regulations. INVT does not assume any liability whatsoever for any installation which breaches local laws and regulations. If recommendations given by INVT are not followed, the medium-frequency power supply may experience problems that the warranty does not cover.
  • Page 12 MF100 Series Medium-frequency Power Supply Installation guide Note:  The fuse, input reactor, and input filter are optional parts. For details, please consult the manufacturer.  P1 and (+) have been short connected by default. If users need to connect to external DC reactor, take off the short-contact tag of P1 and (+).

  • Page 13: Wiring Of Control Terminals

    MF100 Series Medium-frequency Power Supply Installation guide 3.2.2 Wiring of control terminals Figure 3-2 Control terminals wiring of 1PH Analog output 0–10 V/0–20 mA Analog output 0–10 V/0–20 mA +24V Terminal resistor 485+ 0-10 V/0-20 mA 485- input 0-10 V/0-20 mA...

  • Page 14: Diagram Of Control Terminals

    MF100 Series Medium-frequency Power Supply Installation guide Figure 3-4 Control terminals wiring of 3PH 18.5 kW and above Analog output 0–10 V/0–20 mA Analog output 0–10 V/0–20 mA Terminal resistor 485+ 485- +24V +10V 0-10 V/0-20 mA input RO1A 0-10 V/0-20 mA...
  • Page 15 MF100 Series Medium-frequency Power Supply Installation guide Figure 3-7 Control terminals of 18.5 kW and above +10V RO1A RO1B RO1C COM PTA GND AO1 AO2 RO1A RO1B RO1C +24V PW COM COM CME GND 485+ 485- Note: The idle terminals on the control terminals are reserved and cannot be used.
  • Page 16 MF100 Series Medium-frequency Power Supply Installation guide Terminal Instruction name 1. Internal impedance: 3.3 kΩ Digital input 1 2. Accept 12–30 V voltage input Digital input 2 3. This terminal is bi-directional input terminal and supports Digital input 3 NPN/PNP connection modes Digital input 4 4.

  • Page 17: Chapter 4 Keypad Operation Instruction

    MF100 Series Medium-frequency Power Supply Keypad operation instruction Chapter 4 Keypad operation instruction 4.1 What this chapter contains This chapter contains the following operation: Buttons, indicators and the screen as well as the methods to inspect, modify and set function codes by keypad.
  • Page 18 MF100 Series Medium-frequency Power Supply Keypad operation instruction Name Instruction power supply is in the forward rotation state; LED on means the medium-frequency power supply is in the reverse rotation state. keypad operation, terminals operation remote communication control LED off means that the medium-frequency...

  • Page 19: Keypad Display

    15 kW and below 4.3 Keypad display The display state of MF100 series keypad is divided into stop state parameter display, running state parameter display, function code parameter editing state display, and fault alarm display state.

  • Page 20: Keypad Operation

    4.4.2 How to set the password of the medium-frequency power supply MF100 series medium-frequency power supplies provide password protection function to users. Set P07.00 a non-zero value (user password), quit from the function code editing state, and the password protection is changed from valid instantly to valid after one minute.

  • Page 21: How To Watch The State Of The Medium-Frequency Power Supply Through Function Codes

    4.4.3 How to watch the state of the medium-frequency power supply through function codes MF100 series provide group P17 as the state inspection group. Users can enter into P17 group directly to watch the state. Figure 4-5 Sketch map of state watching...

  • Page 22: Chapter 5 Function Parameters

    MF100 Series Medium-frequency Power Supply Function parameters Chapter 5 Function parameters 5.1 What this chapter contains This chapter lists all the function codes and corresponding description of each function code. 5.2 Function parameter list For the convenience of function codes setting, the function group number corresponds to the first-level menu, the function code number corresponds to the second-level menu, and the function code parameter corresponds to the third-level menu.

  • Page 23: P00 Group Basic Functions

    MF100 Series Medium-frequency Power Supply Function parameters value, the parameter will be protected by password. When modifying function parameters through serial communication, the function of user password also follows above rules. P00 group Basic functions Function Name Description Setting range...

  • Page 24: P01 Group Start And Stop Control

    MF100 Series Medium-frequency Power Supply Function parameters P01 group Start and stop control Function Name Description Setting range Default Modify code 0: Ramp stop ○ P01.08 Stop mode 0–1 1: Coast to stop 0: Terminal running command is invalid at power...

