STYLE SELECTIONS and logo design are
trademarks or registered trademarks of LF,
LLC. All rights reserved.
Serial Number
Purchase Date
SG241079
Thank you for purchasing this
Questions, problems or missing parts?
Before returning, contact us on:
877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Sunday or ascs@lowes.com.
10X13 POWER PLAY
STYLE SELECTIONS
product
1
ITEM #5998271
MODEL #GFM60131Q
GAZEBO
ATTACH YOUR RECEIPT HERE
Advertisement
Related Manuals for Style selections GFM60131Q
Summary of Contents for Style selections GFM60131Q
- Page 1 ITEM #5998271 MODEL #GFM60131Q 10X13 POWER PLAY GAZEBO STYLE SELECTIONS and logo design are ATTACH YOUR RECEIPT HERE trademarks or registered trademarks of LF, LLC. All rights reserved. Serial Number Purchase Date Thank you for purchasing this STYLE SELECTIONS product...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents..........................3 Hardware Contents...........................5 Safety Information..........................6 Preparation............................7 Assembly Instructions ....................8 Care and Maintenance........................18 Warranty............................18 PRODUCT SPECIFICATIONS SPECIFICATIONS Dark gray finish frame For outdoor use only. -
Page 3: Package Contents
PACKAGE CONTENTS L U1 L U2 L U3 L U4 L V2 L V1... - Page 4 PACKAGE CONTENTS L W2 L W1 L V3 L W3 L X1 L X2 PART DESCRIPTION PART DESCRIPTION QUANTITY QUANTITY Post leg Short Side Left Edge Cap Foot Plate Short Side Right Edge Cap Foot Plate Cover Roof Top Inclined Edge Cap Long Side Left Cross Beam Roof Topper Side Roof Panel Long Side Right Cross Beam...
-
Page 5: Hardware Contents
HARDWARE CONTENTS (shown actual size) M6 x 10 mm 10 mm Nut with Bolt M6 x 15 mm T-slot Bolt M6 Threads Bolt 8.8 x 10.5 x Qty. 32+1 Bolt M6 x 12 mm Qty. 32+1 M6 x 35 mm Qty. -
Page 6: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. WARNING Not intended for commercial use. For optimum safety, use on even surface only! Improper use of this product or failure to use or assemble as directed may result in injury.This unit is heavy! Do not assemble this item alone. -
Page 7: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 160 minutes Tools Required for Assembly (not included): 15 ft Tape Socket Wrench... -
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Assemble post leg. First, insert post leg (A) into foot plate cover (C), then insert foot plate (B) into post leg (A) , secure it using (BB). Repeat x 4. Hardware Used M6 X 15 mm Bolt x 12 2. - Page 9 ASSEMBLY INSTRUCTIONS 4. Assemble gazebo frame. Place remaining long side left cross beam (D1), long side right cross beam (D2), short side left cross beam (D3), short side right cross beam (D4) on post leg (A) to connect the frames from step 4. Finally secure with (NN). Repeat x 4 Hardware Used Allen Wrench 2...
- Page 10 ASSEMBLY INSTRUCTIONS Assemble corner rafter support & top plate with welded corner flap. Secure the corner rafter support (F) on the top plate with welded corner flap (G), then secure to the four post leg (A) by using (AA & BB & FF), then tighten with (MM). Repeat x 4 Hardware Used M6 x 10 mm Bolt...
- Page 11 ASSEMBLY INSTRUCTIONS 10. Assemble side rooftop cross beam. Place short side rooftop cross beam (K1) and long side rooftop cross beam (K2) between top frame connector - 2 (J2) and connector for top - 1 (J1), secure by using (CC & GG & HH). Repeat x 4 Hardware Used M6 X 35 mm Bolt...
- Page 12 ASSEMBLY INSTRUCTIONS 13. Assemble 2nd tier roof. Secure short corner rafter (L) into small side-topper brace (N1) and long side -topper brace (N2), then secure rooftop connection (M) on the short corner rafter (L), by using (BB), finally secure hook (PP) into rooftop connection (M). Repeat x 4.
- Page 13 ASSEMBLY INSTRUCTIONS 16. Assemble roof frame. Put the frame assembled in step 15 on the frame in step 12 and secure it using (BB). Repeat x 4. Hardware Used M6 X15 mm Bolt 17. Assemble stud. Unfold long side rafter branch (R1) and short side rafter branch (R2), insert (KK) into long side rafter branch (R1) and short side rafter branch (R2).
- Page 14 ASSEMBLY INSTRUCTIONS Note: Make sure holes at bottom of panels align before tightening fully bolts. 19. Assemble long side middle roof panel. Secure the long side middle roof panel (V1) to the long side rafter branch (R1) by using (II & GG & JJ). Repeat x 2.
- Page 15 ASSEMBLY INSTRUCTIONS 22. Assemble roof panel corner Install short/long side left roof panel corner (X1) and short/long side right roof panel corner (X2) into the short/long side left roof panel 1 (W2) and short/long side right roof panel 1 (W3), secure with (BB).
- Page 16 ASSEMBLY INSTRUCTIONS 25. Assemble roof panel 1 Install short/long side left roof panel 1 (W2) and short/long side right roof panel 1 (W3) on roof panel, secure with (BB). Repeat x 4. Hardware Used M6 X 15 mm Bolt 26. Assemble roof panel corner Install short/long side left roof panel corner (X1) and short/long side right roof panel corner (X2) on roof panel, secure with (BB).
- Page 17 ASSEMBLY INSTRUCTIONS 28. Assemble roof top inclined edge cap Install roof top inclined edge cap (T) on roof panel, secure with (CC). Repeat x 4. Hardware Used M6 X 35 mm Bolt...
-
Page 18: Care And Maintenance
CARE AND MAINTENANCE rinse and dry completely. TROUBLESHOOTING Hardware may loosen overtime. Periodically check that all Frame is unstable. connections are tight. WARRANTY This warranty is extended to the original purchaser and applies to defects in materials and workmanship of your patio furniture provided your furniture is maintained with care and used only for personal, residential purposes.
