This document aims to familiarize the reader on the different functionalities and interfaces of C17QS Evaluation board. It also helps the customer in getting started with the C17QS EVK. The EVK is a tool designed for engineers, programmers and developers who are looking to: •...
C17QS EVK User Manual Interfaces 2.1 Chapter Overview Description: This chapter contains all the necessary information on C17QS EVK Interfaces and Pin-outs. 2.2 EVK Layout Figure 1: C17QS EVK Layout www.cavliwireless.com...
C17QS EVK User Manual Component Description Figure 4 C17QS EVK Components LTE Main Antenna USB-UART interface 11. USB boot button GNSS Antenna Input Power Port (Type C) 12. FTDI interface IC SIM card socket Power Button SD card socket Input power toggle switch USB interface 10.
Page 12
C17QS EVK User Manual Pin No. Pin name Description C17QS EVK comes with an SMA Antenna connector for LTE Main antenna interfacing an external LTE Antenna. C17QS EVK comes with an SMA Antenna connector GNSS antenna along with active antenna of voltage 3.3V for interfacing external GNSS Antenna.
C17QS EVK User Manual 3.1 LED Indicators Figure 5 : C17QS LED indicators Led Indicators of C17QS EVK are: 1. VBATT power indicator 2. FTDI Channel-B Rx and Tx indicator 3. FTDI Channel-A Rx and Tx indicator 4. Input Power indicator 5.
C17QS EVK User Manual Setup Guide 4.1 Basic Start-up Steps Given below are the various steps involved in powering on the C17QS Module. 1. Place the EVK on an insulated platform. 2. Connect the GNSS Antenna (if needed) to the corresponding SMA Connectors.