  • Page 25: P05 Group Input Terminals

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Voltage increase ○ P04.29 0.0–3600.0 s 0.0–3600.0 5.0 s time Voltage decrease ○ P04.30 0.0–3600.0 s 0.0–3600.0 5.0 s time Max. output P04.32–100.0% (rated ◎...
  • Page 26 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code 17: Multi-step speed terminal 18: Multi-step speed terminal 19: Multi-step speed terminal 20: Multi-step speed pause 21–32: Reserved 33: Clear frequency increase/decrease setting temporarily 34–35: Reserved...
  • Page 27 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code S1 terminal ○ P05.14 0.00–600.00 s 0.00–600.00 s 0.00 s switch-on delay S1 terminal ○ P05.15 0.00–600.00 s 0.00–600.00 s 0.00 s switch-off delay S2 terminal ○...
  • Page 28 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Corresponding ○ P05.33 setting of lower -100.0%–100.0% -100.0–100.0 0.0% limit of AI1 Upper limit value ○ P05.34 P05.32–10.00 V P05.32–10.00 10.00 V of AI1 Corresponding ○...

  • Page 29: P06 Group Output Terminals

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Lower limit 0.000 0.000 ○ P05.50 0.000 kHz–P05.52 frequency of HDI kHz–P05.52 Corresponding setting of lower ○ P05.51 -100.0%–100.0% -100.0–100.0 0.0% limit frequency of Upper limit P05.50–50.000...
  • Page 30 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Relay RO1 ○ P06.10 0.00–600.00 s 0.00–600.00 s 0.00 s switch-on delay Relay RO1 ○ P06.11 0.00–600.00 s 0.00–600.00 s 0.00 s switch-off delay Relay RO2 ○...

  • Page 31: P07 Group Hmi

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Upper limit of AO1 ○ P06.19 P06.17–100.0% P06.17–100.0 100.0% output Corresponding ○ P06.20 AO1 output of 0.00 V–10.00 V 0.00–10.00 10.00 V upper limit AO1 output filter ○...
  • Page 32 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code 2: Display state of shift key switch-over 3: Reserved 4: Clear UP/DOWN setting 5: Coast to stop 6: Switch over the running command reference mode in...
  • Page 33 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Bit 7: Temperature of the medium-frequency power supply (PT100) Bit 8: PID reference (PT100) Bit 9: PID feedback (% on) Bit 10: Input terminal state Bit 11: Output terminal state Bit 12–15: Reserved...
  • Page 34 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code rectifier bridge module Temperature of ● P07.12 -20.0–120.0℃ inverter module Software version ● P07.13 1.00–655.35 of control board Accumulated ● P07.14 0–65535 h running time...
  • Page 35 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Type of the last 3: Inverter unit W phase ● P07.29 but one fault protection (OUt3) 4–5: Reserved Type of the last ● P07.30 6: Overcurrent (OC) but two fault 7–8: Reserved...
  • Page 36 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code medium-frequency power supply (A-IF) Running ● P07.33 frequency of 0 Hz present fault Ramp reference ● P07.34 frequency of 0 Hz present fault Output voltage of ●...

  • Page 37: P08 Group Enhanced Functions

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Output terminal ● P07.48 state of the last fault Running ● P07.49 frequency of the 0 Hz last but one fault Ramps reference ● P07.50...
  • Page 38 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code 0x000–0x1223 LED ones: Frequency control setting 0: Adjustment through both the ∧ / ∨ key and digital potentiometer are valid 1: Only adjustment through the ∧/∨ key is valid...
  • Page 39 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Integral rate of the ○ P08.43 keypad digital 0.01–10.00 s 0.01–10.00 1.00 s potentiometer 0x000–0x221 Ones: Frequency control selection 0: UP/DOWN terminal setup is valid...

  • Page 40: P09 Group Pid Control

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Tens: Action selection for frequency setup (by Modbus) during power down 0: Save during power down 1: Zero out during power down Hundreds: Action selection...
  • Page 41 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Proportional gain ○ P09.04 0.00–100.00 0.00–100.00 1.00 (Kp) ○ P09.05 Integral time (Ti) 0.01–10.00 s 0.01–10.00 0.10 s Derivative time ○ P09.06 0.00–10.00 s 0.00–10.00 0.00 s...

  • Page 42: P10 Group Multi-Step Speed Control

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code main reference A frequency source buffering is invalid 1: A+B frequency, acceleration/ deceleration of main reference A frequency source buffering is valid, acceleration and deceleration are determined by P08.04 (acceleration time...
  • Page 43 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Running time of ○ P10.07 0.0–6553.5 s (h) 0.0–6553.5 0.0 s step ○ P10.08 Multi-step speed 3 -100.0–100.0% -100.0–100.0 0.0% Running time of ○ P10.09 0.0–6553.5 s (h)

  • Page 44: P11 Group Protective Parameters

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Running time of ○ P10.29 0.0–6553.5 s (h) 0.0–6553.5 0.0 s step Multi-step speed ○ P10.30 -100.0–100.0% -100.0–100.0 0.0% Running time of ○ P10.31 0.0–6553.5 s (h) 0.0–6553.5...
  • Page 45 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Software 30.0%–200.0% (rated ◎ P11.06 current-limiting 30.0%–200.0% 120.0% current) level Software ○ P11.07 current-limiting 0–4000 0–4000 gain Hardware 20.0%–240.0% (peak of ◎ P11.09 current-limiting 20.0%–240.0% 220.0%...
  • Page 46 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code power supply reports OH3 fault, and stops.) 2: Potential difference control (When the actual temperature is not less than the upper limit of temperature (P11.22), the...

  • Page 47: P14 Group Serial Communication

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Upper limit of the temperature ◎ P11.25 sampling of the 0–4096 0–4096 3885 medium-frequenc y power supply P14 group Serial communication Function Name Description Setting range...
  • Page 48 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code 10: Even parity (E, 7, 2) for ASCII 11: Odd parity (O, 7, 2) for ASCII 12: No parity check (N, 8, 1) for ASCII...

  • Page 49: P17 Group State Viewing Functions

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code is invalid 1: Communication encryption is valid P17 group State viewing functions Function Name Description Setting range Default Modify code P00.05–P00.0 ● P17.00 Set frequency P00.05–P00.03...

  • Page 50: P18 Group Special State Viewing Functions

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code ● P17.20 AI2 input voltage 0.00–10.00 V 0.00–10.00 0.00 V -10.00–10.00 ● P17.21 AI3 input voltage -10.00–10.00 V 0.00 V HDI input 0.000 ● P17.22 0.000–50.000 kHz...
  • Page 51 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code P24.02) 1: AI1 2: AI2 3: AI3 4: HDI 5: Multi-step (the set value is determined by P10 group multi-step speed parameter) 6: PID 7: Modbus communication...
  • Page 52 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code resonance frequency of the load applicable constant voltage and current mode. 0: Disabled 1: Adapting to resonance frequency online -12.0%–60.0% Phase control ○ P24.10 Valid when tens of P24.09 is -12.0%–60.0%...

  • Page 53: P25 Group Function Group 2 Special For The Medium-Frequency Power Supply

    MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code 2: AI1 input detection 3: AI2 input detection 4: AI3 input detection 0.0–500.0A Max. AC incoming Max. current value ○ P24.17 0.0–500.0 A current corresponding analog inputs AI1–AI3.
  • Page 54 MF100 Series Medium-frequency Power Supply Function parameters Function Name Description Setting range Default Modify code Max. current for ○ P25.08 spot welding and 0–100% 0–100% updating Duty cycle of ○ P25.09 0.0–6.0% 0.0–6.0% 1.5% reverse recovery...

  • Page 55: Chapter 6 Commissioning Guide

    MF100 Series Medium-frequency Power Supply Commissioning guide Chapter 6 Commissioning guide 6.1 Commissioning procedures The first operation is described as below. Start Power on after checking that the wiring is proper Restore to default value (P00.18=1) Set the upper/lower limit of the running frequency (P00.04 and...

  • Page 56: Constant Voltage/Current Dual Working Mode

    MF100 Series Medium-frequency Power Supply Commissioning guide 6.2 Constant voltage/current dual working mode The medium-frequency power supply adopts the constant voltage mode by default, namely P24.00=0, and you can finish the parameter setting of output voltage through selecting P04.27–P04.32. Function...

  • Page 57: Adapting To Resonance Frequency

    MF100 Series Medium-frequency Power Supply Commissioning guide selecting P24.01–P24.02, and set P24.03–P24.04 as needed. Function Default Name Description Modify code value Working mode of 0–1 ◎ P24.00 0: Constant voltage output medium-frequency 1: Constant current output output 0–8 0: Keypad (current is set in P24.02)
  • Page 58 MF100 Series Medium-frequency Power Supply Commissioning guide Function Name Description Default value Modify 0x00–0x11 Ones: Aimed stable resonance frequency of the load, and applicable in the constant voltage mode 0: Disabled 1: The frequency detection function is enabled once. Tens: Aimed at the varying...
  • Page 59 MF100 Series Medium-frequency Power Supply Commissioning guide The second function is aimed at the load whose resonance frequency is varying during the running. When tens of P24.09 is set to 1, the medium-frequency power supply starts to run, and follows automatically the resonance frequency of the load.

  • Page 60: Automatic Current Limiting Setting

    MF100 Series Medium-frequency Power Supply Commissioning guide 6.4 Automatic current limiting setting P11.05 can be used to select two current-limiting methods, namely software and hardware current-limiting. P11.06 and P11.09 can be used to set the size of the corresponding current-limiting value.

  • Page 61: Running Password Protection

    MF100 Series Medium-frequency Power Supply Commissioning guide Function Name Description Default value Modify code than the upper limit of temperature (P11.22) or not not more than the lower limit of temperature (P11.21), the power supply reports OH3 fault, and stops.)
  • Page 62 MF100 Series Medium-frequency Power Supply Commissioning guide Function Name Description Default value Modify code Actual running ○ P17.36 0–65535 h time Actual time ○ P17.37 0–65535 h setting ○ P17.38 Set password 0–65535 Unlock the ○ P17.39 0–65535 password input 0–1...

  • Page 63: Chapter 7 Fault Tracking

    This chapter covers most of the alarms and faults, and their possible causes and corrective measures. If the alarm or fault causes cannot be figured out, you can contact local INVT office.
  • Page 64 MF100 Series Medium-frequency Power Supply Fault tracking Fault Fault type Possible cause Corrective measures code Misacts caused by Check whether there is strong interference; interference surrounds Inverter unit Drive wires are poorly peripheral equipment. OUt3 Phase-W connected ; protection To-ground short circuit occurs.
  • Page 65 MF100 Series Medium-frequency Power Supply Fault tracking Fault Fault type Possible cause Corrective measures code Overheat of Air duct is blocked or fan rectifier module is damaged; Ventilate the air duct or Overheat of Ambient temperature is replace the fan;...

  • Page 66: Other States

    MF100 Series Medium-frequency Power Supply Fault tracking 7.5.2 Other states Displayed State type Possible cause Corrective measures code The system is powered System power PoFF off or the bus voltage is Check the grid conditions. failure too low. Current prealarm...

  • Page 67: Chapter 8 Communication Protocol

    Chapter 8 Communication protocol 8.1 What this chapter contains This chapter describes the communication protocol of MF100 series products. MF100 medium-frequency power supply provides RS485 communication interfaces, and adopts the master-slave communication based on the international standard Modbus communication protocol.

  • Page 68: Rtu Mode

    MF100 Series Medium-frequency Power Supply Communication protocol varies according to the baud rate, as described in the following table. Baud rate Max. transmission Baud rate Max. transmission (bps) distance (bps) distance 2400 1800 m 9600 800 m 4800 1200 m...

  • Page 69: Ascii Mode

    MF100 Series Medium-frequency Power Supply Communication protocol The CRC check value is incorrect due to the disorder of the frames, and thus a communication fault occurs. The following table describes the standard structure of an RTU frame. START (frame header) T1-T2-T3-T4 (transmission time of 3.5 bytes)

  • Page 70: Error Check Modes Of Rtu Communication Frame

    MF100 Series Medium-frequency Power Supply Communication protocol ASCII data frame format Modbus message Slave Function End character: "0x00" Start character: "0x3A" Data Checkout address code "0x0A" Standard structure of ASCII frame: START ":" (0x3A) Address Hi Communication address: 8-bit address is formed by the combination of two ASCII codes...
  • Page 71 MF100 Series Medium-frequency Power Supply Communication protocol 8.3.4.2 CRC check mode---CRC(Cyclical Redundancy Check) A frame in the RTU format includes an error detection domain based on the CRC calculation. The CRC domain checks all the content of the frame. The CRC domain consists of two bytes, including 16 binary bits.

  • Page 72: Command Code And Communication Data

    MF100 Series Medium-frequency Power Supply Communication protocol In the ladder logic, CKSM uses the table look-up method to calculate the CRC value according to the content in the frame. The program of this method is simple, and the calculation is fast, but the ROM space occupied is large.
  • Page 73 MF100 Series Medium-frequency Power Supply Communication protocol RTU master command (transmitted by the RTU slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) ADDR (address) ADDR CMD (command code) Most significant byte...
  • Page 74 MF100 Series Medium-frequency Power Supply Communication protocol RTU master command (transmitted by the RTU slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) LSB of data writing LSB of data writing address...
  • Page 75 MF100 Series Medium-frequency Power Supply Communication protocol RTU master command (transmitted by the RTU slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) T1-T2-T3-T4 T1-T2-T3-T4 (transmission time of (transmission time of 3.5 bytes) 3.5 bytes)

  • Page 76: Ascii Mode

    MF100 Series Medium-frequency Power Supply Communication protocol RTU master command (transmitted by the RTU slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) MSB of CRC T1-T2-T3-T4 (transmission time of 3.5 bytes) 8.4.2 ASCII mode...
  • Page 77 MF100 Series Medium-frequency Power Supply Communication protocol ASCII master command (transmitted by the ASCII slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) START START ADDR ADDR MSB of data writing MSB of data writing...
  • Page 78 MF100 Series Medium-frequency Power Supply Communication protocol ASCII master command (transmitted by the ASCII slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) MSB of data content MSB of data content MSB of data content...

  • Page 79: Data Address Definition

    MF100 Series Medium-frequency Power Supply Communication protocol ASCII master command (transmitted by the ASCII slave response (transmitted by the master to the medium-frequency power medium-frequency power supply to the supply) master) MSB of data in 0005H LSB of data in 0005H...

  • Page 80: The Address Instruction Of Other Functions In Modbus

    MF100 Series Medium-frequency Power Supply Communication protocol on-chip RAM, that is, modifying the MSB of the corresponding function code address from 0 to 1. For example, if P00.07 is not to be stored in the EEPROM, you need only to modify the value of the RAM, that is, set the address to 8007H.
  • Page 81 MF100 Series Medium-frequency Power Supply Communication protocol Function Address Data description Bit 0: =0: Not ready to run =1: Ready to run State word 2 of the Bit 1–4: Reserved medium-frequency 2101H Bit5–Bit6: =00: Keypad-based control power supply =01: Terminal-based control...

  • Page 82: Fieldbus Scale

    MF100 Series Medium-frequency Power Supply Communication protocol 6H is used to control the medium-frequency power supply. The R characteristic indicates that a function can only be read, and W indicates that a function can only be written. Note: Some parameters in the preceding table are valid only after they are enabled. Take the running and stop operations as examples, you need to set "Running command channel"...

  • Page 83: Error Message Response

    MF100 Series Medium-frequency Power Supply Communication protocol 04 1D 00 32 99 29 Address of the Write Parameter address Parameter data CRC check medium-frequency command power supply After receiving the command, the medium-frequency power supply converts 50 into 5.0 based on the fieldbus scale, and then sets "Voltage increase time"...
  • Page 84 MF100 Series Medium-frequency Power Supply Communication protocol Code Name Definition Password The password entered in the password verification address is error different from that set by the user in P07.00. The length of the data frame transmitted by the upper computer is...

  • Page 85: Read/Write Operation Example

    MF100 Series Medium-frequency Power Supply Communication protocol But the setting range of the "Running command channel" is 0 to 2. The value 3 exceeds the setting range. In this case, the medium-frequency power supply returns an error message response as...

  • Page 86: Write Command 06H Examples

    MF100 Series Medium-frequency Power Supply Communication protocol CR LF 00 03 Number of Address of the Read Data content LRC check START bytes medium- command frequency power supply The data content returned by the medium-frequency power supply is 0003H. From the table, the medium-frequency power supply stops.
  • Page 87 MF100 Series Medium-frequency Power Supply Communication protocol 06 20 00 00 01 D6 CR LF Address of the Write Parameter Data quantity LRC check START medium-frequency address command power supply Example 2: Set the "Max. output frequency" of the medium-frequency power supply whose address is 03H to 100 Hz.

  • Page 88: Continuously Write Command 10H Examples

    MF100 Series Medium-frequency Power Supply Communication protocol 8.6.3 Continuously write command 10H examples Example 1: Set the medium-frequency power supply whose address is 01H to be running at the frequency of 10 Hz. Refer to the table of other function parameters, the address of "Communication-based control command"...
  • Page 89 MF100 Series Medium-frequency Power Supply Communication protocol 20 00 00 02 CR LF Continuous Parameter Data quantity LRC check Address of the START address write command medium frequency power supply Example 2: Set "Acceleration time" of the medium-frequency power supply whose address is 01H to 10 s, and "Deceleration time"...

  • Page 90: Modbus Communication Commissioning Example

    MF100 Series Medium-frequency Power Supply Communication protocol Note: In the preceding command description, spaces are added to a command just for explanatory purposes. In practical applications, no space is required in the commands. 8.6.4 Modbus communication commissioning example A PC is used as the host, an RS232-RS485 converter is used for signal conversion, and the PC serial port used by the converter is COM1 (an RS232 port).

  • Page 91: Common Communication Faults

    MF100 Series Medium-frequency Power Supply Communication protocol 42 28 20 00 00 01 Address of the Write Parameter address Running CRC check medium- command frequency power supply 8.7 Common communication faults Common communication faults include the following: 1. No response is returned.

  • Page 92: Appendix A Dimension Drawings

    Dimension drawings Appendix A Dimension drawings A.1 What this chapter contains This chapter describes the dimension drawings of MF100 series medium-frequency power supply. The dimension unit used in the drawings is mm. A.2 Keypad dimensions A.2.1 Structure dragram of 1PH 220 V external keypad...

  • Page 93: Structure Diagram Of 3Ph 380 V Keypad

    MF100 Series Medium-frequency Power Supply Dimension drawings A.2.2 Structure diagram of 3PH 380 V keypad Structure diagram of 3PH Installation hole diagram for keypad installation without 380V keypad bracket Note: When installing an external keypad, you can directly use threaded screws or a keypad bracket to fix it.

  • Page 94: Dimensions Of The Medium-Frequency Power Supply

    MF100 Series Medium-frequency Power Supply Dimension drawings Keypad installation bracket Customer installation (standard) of 37 to 315 kW dimensions A.3 Dimensions of the medium-frequency power supply A.3.1 Rail installation dimensions Figure A-1 Rail installation diagram of 1PH 220 V Table A-1 Rail installation dimensions of 1PH 220 V (unit: mm)

  • Page 95: Wall-Mounting Dimensions

    MF100 Series Medium-frequency Power Supply Dimension drawings A.3.2 Wall-mounting dimensions Figure A-2 Wall-mounting diagram of 1.1 to 15 kW Figure A-3 Wall-mounting diagram of 18.5 to 30 kW Figure A-4 Wall-mounting diagram of 37 to 110 kW...
  • Page 96 MF100 Series Medium-frequency Power Supply Dimension drawings Figure A-5 Wall-mounting diagram of 132 to 200 kW Figure A-6 Wall-mounting diagram of 220 to 315 kW Table A-2 Wall-mounting dimensions of 1PH 220 V (unit: mm) Specification of the Installation medium-frequency...

  • Page 97: Flange Installation Dimensions

    MF100 Series Medium-frequency Power Supply Dimension drawings A.3.3 Flange installation dimensions Figure A-7 Flange installation diagram of 2.2 to 15 kW Figure A-8 Flange installation diagram of 18.5 to 30 kW Figure A-9 Flange installation diagram of 37 to 110 kW...
  • Page 98 MF100 Series Medium-frequency Power Supply Dimension drawings Figure A-10 Flange installation diagram of 132 to 200 kW Table A-4 Flange installation dimensions of 1PH 220 V (unit: mm) Specification of Installation hole medium-frequency diameter power supply 4 kW 170.2 131 84.5...

  • Page 99: Floor Installation Dimensions

    MF100 Series Medium-frequency Power Supply Dimension drawings A.3.4 Floor installation dimensions Figure A-11 Floor installation diagram of 220 to 315 kW Table A-6 Floor installation dimensions (unit: mm) Specification of Installation hole medium-frequency diameter power supply 13\12 220 kW–315 kW...
  • Page 100 6 6 0 0 1 - 0 0 5 9 7...
